Alcatel-Lucent OmniSwitch 6800 Series Manuale utente

OmniSwitch®6800 Series

Getting Started Guide

060195-10, Rev.D

June 2007

Warning. Only personnel knowledgeable in basic electrical and mechanical procedures should install or maintain this

equipment.

Lithium Batteries Caution. There is a danger of explosion if the Lithium battery in your chassis is incorrectly replaced.

Replace the battery only with the same or equivalent type of battery recommended by the manufacturer. Dispose of used

batteries according to the manufacturer’s instructions. The manufacturer’s instructions are as follows:

The features and specifications described in this guide are subject to change without notice.

the express written permission of Alcatel-Lucent.

Alcatel-Lucent®and the Alcatel-Lucent logo are registered trademarks of Alcatel-Lucent. Xylan®, OmniSwitch®,

OmniStack®, and Alcatel-Lucent OmniVista®are registered trademarks of Alcatel-Lucent.

OmniAccess™, Omni Switch/Router™, PolicyView™, RouterView™, SwitchManager™, VoiceView™, WebView™,

X-Cell™, X-Vision™, and the Xylan logo are trademarks of Alcatel-Lucent.

This OmniSwitch product contains components which may be covered by one or more of the following U.S. Patents:

• U.S. Patent No. 6,339,830

• U.S. Patent No. 6,070,243

• U.S. Patent No. 6,061,368

• U.S. Patent No. 5,394,402

• U.S. Patent No. 6,047,024

• U.S. Patent No. 6,314,106

• U.S. Patent No. 6,542,507

Return the module with the Lithium battery to Alcatel-Lucent. The Lithium

battery will be replaced at Alcatel-Lucent’s factory.

Alcatel-Lucent

26801 West Agoura Road

Calabasas, CA 91301

(818) 880-3500 FAX (818) 880-3505

US Customer Support: (800) 995-2696

International Customer Support: (818) 878-4507

Internet: service.esd.alcatel-lucent.com

June 2007 iii

OmniSwitch 6800 Series. . . . . . . . . . . . . . 1

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installing the Hardware . . . . . . . . . . . . . . . 3

Items Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Environmental Requirements . . . . . . . . . . . . . . . 3

Electrical Requirements . . . . . . . . . . . . . . . . . . . 3

Weight Considerations . . . . . . . . . . . . . . . . . . . . 3

Items Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Unpacking and Initial Setup . . . . . . . . . . . . . . . . . . . 4

Unpacking the Chassis . . . . . . . . . . . . . . . . . . . . 4

Recommendations . . . . . . . . . . . . . . . . . . . . 4

Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 4

Setting Up the Switch . . . . . . . . . . . . . . . . . . . . . . . . 5

Airflow Considerations . . . . . . . . . . . . . . . . . . . . 5

Installation Options . . . . . . . . . . . . . . . . . . . . . . . 6

Installing the Switch on a Tabletop or Bench . . . 6

Tabletop Mounting Steps . . . . . . . . . . . . . . . 6

Rack-Mounting the Switch . . . . . . . . . . . . . . . . . 7

Rack Mounting Steps . . . . . . . . . . . . . . . . . . 7

Installing Combo Port SFPs . . . . . . . . . . . . . . . . . . . 9

Installing Backup Power Supply Components . . . . . 9

Connections and Cabling . . . . . . . . . . . . . 10

Connecting the Serial Cable . . . . . . . . . . . . . . . . . . 10

Serial Connection Default Settings . . . . . . . . . . . . . 10

Booting OmniSwitch 6800 Series

Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Booting a Standalone Switch . . . . . . . . . . . . . . . . . 11

Your First Login Session . . . . . . . . . . . . . . . 12

Logging In to the Switch . . . . . . . . . . . . . . . . . . . . . 12

Assigning an IP Address to the Switch . . . . . . . . . . 13

Unlocking Session Types . . . . . . . . . . . . . . . . . . . . 14

Changing the Login Password . . . . . . . . . . . . . . . . 15

Setting the System Time Zone . . . . . . . . . . . . . . . . 15

Setting the Date and Time . . . . . . . . . . . . . . . . . . . . 16

Setting Optional System Information . . . . . . . . . . . 16

Specifying an Administrative Contact . . . . . . .16

Specifying a System Name . . . . . . . . . . . . . . . .17

Specifying the Switch’s Location . . . . . . . . . . .17

Viewing and Saving Changes . . . . . . . . . . . . . . . . . 17

Table of Contents

iv June 2007

Files and Directories. . . . . . . . . . . . . . . . . . . . 18

Boot and Image Files . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

boot.params File . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

boot.cfg File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

boot.slot.cfg File . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Image Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Working and Certified Directories . . . . . . . . . . . . . . . . 20

Working Directory . . . . . . . . . . . . . . . . . . . . . . 20

Certified Directory . . . . . . . . . . . . . . . . . . . . . . 21

Using WebView . . . . . . . . . . . . . . . . . . . . . . . . . 24

Browser Compatibility . . . . . . . . . . . . . . . . . . . . . . 24

Logging In to WebView . . . . . . . . . . . . . . . . . . . . . 24

Navigating WebView . . . . . . . . . . . . . . . . . . . . . . . 25

Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Additional Information . . . . . . . . . . . . . . . . . . . . . . 27

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

June 2007 OmniSwitch 6800 Series 1

OmniSwitch 6800 Series

The OmniSwitch 6800 Series is an advanced fixed

configuration family of Ethernet switches. These switches

provide wire rate Layer 2 forwarding and Layer 3 routing with

advanced services.

They are fixed configuration, triple-speed (10/100/1000)

switches that provide increased network performance,

improved application response times, secure the LAN, and

enhance user productivity by maximizing mobility, network

capacity, and services over existing category 5/5E/6 cabling.

Refer to the User Manual CD for additional hardware and

software OmniSwitch documentation.

OmniSwitch6800-48L

PWR

FANTMP

BPS

PRI

4547

4648

Console

47LINK/ACT

48LINK/ACT

XFP1XFP2

Speed1

Speed2

OmniSwitch6800-24L

PWR

FANTMP

BPS

PRI

2123

2224

Console

23LINK/ACT

24LINK/ACT

Speed2

Speed1

OmniSwitch6800-U24

PWR

FAN TMP

BPS

XFP1 XFP2

Console

Speed LNK/ACT

CLASS1LASER PRODUCT

13573

2468

911 13 15 11

10 12

13 15

14 16

10 12 14 16

17 19 21 23

18 20 22

18 20 22 24

21 22 23 24

OmniSwitch6800-48

PWR

FAN TMP

BPS

PRI

4547

46 48

Console

47LINK/ACT

48LINK/ACT

XFP1 XFP2 28 30 32

Speed1

Speed2

OmniSwitch6800-24

PWR

FAN TMP

BPS

PRI

21 23

22 24

Console

23LINK/ACT

24LINK/ACT

Speed 2

Speed1

OmniSwitch 6800-24

OmniSwitch 6800-U24

OmniSwitch 6800-48

OmniSwitch 6800-24L

OmniSwitch 6800-48L

2 OmniSwitch 6800 Series June 2007

Related Documentation

The following are the titles and descriptions of all the

OmniSwitch 6800 Series user documentation included in the

User Manual CD:

•OmniSwitch 6800 Series Getting Started Guide

Describes the hardware and software procedures for

getting an OmniSwitch 6800 Series switch up and

running. Also provides information on fundamental

aspects of OmniSwitch hardware components and

software architecture.

•OmniSwitch 6800 Series Hardware Users Guide

Complete technical specifications and procedures for

all OmniSwitch 6800 Series hardware, including chas-

sis, power supplies, fans, combo ports, stacking

procedures, optional backup power supplies, etc.

•OmniSwitch CLI Reference Guide

Complete reference to all CLI commands supported on

the OmniSwitch 6800 Series. Includes syntax defini-

tions, default values, examples, usage guidelines, and

CLI-to-MIB variable mappings.

•OmniSwitch 6800/6850/9000 Switch Management

Guide

Includes procedures for readying a switch for

integration into a network. Topics include the software

directory architecture, image rollback protections,

authenticated switch access, managing switch files,

system configuration, using SNMP, and using web

management software (WebView).

•OmniSwitch 6800/6850/9000 Network Configuration

Guide

Includes network configuration procedures and

descriptive information on all the major software

features and protocols included in the base software

package. Chapters cover Layer 2 information (Ether-

net and VLAN configuration), Layer 3 information

(static routes), security options (authenticated

VLANs), Quality of Service (QoS), and link

aggregation.

•OmniSwitch 6800/6850/9000 Advanced Routing

Configuration Guide

Includes network configuration procedures and

descriptive information on all the software features and

protocols included in the advanced routing software

package. Chapters cover multicast routing (DVMRP

and PIM-SM) and OSPF.

•OmniSwitch Transceivers Guide

Includes information on Small Form Factor Pluggable

(SFPs) and 10 Gbps Small Form Factor Pluggables

(XFPs) transceivers.

June 2007 Installing the Hardware 3

Items Required

In addition to the materials and components provided in the

OmniSwitch 6800 Series shipment, you must provide the

following items in order to complete this installation:

•Grounding wrist strap

•Phillips screwdriver

•Serial cable

•Rack mount screws, if applicable

Site Preparation

Environmental Requirements

OmniSwitch 6800 Series switches have the following environ-

mental and airflow requirements:

•The installation site must maintain a temperature

between 0° and 45° Celsius (32° and 122° Fahrenheit)

and not exceed 95 percent maximum humidity (non-

condensing) at any time.

•Be sure to allow adequate room for proper air ventila-

tion and access at the front, back, and sides of the

switch. No clearance is necessary at the top or bottom

of the chassis. Refer to page 5 for minimum clearance

requirements.

Electrical Requirements

OmniSwitch 6800 Series switches have the following general

electrical requirements:

•Each switch requires one grounded AC power source.

•Grounded AC power source must be 110V for North

American installations (220V international).

•Each supplied AC power cord is approximately 2

meters (6.5 feet) long. Do not use extension cords.

Weight Considerations

A single OS6800 weighs approximately 14 lbs.

(6.30 Kg). A stack of eight OS6800 switches weighs

approximately 111 lbs (50.4 Kgs).

Installing the Hardware

4 Installing the Hardware June 2007

Items Included

Your OmniSwitch 6800 Series switch order includes the

following items:

•OmniSwitch chassis

•Rack mount flanges with attachment screws (rack

mount flanges may be pre-installed on some orders)

•Power cord (country-specific)

•Documentation CD containing a complete set of user

guides for the switch and switch software. Refer to

“Related Documentation” on page 2 for a complete list of

included documentation.

Depending on the items ordered for your specific network

requirements, the following optional items may also be

included:

•Stacking cables (per order)

•SFPs (per order)

•10 Gigabit XFP connectors (per order)

•Backup power supply components and cables

(per order)

Unpacking and Initial Setup

Unpacking the Chassis

To protect your OmniSwitch chassis and hardware compo-

nents from electrostatic discharge (ESD) and physical damage,

read all unpacking recommendations and instructions care-

fully before beginning.

Recommendations

•Unpack your OmniSwitch chassis as close as possible

to the location where it will be installed.

•Depending on your order, Small Form-Factor Plugga-

bles (SFPs), stacking cables, and backup power supply

components may be packaged separately. In order to

greatly reduce exposure to electrostatic discharge

(ESD) and physical damage, do not unpack these items

until they are ready to be installed.

Instructions

1Carefully cut the tape along the seam at the top of the

box containing the chassis.

2Lift the box’s top flaps. Remove any smaller boxes or

pouches that are enclosed and set them aside.

3Lift the chassis out of the packaging.

4Carefully remove any foam pads and protective plastic

from the switch chassis.

June 2007 Installing the Hardware 5

Note. Alcatel-Lucent provides factory-installed blank

cover plates for empty backup power supply or 10 Giga-

bit expansion module bays. Do not remove these cover

plates unless a backup power supply or expansion module

is to be installed immediately at the corresponding bay.

5If you are installing multiple switches in a stacked

configuration, repeat steps 1 through 4 for the remaining

switches that will make up the stack.

6Once all OmniSwitch 6800 Series switches have been

removed from their packaging, continue to “Setting Up

the Switch.”

Setting Up the Switch

Note. Due to their airflow and access requirements,

OmniSwitch 6800 Series switches cannot be wall-

mounted.

Airflow Considerations

Be sure that your switch is placed in a well-ventilated, static-

free environment. Always allow adequate clearance at the

front, rear, and sides of the switch.

The following diagram shows recommended minimum clear-

ances for adequate chassis airflow and access to components at

the rear of the chassis:

PWR

FANTMP

BPS

PRI

2123

2224

Console

23LINK/ACT

24LINK/ACT

Speed2

Speed1

Rear. 5 inches minimum

at rear of chassis.

Front. 6 inches minimum

at front of chassis for

cable access and LED

visibility.

Sides. 2 inches minimum

at left and right sides for

chassis airflow.

Chassis Top View

6 Installing the Hardware June 2007

Never obstruct the air vents located at the left and right sides

of the chassis.

Note. Clearance is not required at the top and bottom of

the chassis. For detailed chassis airflow diagrams, refer to

the OmniSwitch 6800 Series Hardware Users Guide.

Installation Options

There are two ways in which the OmniSwitch 6800 Series

switches can be installed:

•Tabletop installation

•Rack-mount installation

For information on setting up a switch as a tabletop unit, refer

to “Installing the Switch on a Tabletop or Bench.” For infor-

mation on rack-mounting the switch, refer to

“Rack-Mounting the Switch” on page 7.

Installing the Switch on a Tabletop or

Bench

OmniSwitch 6800 Series switches can be installed freestand-

ing as tabletop units. Place your switch in a stable, flat, static-

free surface.

Note. OmniSwitch 6800 Series switches must be placed

“right side up.” Never attempt to operate a switch posi-

tioned on its side.

Tabletop Mounting Steps

To install the switch as a tabletop unit, follow the steps below:

1Position the chassis on the table or bench where it is to

be installed.

2Be sure that adequate clearance has been provided for

chassis airflow and access to the front, back, and sides of

the switch. For recommended clearances, refer to page 5.

Also, be sure that you have placed the chassis within reach

of all required AC power sources.

If you are placing multiple switches in a stacked configu-

ration, carefully stack the remaining switches, one on top

of the other. Up to eight switches may be stacked to form

a single virtual chassis. Be sure to maintain adequate

clearance at the front, rear, left, and right side of all

switches (see page 5). Also, be sure that you have placed

all switches in the stack within reach of required AC

power sources.

Note. If you are installing a single (i.e., standalone)

switch, continue to “Connections and Cabling” on page 10

for additional setup procedures.

Altri manuali per OmniSwitch 6800 Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Alcatel-Lucent Interruttore

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6800 Series Manuale di programmazione

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6800 Series Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 9000 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS E OS Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6855 Series Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6450-P10S Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent OmniAccess 4504 Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6350 Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent 7210 SAS D Manuale utente

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-320 Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6560 Series Manuale di installazione

Alcatel-Lucent

Alcatel-Lucent 1675 LambdaUnite Guida utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS D Manuale utente

Alcatel-Lucent

Alcatel-Lucent 1850 Guida utente

Alcatel-Lucent

Alcatel-Lucent 7250 SAS Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7210 SAS-D Foglio di istruzioni

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6250 Manuale utente

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Manuale di programmazione

Alcatel-Lucent

Alcatel-Lucent OmniSwitch 6850-48 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 1850 TSS-60 Guida utente

Alcatel-Lucent

Alcatel-Lucent 4306 Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuale utente
