Introduction
Thank you for choosing BT-FG01 security smoke system. It is the most effective
and reliable security system to protect your property and premises. Please read
this instruction to ensure you have the maximum performance of your security
smoke system. If you have any question or uncertainty, please contact with your
dealer. Once again, thank you for your choice. We hope it is an equipment which
never needs to be tested in real life.
Every effort has been made to ensure the contents in this manual are correct. The factory
does not accept any liability for loss or damage caused or alleged to be caused directly
or indirectly by this manual. The factory reserves the right to change the contents in
this manual without any further notice.
Reminder: Before installation, please ensure that you have all the following items in the box:
Security Smoke Generator x 1
Mounting Wall Bracket x 1
Smoke Fluid Bag x 1
Placing or changing Fluid Bag
When placing or changing fluid bag, please ensure the fluid needle is inserted into fluid
bag completely. Locate the bag neck in the holder and ensure the fluid micro switch is
activated properly and screw the bag clamp tightly. Every time when placing a new fluid
bag, please make sure mains power is applied to smoke generator. This can allow fluid
timer be reset correctly.
Fluid Consumption Calculation and Reset
The fluid consumption is calculated and monitored by an on-board fluid timer. In order to avoid
incorrect fluid consumption calculation, every time when the bag clamp is unscrewed and the
fluid bag is removed and the fluid micro switch is released, ensure a new (full fluid bag is
replaced to reset the on-board timer.
Important: Every time when placing a new fluid bag, please make sure mains power is applied
to smoke generator. This can allow fluid timer be reset correctly!
Fluid Micro Switch
Bag Clamp
Insert Fluid Needle
