Aktakom ACM-2353 Manuale utente
USER MANUAL
Clamp Meters
ACM-2353
www.tmatlantic.com
Overview
This Operating Manual covers information on
safety and cautions. Please read the relevant
information carefully and observe all the Warnings
and Notes strictly.
Warning
To avoid electric shock or personal injury, read the
“Safety Information” and “Rules for Safe
Operation” carefully before using the Meter.
This clamp is a three phase intelligent handheld
digital power clamp meter (hereafter referred to as “the
Meter”) which has both the features of digital current
meter and also power measurement meter.
The Meter can measure Voltage, Current, Active
Power, Apparent Power, Reactive Power, Power
Factor, Phase Angle, Frequency, Active Energy and
etc.
1
2
Unpacking Inspection
Open the package case and take out the Meter. Check
the following items carefully to see any missing or
damaged part:
Item Description Qty
1 English Operating
Manual 1 piece
2 Red Test Lead 3 piece
3 Black Test Lead 1 piece
4 Red Alligator Clip 3 piece
5 Black Alligator
Clip 1 piece
6 USB Interface
Cable 1 piece
7 Software 1 piece
8 Tool Box 1 piece
9 9V Battery 1 piece
In the event you find any missing or damage, please
contact your dealer immediately.
Safety Information
This Meter complies with the standards IEC61010: in
pollution degree 2, overvoltage category (CAT. III
600V, CAT IV 300V) and double insulation.
CAT. III: Distribution level, fixed installation, with
smaller transient overvoltages than CAT. IV CAT.IV:
Primary supply level, overhead lines, cable systems
etc.
Use the Meter only as specified in this operating
manual, otherwise the protection provided by the
Meter may be impaired.
In this manual, a Warning identifies conditions and
actions that pose hazards to the user, or may damage
the Meter or the equipment under test.
A Note identifies the information that user should pay
attention to.
Rules For Safe Operation
Warning
To avoid possible electric shock or personal injury,
and to avoid possible damage to the Meter or to the
equipment under test, adhere to the following rules:
zBefore using the Meter inspect the case. Do not
use the Meter if it is damaged or the case (or part of
3
4
the case) is removed. Look for cracks or missing
plastic. Pay attention to the insulation around the
connectors.
zInspect the test leads for damaged insulation or
exposed metal. Replace damaged test leads with
identical model number or electrical specifications
before using the Meter.
z Do not apply more that the rated voltage, as
marked on the Meter.
z When measurement has been completed,
disconnect the connection between the test leads and
the circuit under test, remove the
esting leads away from the input terminals of the Meter
and turn the Meter power off.
zDo not carry out the measurement when the
Meter’s back case and / or battery door is opened to
avoid electric shock.
zWhen the Meter working at an effective voltage
over 30V in AC, special care should be taken.
zUse the proper terminals and functionyou're your
measurements.
zDo not use or store the Meter in an environment of
high temperature, humidity, explosive, inflammable
and strong magnetic field. The performance of the
Meter may deteriorate after dampened.
zDo not use the Meter if the surface of it is wet or
the user’s hands are wet.
zWhen using the test leads, keep your fingers
behind the finger guards.
zReplace the battery as soon as the battery
indicator appears. With a low battery, the Meter
might produce false readings that can lead to electric
shock and personal injury.
zWhen opening the battery door, must make sure
the Meter is power off.
zWhen servicing the Meter, use only the same
model number or identical electrical specifications
replacement parts.
zThe internal circuit of the Meter shall not be altered
at will to avoid damage of the Meter and any accident.
zSoft cloth and mild detergent should be used to
clean the surface of the Meter when servicing. No
abrasive and solvent should be used to prevent the
surface of the Meter from corrosion, damage and
accident.
zThe Meter is suitable for indoor use.
zTurn the Meter off when it is not in use and take
out the battery when not using for a long time.
zConstantly check the battery as it may leak when it
has been using for some time, replace the battery as
soon as leaking appears. A leaking battery will
damage the Meter.
5
The Meter Structure
A. The Meter Front Structure (see figure 1)
6
Red Blue Yellow Black
Figure 1
7
1
Transformer Jaw: designed to pick up the AC
and DC current flowing through the conductor.
It could transfer current to voltage. The tested
conductor must vertically go through the Jaw
center.
2 Hand Guards: to protect user’s hand from
touching the dangerous area.
3 MR button (recall data)
4 SEL / button (press to select phase and sum
of Watts measurement)
5 MAXMIN / button
6 SAVE button (data store button)
7 LCD Display
8 L2 Input Terminal(Second phase
measurement)
9 L3 Input Terminal (Third phase measurement)
10 COM Input Terminal
11 L1 Input Terminal (First phase measurement)
12 USB button
13 CLEAR button
14 LIGHT button (auto display backlight button)
15 button (Sum)
16 HOLD button
17 Rotary function switch
18 NCV indicate lamp
B. The Meter Back and Bottom Structure
(see figure 2)
Figure 2
8
1 Infrared slot
2 USB Interface Cable
FUNCTION
Below table indicated for information about the
functional button operations.
Button Operation Performed
HOLD
zPress HOLD to enter the Hold
mode any mode, appears and the
Meter beeps.
zPress HOLD again to exit the Hold
mode to return to measurement mode,
the Meter beeps and, disappears.
Press the backlight button when
needed. Auto shut-down backlight after
lighting 20secs.Press the button again,
turn the backlight off manually
zAt Active power (main display) +
Phase angle (secondary display)
mode, press once button to sum up
the current phase of 3 phase
9
