AGPtek M08 Manuale utente

01-13 AGPTek M08 Music Player User Maunal

14-26 M08 MP3 Player Bedienungsanleitung

27-39 AGPTek M08Music Player Guía rápido de inicio

40-53 AGPTek M08 Music Player Guida Rapida

54-67 AGPTek M08 Music Player Guide Rapide

68-78 AGPTek M08MP3

プレーヤー取扱説明書

INDEX

Music.......................................................................................................4

FM radio..................................................................................................6

Folder View............................................................................................ 7

Set............................................................................................................7

Recordings..............................................................................................8

EBook......................................................................................................9

Help and Troubleshooting..................................................................10

Specifications.......................................................................................12

Buttons and controls

1. Display screen

2. “ ”:Play/Pause/Sel

ection button

3. “ ”: Previous/Fast

backward button

4. “ ”: Next/Fast

forward button

5. “M”: Menu button

/Screen lock button

6. Back button

7. Power button

8. Volume +

9. Volume -

10. TF card slot

11. USB port

12. Reset hole

13. Earphone jack

Charge the Player

1. Plug the attached USB cable into the USB port of a computer to

charge the player.

2. Use only the 5V/500mA charger for charging or it may lead to

product failure.

While it is fully charged, disconnect the cable from your device by

pulling it straight outward.

When you start charging, it will show two options: “Charge &

Transfer”and “Charge & Play”. An icon in the top right corner will

show the charging status.

Power On/Off

Hold the power button switch on/off the device. Click to wake

up/turn off the screen while it is working on backstage.

Note: The player will power off automatically if inactive and no

applications operate on backstage for 2 minutes.

Volumn Adjustment

Click button +/- on the left side to increase/decrease the volume.

Main interface

Each time you press the button / , it will bring you to one of

its 9 different functions, including Music, FM radio, Folder View, Set,

Recordings, Pictures, EBook, Video and Last Played(Now Playing)

Music

When there is a Music icon in the main interface, click button

to access to its function. The related list will show, including: All

songs, Last played, Artists, Albums, Genres, Playlists, Create Playlist.

Choose from these menu, and click button to play the music.

Last played: start playing from where you left last time;

Create Playlist: all your favorite songs can be added here.

Rewind/Forward

While it’s on music playing interface, hold the button / to

rewind/fast forward, short press to previous/next music file. Click

button for playing/pause.

Submenu

While it’s on music playing interface, click button M to access to

the submenu.

The related list will show, including “Home”,“Shuffle”,“Repeat”,

“Bookmarks”

,“Play music from”

,“Equalizer”

,“Variable Speed

Playback”,“Sleep timer”,“Delete”“Add to playlist”and“Remove

from playlist”.

1. Bookmarks

Click button M >Bookmarks>Add bookmark /Go to bookmark

/Delete bookmark. Select according to your need.

2. Variable Speed Playback

Click button M >Variable Speed Playback to adjust speed from

-8(Slowest) to +8(Fastest ). Set the playing speed as you need.

3. Delete

Click button M >Delete, then choose yes to delete the audio files

you want.

4. Equalizer

Click button M >Equalizer >Normal, Rock, Funk, Hip hop”,“Jazz”,

“Classical”,“Techno”,“Custom”.

FM radio

Insert the earphone, then select FM frequency from 87.5 to

108.0MHz.

While in the FM radio playing interface, press button Mto enter

the submenu: Home, Start FM radio recording, Presets, Save to preset,

Clear preset, Auto tune, Tuner region, FM recording.

Tune to the radio station you want. Choose Start FM radio

recording to start recording the radio. Click to pause/resume.

Click and choose yes to save the recording and it will back to

the FM radio interface automatically. Click button M to find the

saved recordings in FM recording.

Note: The radio recordings will also be saved in

Recordings >Recordings library.

Folder View

Find Folder View on main screen with button to access to its

function.

Click button M/to choose from the different folders/files. Click

to play/view.

Note: Always put the lyric file and the music file in the same folder.

Set

When there is a Set icon in the main interface, click button to

access to its function. The related list will show, including: Play

mode, Sound settings, Sleep timer, Display settings, Date and time,

Language, Information, Format device, Factory settings, Create

playlist.

Note: when you set “date and time”, use button Mto switch to next

one. For example, “Set time”, after you set the hour, press button M

to switch to set minute.

Recordings

When there is a Recordings icon in the main interface, click button

to access to its function. The related list will show, including:

Start voice recording, Storage, Recordings library, Record format,

Record settings.

- Click button to start recording, click it again to

pause/resume.

- Click the button and choose yes to save the recording.

- Find the saved recordings in Recordings >Recordings library.

Click the button M/ to select from all the recordings you have

saved. Then click the button to play the recordings.

Record format: MP3/WAV/ACT Rec

Record settings > set rec bitrate/VOR(Voice Operated

Recording)/set recording scene

EBook

When there is a EBook icon in the main interface, click button

to access to its function. While reading e-book, press button Mto

enter the submenu: Playsetting(Auto scroll time), Delete ebook,

Bookmark Select, Delete bookmark, Add book mark, Page select.

Note: Only txt format is supported for EBook.

Last Played(Now Playing)

When there is a Last Played(Now Playing) icon in the main interface,

click button to access to its function. The music/radio playing

interface will be shown, and it will resume playing music/radio

from where you left.

Note: When there is no music/radio playing in the backstage, the

Last Played(Now Playing) function will not be available.

Help and Troubleshooting

●Can’t turn on the player

- Please check whether the player is run out of battery, connect the
