ALIENWARE® M11x

COMPREHENSIVE SPECIFICATIONS

The contents herein are subject to change without notice.

Reproduction of these materials in any manner whatsoever without the prior written permission of Dell Inc. is

strictly prohibited.

Trademarks used in this manual: Alienware is a trademark or registered trademarks of Alienware Corporation.;

Dell is a trademark of Dell Inc.; Intel and Pentium are the registered trademarks and Core is a trademark of Intel

Corporation in the U.S. and other countries.; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc.

Other trademarks and trade names may be used in this manual to refer to either the entities claiming the marks

and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other

than its own.

Model: P06T Type: P06T001/P06T002 Rev. A00 February 2010

COMPREHENSIVE SPECIFICATIONS

Computer Model

Alienware M11x

Dimensions

Height (Front and Back) 32.7 mm (1.29 inches)

Width 285.7 mm (11.25 inches)

Depth 233.3 mm (9.19 inches)

Weight with 8-cell battery

(starting at)

1.99 kg (4.39 lb)

NOTE: e weight of your laptop will vary depending

on the conguration ordered and the manufacturing

variability.

COMPREHENSIVE SPECIFICATIONS

Processor and System Chipset

Processor Intel Pentium™ Dual Core

Intel®Core™2 Duo

L2 cache

Intel Pentium Dual Core

Intel Core2 Duo

2 MB

3 MB

Bus clock 200 MHz

System chipset Intel GS45

SDRAM bus width one or two 64-bit channels of DDR3 memory up to

800 MHz

Processor address bus width 32 bits

Processor data width 64 bits

BIOS EPROM 16 Mbit

Graphics bus PCIe x16 bus

PCI bus 32 bits

COMPREHENSIVE SPECIFICATIONS

Memory

Connectors two internally-accessible DDR3 SODIMM sockets

Capacities 1 GB, 2 GB, and 4 GB

Memory type 800 MHz (dual-channel congurations)

Memory congurations

possible

2 GB, 4 GB, and 8 GB

IEEE 1394 A

IEEE 1394A controller JMicron JMB380

IEEE 1394 interface compliant with standard IEE1394a-2000 specication

Ports and Connectors

Network adapter one RJ45 connector

USB three 4-pin USB 2.0-compliant connectors, including

one USB PowerShare connector

VGA one 15-hole connector

HDMI one 19-pin connector

COMPREHENSIVE SPECIFICATIONS

Ports and Connectors

DisplayPort one 20-pin connector

Audio two audio output/headphone connectors and one audio

input/microphone connector

3-in-1 Media Card Reader one combo connector

SIM card one SIM card slot

IEEE 1394 one 4-pin serial connector

Communications

Network adapter 10/100 Mbps Ethernet LAN on system board

Wireless WLAN Mini-Card (half Mini-Card slot)•

WWAN Mini-Card (full Mini-Card slot) (optional)•

integrated Bluetooth• ®module (optional)

COMPREHENSIVE SPECIFICATIONS

Video

Video controller integrated on

the system board

Discrete video controller

Intel GS45

Nvidia NV11P-GS1

Video memory

Intel GS45

Nvidia NV11P-GS1

dynamic based on system memory capacity

1 GB

External display support VGA, HDMI, and DisplayPort

Audio

Controller Realtek ALC665

Speaker single 8-ohms speakers in both the left and right speaker

assembly

Internal speaker amplier up to 1 W per channel; up to 2 W total power

Internal microphone support single digital microphone in camera assembly

Volume controls program menus and media keyboard function keys

COMPREHENSIVE SPECIFICATIONS

Hard-Drive Storage

Interface SATA

Number of hard drives one

Hard drive 2.5 inch SATA hard drive

Type standard portable and solid-state hard-drives

Cards Supported

Media cards Secure Digital (SD) memory card•

MultiMedia Card (MMC)•

Memory Stick PRO•

Video cards Intel Graphics Media Accelerator 4500MHD•

(Integrated on system board)

Nvidia GeForce GT 335M (Discrete)•

COMPREHENSIVE SPECIFICATIONS

Display

Type (WLED) 11.6 inch HD+ TrueLife

Maximum resolution 1366 x 768

Dimensions

Height 144 mm (5.67 inches)

Width 256.12 mm (10.08 inches)

Diagonal 293.83 mm (11.57 inches)

Refresh rate 60 Hz

Operating angle 0° (closed) to 140°

Pixel pitch 0.2550 mm

Controls brightness can be controlled through keyboard

shortcuts
