AG Neovo TX-W42 Manuale utente

NeoV™ Touch Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

www.agneovo.com

TX-W42

A 42” multi-touch display

engineered with advanced optical

touch technology and NeoV™ Touch

Glass for the busiest and most

engaging public environments.

For the best in versatility, durability and now multi-touch

interactivity, display professionals choose the AG Neovo TX-W42.

Advanced optical touch technology provides accurate, zero-

pressure response from any pointing object, even gloved ngers and

styluses. With Windows® 7 multi-touch compatibility, the TX-W42

is making it possible for audio-visual designers and integrators

to develop exciting and interactive applications. Featuring anti-

ngerprint NeoV™ Touch Glass and sturdy metal design, the

TX-W42 is designed to perform in point-of-sale systems, directories,

information kiosk and other public environments.

> Incorporates advanced optical touch technology

> Multi-touch capabilities for systems with Microso® Windows® 7

> 1920 x 1080 Full HD resolution

> 4000:1 contrast ratio

> NeoV™ Touch Glass prevents the screen from ngerprints

> Anti-Burn-in™ technology

> Horizontal resolution up to 630TVL (NTSC), 650TVL (PAL)

> Smart Omni Viewer: PIP , PBP and VOV functions

> Built-in Image Enhancer: 3D Comb Filter/ Deinterlace/ Noise Reduction

> Versatile connectivity (VGA, DVI, BNC in/out x 2, S-Video, Component)

> RS-232 for individual and multi-display control

> NTSC/PAL video system support

> Built-in speakers

> IR remote control

> Durable metal housing

> Control key lock function

> VESA standard wall mount

REACH

NeoV™ Touch Glass keeps the screen protected

and looking new.

Mutiple video inputs (VGA, DVI, dual BNC,

S-Video and Component) allow for eortless

system integration

Advanced optical touch technology for accurate,

zero-pressure response multi-touch gestures

Anti-Burn-in™ technology prevents image sticking

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: TXW4A0 Version 4.0, 20110120

Speciﬁcations TX-W42

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

TFT LCD

42.0”

FHD 1920 x 1080

0.48455 mm

450 cd/m2( Typical)

4000:1 (Typical)

178°/178° (Typical)

16.7M

6.5 ms (GTG)

Frequency (H/V) H: 24 kHz - 82 kHz

V: 50 Hz - 85 Hz

Input VGA

DVI

CVBS

S-Video

Component (YPbPr)

15-Pin D-Sub

24-Pin DVI-D

BNC x 2

4-Pin mini DIN

RCA x 2

Output CVBS

S-Video

BNC x 2

4-Pin mini DIN

External Control RS-232C in/out 9-Pin D-Sub

Audio Audio In

Audio Out

Speaker

1 x stereo audio in for PC (3.5 Ø)

1 x stereo audio in for CVBS (RCA)

1 x stereo audio in for S-Video (RCA)

2 x stereo audio in for YPbPr (RCA)

1 x stereo audio out for CVBS (RCA)

2W x 2

Touch Screen Technology

Positional Accuracy

Active Force

Panel Interface

Optical

±3mm over 95% of touchable area

None required

USB 1.1 (Full speed, HID compliant)

Power DC Output

Power

Consumption

12V / 350 mA, DC jack 2.5 Ø

100 - 240V, 50 - 60 Hz

< 165W (On) / < 10W (Off)

NeoV™

Touch Glass

Thickness

Gloss

Transmission Rate

Coating Hardness

3.0 mm (0.18”)

100 GU

> 92%

> 8H

Operating

Conditions

Temperature

Humidity

0°C ~ 40°C (32°F ~ -104°F)

10% ~ 85%

Mounting VESA FPMPMI 400 x 200 mm & 600 x 400 mm

Dimensions Without Base

(W x H x D)

With Base

(W x H x D)

1011 x 604 x 122 mm

(39.8” x 23.8” x 4.8”)

1011 x 667 x 190 mm

(39.8” x 26.3” x 7.5”)

Weight With / Without Base 29.4 kg (64.7 lbs) / 27.9 kg (61.4 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC, CE, BSMI, RoHS, WEEE, REACH

Accessories Supplied CD (user manual and touch driver),

15-Pin VGA cable, 24-Pin DVI cable,

power cord, audio cable, USB cable,

IR remote

TX-W42
