Alienware ANW15-7493SLV-REFA Manuale utente
Views
Specifications
Alienware 15
Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. DellTM and the Dell logo are trademarks of Dell Inc. in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
2014 ‑ 12 Rev. A00
Regulatory model: P42F | Type: P42F001
Computer model: Alienware 15
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
1 Power-adapter port
Connect a power adapter to provide power to your
computer and charge the battery.
2 Security-cable slot
Connect a security cable to prevent unauthorized
movement of your computer.
3 USB 3.0 port with PowerShare
Connect peripherals such as storage devices, printers, and
so on. Provides data transfer speeds up to 5 Gbps.
PowerShare allows you to charge your USB devices even
when your computer is turned off.
NOTE: If your computer is turned off or in hibernate
state, you must connect the power adapter to charge
your devices using the PowerShare port. You must
enable this feature in the BIOS setup program.
NOTE: Certain USB devices may not charge when
the computer is turned off or in sleep state. In such
cases, turn on the computer to charge the device.
4 USB 3.0 port
Connect peripherals such as storage devices, printers, and
so on. Provides data transfer speeds up to 5 Gbps.
5 Microphone/Headphone port
Connect an external microphone to provide sound input
or connect a headphone or speakers.
6 Headset port
Connect a headphone, a microphone, or a headphone and
microphone combo (headset).
12 3 4 5 6
Views
Specifications
Back
Left
Right
Base
Display
Left
1 Media-card reader
Reads from and writes to media cards.
2 USB 3.0 ports (2)
Connect peripherals such as storage devices, printers, and
so on. Provide data transfer speeds up to 5 Gbps.
3 Network port
Connect an Ethernet (RJ45) cable from a router or a
broadband modem for network or internet access.
The two lights next to the connector indicate the
connectivity status and network activity.
12 3
Views
Specifications
Back
Left
Right
Base
Display
Right
1 Power button with power-status light
Press to turn on the computer if it is turned off or in sleep
state.
Press to put the computer in sleep state if it is turned on.
Press and hold for 4 seconds to force shut‑down the
computer.
Solid white light indicates the computer in on and
breathing white light indicates the computer is in sleep
state. The light is off when the computer is in hibernate
state or turned off.
NOTE: You can customize the power‑button
behaviour in Power Options. For more information,
see Me and My Dell at dell.com/support/manuals.
2 Caps-lock status light
Turns on when caps‑lock is turned on.
3 Wireless-status light
Turns on when wireless is turned on.
4 Hard-drive activity light
Turns on when the computer reads from or writes to the
hard drive.
5 Left-click button
Press to left‑click.
6 Touch pad
Move your finger on the touch pad to move the mouse
pointer. Tap to left‑click.
7 Right-click button
Press to right‑click.
3
5 6 7
21
4
Views
Specifications
Back
Left
Right
Base
Display
Base
1 Left digital-array microphone
Provides high‑quality digital sound input for audio
recording, voice calls, and so on.
2 Camera
Allows you to video chat, capture photos, and record
videos.
3 Camera-status light
Turns on when the camera is in use.
4 Right digital-array microphone
Provides high‑quality digital sound input for audio
recording, voice calls, and so on.
2
134
Views
Specifications
Back
Left
Right
Base
Display
Display
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touch Pad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media-Card
Reader Keyboard
Dimensions and Weight
Height 34 mm (1.33 in)
Width 386 mm (15.19 in)
Depth 270 mm (10.62 in)
Weight (maximum):
Full HD (non‑touch screen) 3.22 kg (7.10 lb)
Ultra HD (touch screen) 3.39 kg (7.48 lb)
NOTE: The weight of your laptop varies depending on the configuration ordered and
the manufacturing variability.
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touch Pad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media-Card
Reader Keyboard
System Information
Computer model Alienware 15
Processor • 4th Generation Intel Core i5
• 4th Generation Intel Core i7
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touch Pad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media-Card
Reader Keyboard
Memory
Slot Two SODIMM slots
Type DDR3L
Speed 1600 MHz
Configurations supported 8 GB, 12 GB, and 16 GB
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touch Pad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media-Card
Reader Keyboard
Ports and Connectors
External:
Network One RJ45 port
USB • One USB 3.0 port with PowerShare
• Three USB 3.0 ports
Audio/video • One HDMI port
• One headphone and microphone combo (headset) port
• One microphone/headphone port
• One External Graphics Port
• One Mini DisplayPort
Internal:
M.2 card One M.2‑card slot for Wi‑Fi, Bluetooth, and Intel WiDi (optional)
