SpeedTouch™
570/570i
Wireless ADSL Routers
Setup and User’s Guide
500
SERIES
3EC 17766 BAAA TCZZA Ed. 01
SpeedTouch™ 570
Setup and User’s Guide
3EC 17766 BAAA TCZZA Ed. 01
Status Released
Change Note PeckelbeenS
Short Title CD-UG ST570 R2.0
Copyright © 2002 THOMSON multimedia. All rights reserved. Passing on, and copying of this docu-
ment, use and communication of its contents is not permitted without written authorization
from THOMSON multimedia. The content of this document is furnished for informational
use only, may be subject to change without notice, and should not be construed as a commit-
ment by THOMSON multimedia. THOMSON multimedia assumes no responsibility or
liability for any errors or inaccuracies that may appear in this document.
3EC 17766 BAAA TCZZA Ed. 01 5
Contents
1 SpeedTouch™570 Installation ...................................... 7
1.1 Getting Acquainted with the SpeedTouch™570.............................................. 8
1.2 Preparing the SpeedTouch™570 ..................................................................... 10
1.3 Wireless Connectivity ....................................................................................... 13
1.3.1. First-time Wireless Client Connectivity ...................................................................................15
1.3.2. Connecting other Wireless Clients ...........................................................................................16
1.4 SpeedTouch™570 Configuration Setup .......................................................... 18
1.4.1. Configuration Setup for MS Windows OSs ............................................................................. 19
1.4.2. Configuration Setup for other OSs ............................................................................................24
1.5 SpeedTouch™570 Internet Connectivity........................................................ 26
2 SpeedTouch™570 Web Interface .............................. 29
2.1 System Tasks ...................................................................................................... 32
2.2 Other Places Tasks ............................................................................................ 36
3 Troubleshooting and Specifications ........................... 43
3EC 17766 BAAA TCZZA Ed. 01
6
1 SpeedTouch™570 Installation
3EC 17766 BAAA TCZZA Ed. 01 7
1 SpeedTouch™570 Installation
Introduction Thank you for purchasing the SpeedTouch™570 Wireless ADSL router!
With the SpeedTouch™570 two cutting-edge technologies are combined: ADSL and
the Wireless LAN (WLAN). With this answer to the increasing popularity of both tech-
nologies, users can connect to your (Wireless) network and surf the Internet at high
speed without the need for any expensive wiring installation.
In this Setup and User's
Guide
This Setup and User's Guide will assist you in getting acquainted with the Speed-
Touch™570 and quickly connecting wired and wireless users to the Internet.
Terminology For readability, both the SpeedTouch™570 and SpeedTouch™570i will be referred to as
SpeedTouch™570 in this Setup and User's Guide.
Quick installation and
Safety instructions
Prior to connecting the SpeedTouch™570 , read the SpeedTouch™ Quick Installation
Guide and Safety instructions.
Documentation and
software updates
Due to the continuous evolution of DSL technology, existing products are regularly
upgraded.
For more information on the newest technological breakthroughs, software upgrades
and documents, please consult the SpeedTouch™ web sites at:
•http://www.speedtouch.com
3EC 17766 BAAA TCZZA Ed. 01
1 SpeedTouch™570 Installation
8
1.1 Getting Acquainted with the SpeedTouch™570
Introducing the
SpeedTouch™
Prior to proceeding, please make sure to read first the SpeedTouch™ Quick Installation
Guide . It provides important package content and safety information.
Check whether all items are present in your package.
In the event of damaged or missing items, please contact your local product dealer for
more information.
The SpeedTouch™570 You SpeedTouch™ is presented in a slim line box:
SpeedTouch™ LEDs The SpeedTouch™570 is equipped with 5 LEDs on its front panel, indicating the state of
the device during operation:
Indicator Description
Name Color State
LAN Green Flashing Wireless LAN traffic activity
Off No Wireless LAN activity
Line TX Green Flashing Cell transmission on DSL line
Off No transmission activity
Line RX Green Flashing Cell reception from DSL line
Off No reception activity
Line Sync Green Flashing Initialization of DSL line
On DSL line synchronized
PWR/Alarm Green On Power on, normal operation
Amber Flashing WLAN client registration
1 SpeedTouch™570 Installation
3EC 17766 BAAA TCZZA Ed. 01 9
SpeedTouch™570 back
panel layout
Ethernet port LED
functionality
The Ethernet port on the rear panel has two LEDs:
A Power button D Defaults button
B Power inlet E 10/100Base-T Ethernet port
C WLAN Registration button F DSL line port
BACDE F
Indicator Description
Name LED
Status
A 10/100Base-T Off 10Base-T Ethernet connection.
Solid 100Base-T Ethernet connection.
BIntegrity
Activity
Off No connection on this port.
Solid Ethernet link up.
Flashing Data is flowing from/to this port.
BA
3EC 17766 BAAA TCZZA Ed. 01
1 SpeedTouch™570 Installation
10
1.2 Preparing the SpeedTouch™570
Wall fixing assembly Part of the package is a wall mounting assembly which allows you to conveniently mount
the SpeedTouch™570 on a wall.
Before you start, check for the following items:
•The wall fixing assembly
•2 screws and 2 wall plugs
•1 Velcro sticker.
To prepare the wall fixing assembly and the SpeedTouch™570 , proceed as follows:
Step Action
1Mark two hole horizontal positions, 134 mm (5.36 inches) apart:
2Drill the marked holes with a 6mm (0.24 inches) diameter drill bit to a
minimum depth of 35mm (1.38 inches).
3Insert the wall plugs in the drilled holes, position the wall fixing assembly over
the holes, insert the screws in the wall plugs and tighten them firmly:
4Place the Velcro sticker on the wall fixing assembly in the marked area.
