Akai AD66U Manuale utente
DVD player
ALD1915H
GB 2
NL 19
FR 38
ES 56
DA112
DE 74
EL 93
User manual
Gebruiksaanwijzing
Manuel de l’utilisateur
Manual de instrucciones
Gebrauchsanleitung
Οδηγίες χρήσεως
Brugsanvisning
AD66U
Table of contents
Copyright notice
Design and specications are subject to change without notice.
1. Safety........................................................................... 3
1.1 Intended use ....................................................................3
1.2 Labels in this manual .......................................................3
1.3 General safety instructions ..............................................3
2. Preparations for use................................................... 4
2.1 Unpacking ........................................................................4
2.2 Package contents ............................................................5
3. Installation................................................................... 5
3.1 Connecting random equipment ........................................6
3.2 Remote control.................................................................7
4. Functions..................................................................... 7
4.1 DVD Player ......................................................................7
4.2 Remote control.................................................................8
5. Operation..................................................................... 8
5.1 Quick start ........................................................................8
5.2 DVD/CD functions ............................................................9
5.3 USB functions ................................................................12
5.4 General setup menu operation ......................................13
6. Cleaning and maintenance ...................................... 14
6.1 Handle and care of a disc ..............................................14
7. Troubleshooting........................................................ 15
8. Technical data........................................................... 17
9. Disposal of used electrical
and electronic equipment ........................................ 18
3
AD66U
Safety1.
Intended use1.1
The DVD Player plays lm and photos from DVD and USB. The appliance
also plays music from CD. Read the manual carefully before rst use.
2 DVDs and DVD appliances are manufactured under the worldwide
agreed DVD regional code system that the appliance will operate
only with corresponding disc of the same regional code. If the code
number on the label of a DVD does not match that on the label
alongside, the DVD will not play on this appliance.
i The appliance has built-in copyright protection technology that
prevents copying from a disc to any media. If a video recorder is
connected to the appliance, the video output image will be distorted
during recording.
Labels in this manual1.2
! WARNING
A warning means that injury or death is possible if the instructions
are not obeyed.
! CAUTION
A caution means that damage to the equipment is possible.
i
A note gives additional information, e.g. for a procedure.
General safety instructions1.3
! WARNING
Do not put force on the appliance. The appliance can fall and can
cause serious injury.
4
! CAUTION
Do not spill any liquid on the appliance.
! WARNING
Do not insert any objects in the ventilation holes.
! CAUTION
Do not block the ventilation holes.
i This appliance is double insulated; therefore no earth wire is
required. Always check that the mains voltage corresponds to the
voltage on the rating plate.
L This appliance employs a laser system. To prevent direct exposure
to the laser beam, do not open the appliance. Visible laser
radiation when open and interlock defeated.
Preparations for use2.
Unpacking2.1
● Unpack the appliance carefully.
● Check the package contents as described below. If any item is missing,
please contact your reseller.
● Remove the labels from the front panel carefully if present.
i We recommend that you retain the original carton and packing
materials in case it ever becomes necessary to return your product
for service. This is the only way to safely protect the product
against damage in transit. If you do dispose of the carton and the
packing materials, please remember to recycle with due care to the
environment.
5
AD66U
Package contents2.2
The following items are included in the received package:
1 DVD Player
1 Remote control
2 Batteries (AAA)
1 Operator manual
i
If any item is missing, please contact your reseller.
Installation3.
● Put the appliance on a horizontal at surface.
● Connect the random equipment to the appliance.
Read the paragraph "Connecting random equipment".
● Connect the appliance to the mains.
● Install the batteries in the remote control.
Read the paragraph "Remote control".
!
CAUTION
● Do not put the appliance near a heat source.
● Do not expose the appliance to direct sunlight.
i This appliance is equipped with rubber feet to prevent it from
moving. The feet are made from non-migrating material specially
formulated to avoid leaving any marks or stains on furniture.
However, certain types of furniture polishes, wood preservatives or
cleaning sprays cause the rubber to soften and leave marks or a
residue on the furniture, and potentially risk the surface to become
damaged. To prevent damage to wooden surfaces, we recommend
that you apply self-adhesive pads to the bottom of the rubber feet
before installation.
6
Connecting random equipment3.1
The appliance includes various options
for permanent connection of random
equipment. Suitable cables can be
purchased at your reseller.
Audio connections (output)
These connections allow you to send
audio signal to a connected TV or
amplier.
The appliance has the following audio
outputs:
● Coaxial digital audio: Insert a
suitable cable into the COAXIAL
connection.
Connect the other end of the cable to
the audio input of your random equipment.
Video connections
These connections allow you to send video signal (still images or movies) to
a connected TV.
The appliance has the following video outputs (in order of preference):
● SCART: Insert a suitable cable into the SCART connection.
Connect the other end of the cable to the video input of your random
equipment.
7
AD66U
Remote control3.2
Install batteries
● Remove the battery cover.
● Insert the batteries matching the (+)
and (-) polarity markings.
● Re-install the battery cover.
! CAUTION
Incorrect installation can
cause battery leakage and
corrosion which will damage
the appliance. Corrosion,
oxidation, battery leakage
and any other gradually
acidic defect of this nature
will invalidate the guarantee.
Functions4.
DVD Player4.1
1 2 3 4 5 6 7
1 POWER/STANDBY button
2 Disc tray
3 Display
4 Remote control sensor
5 OPEN/CLOSE button
6 PLAY/PAUSE button
7 USB slot
8
Remote control4.2
8 POWER/STANDBY button
9 Digit buttons (0-9)
10 ZOOM/MENU button
11 SUBTITLE/TITLE button
12 SETUP button
13 AUDIO/ANGLE button
14 Arrow buttons
15 OK button
16 REW button
17 FWD button
18 PREV button
19 NEXT button
20 MUTE button
21 GOTO button
22 DISPLAY button
23 VOL- button
24 VOL+ button
25 STOP button
26 PLAY/PAUSE button
27 REPEAT/PROG button
28 USB button
29 OPEN/CLOSE button
Operation5.
All functions of the appliance are accessible using the remote control.
All instructions refer to operation with the remote control, unless indicated
otherwise.
Quick start5.1
General functions
● Set the appliance in the standby mode.
● To switch on the appliance, press the POWER/STANDBY button (8).
To switch back to the standby mode, press the POWER/STANDBY button
(8) again.
8
9
22
25
10
11
12
15
14
13
16
17
18
19
20
21
23
24
26
27
28
29
9
AD66U
● To adjust the volume, press the VOL+ button (24) or the VOL- button (23).
● To mute or restore sound, press the MUTE button (20).
DVD/CD functions
● Switch on the appliance.
● Press the OPEN/CLOSE button (29) to open the disc tray (2).
● Place a disc in the disc tray (2).
● Press the OPEN/CLOSE button (29) to close the disc tray (2).
The display shows the total number of tracks on the CD.
● To start playback, press the PLAY/PAUSE button (26) once.
● For extended instructions, read the paragraph "DVD/CD functions" further
on in this manual.
USB functions
● Switch on the appliance.
● Insert the device in the slot (7). The device can only be connected one way.
● Press the USB button (28) to select the USB mode.
● To start playback, press the PLAY/PAUSE button (26) once.
● For extended instructions, read the paragraph "USB functions" further on
in this manual.
DVD/CD functions5.2
After the disc has been loaded, a content menu will display on the TV screen.
● Press the arrow buttons (14) to select a menu item.
● Press the OK button (15) to enter the selected menu item.
During playback, the following functions are available:
● To select a chapter (DVD) or track (CD), press the digit buttons (9).
● To select the next or previous chapter (DVD) or track (CD), press the
PREV button (18) or the NEXT button (19).
● To forward or rewind the DVD, press the FWD button (17) or the REW
button (16). The available speed rates are: 2, 4, 8, 16, 32.
● To pause playback, press the PLAY/PAUSE button (26). To resume
playback, press the PLAY/PAUSE button (26) again.
● To stop playback temporarily, press the STOP button (25). To stop
playback permanently, press the STOP button (25) again. To resume
playback, press the PLAY/PAUSE button (26).
● To repeat a chapter (DVD) or one or all tracks (CD):
Press the REPEAT button (27) to repeat the current chapter or track.•
10
Press the REPEAT button (27) again to repeat the current title.•
Press the REPEAT button (27) again to repeat all chapters or tracks.•
Press the REPEAT button (27) again to cancel the function.•
● To view a specic title of a DVD, press the TITLE button (11). Use the
arrow buttons (14) to select the title.
● To switch on the subtitles of a DVD, press the SUBTITLE button (11). To
switch off the subtitles of a DVD, press the SUBTITLE button (11) again.
● To select the audio language of a DVD, press the AUDIO button (13)
repeatedly until the desired language is set.
● To select extra information of a DVD or CD (remaining time/passed
playtime/track number/chapter number), press the DISPLAY button (22).
● To select the camera angle, press the ANGLE button (13).
i
● Normally, if an MP3 disc is loaded, the unit will take longer time to read
the initial data.
● A DVD that does not match the region code cannot be read by this
appliance.
● If a disc contains mixed content (e.g. MP3 and video les), the appliance
will only recognise, list and play one content type.
● The screen saver becomes active if no disc has been loaded for
3 minutes, or if the appliance has been in STOP mode for 3 minutes.
Using the GOTO function
The GOTO function can be used to select a specic starting point on a DVD
or CD.
● Press the GOTO button (21).
● Press the arrow buttons (14) to select an entry.
The possible entries for DVD are:
Disc time -
Chapter -
Title -
Chapter time -
Title time -
The possible entries for CD are:
Track time -
Specic track -
● Press the digit buttons (9) to set a selection.
Altri manuali per AD66U
1
Indice
Altri manuali Akai Lettore DVD
Akai
Akai A51005 Manuale utente
Akai
Akai AMD315 - Microset Manuale utente
Akai
Akai DV-PS7830 Manuale utente
Akai
Akai DV-P4930KDSM Manuale utente
Akai
Akai AKDVD7 Manuale utente
Akai
Akai A-4191 Manuale utente
Akai
Akai A-211 Manuale utente
Akai
Akai DV-P4330S Manuale utente
Akai
Akai DV-P4799KDMC Manuale utente
Akai
Akai DV-P4780KDSM Manuale utente
Akai
Akai DVP4785KDSM Manuale utente
Akai
Akai AD 70H Manuale utente
Akai
Akai DV-PX7830 Manuale utente
Akai
Akai AKD-250U Manuale utente
Akai
Akai DV-P4575SDK Manuale utente
Akai
Akai DV-P4925KDSM Manuale utente
Akai
Akai STD-2001 Manuale utente
Akai
Akai DV-P2340 Manuale utente
Akai
Akai DVD-2280 Manuale utente
Akai
Akai AKH-100XS Manuale utente
