ALK Nokia N70 Manuale utente

Quickstart Guide

Satellite Navigation

for Nokia N70

CoPilot Live. Local knowledge, everywhere

www.alk.eu.com

symbian booklet 050406_new 5/4/06 12:04 Page 1

CoPilot Satellite Navigation Kit

CoPilot Satellite Navigation Kit for Nokia N70

Your CoPilot kit contains the following:

*Only included in CoPilot Bluetooth kits.

RS-MMC memory

cardpre-loaded

with maps

1xinstallation CD

2 x data CDs

Product

key card

QuickstartGuide

Satellite Navigation

for Nokia N70

CoPilot Live. Local knowledge, everywhere

Bluetooth

receiver*

Car charger*

and car mount*

Quickstart

guide

CoPilot Satellite Navigation Kit

iCoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

CoPilot Customer Support Helpline

Call a member of our Customer Support team for professional

and friendly support on CoPilot.

Our helpline is open Monday to Friday between 09:00 and

17:00 hours.

Online Support

Please email [email protected] for answers to your

CoPilot support related queries and questions.

Alternatively, visit the support section at www.alk.eu.com

to register and activate your CoPilot.

Our FAQs section provides answers to customers’ most

frequent requests to help you get started and make the

most out of CoPilot today.

CoPilot Customer Support

Telephone +44 (0) 20 7404 4222

Customer Support

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 2

Getting Started 1

Keys and User Interface 2

Unique Product Key Code Entry 3

License Activation 4

Bluetooth GPS Receiver Set-up 5

CoPilot Welcome Menu 7

Navigating to a Destination 8

nEntering an Address 8

Navigating to a Point of Interest 9

nPOI Alerts 9

How to Change Driving Views 10

Navigation Modes 11

Advanced Routing Settings 12

Advanced Features 13

CoPilot Live Services 14

nLive Traffic 16

nLive Location Tracking 18

nLive Messaging 19

nLive Destination Sending 20

Trouble Shooting 21

Help 23

CoPilot Customer Support 24

Contents

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

Contents

CoPilot has a help function, which provides you with instructions

and information about setting up and using the software.

Select Welcome > Help (or Options > Help).

User Guide

Read the user guide to get familiar with CoPilot.

The user guide provides important safety information, detailed

instructions for setting up your CoPilot, comprehensive

information on downloading and transferring map data for

European, USA and Australian upgrades.

Learn how to use the advanced navigation features in CoPilot

and setup Live Communications to enjoy real time traffic, Live

tracking and messaging - plus much more.

Help

23 CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 3

Getting Started

1CoPilot Live 6 Symbian S60

Setting up your Nokia N70

Set up your Nokia N70 following the instructions supplied

with the phone's manual.

Please ensure your phone's battery is fully charged.

Set the correct date and time on your Nokia N70 for

optimum performance.

CoPilot Live Satellite Navigation on your Nokia N70

CoPilot is preloaded on the RS-MMC memory card.

To start using CoPilot Live on your Nokia N70, simply insert

the memorycardinto your phone.

Once the card is inserted, press the Menu key to open the

main menu of the Nokia N70.

Using the scroll key cursors, browse to ‘My Own’ and open

the folder.

The CoPilot icon will be displayed within the ‘My Own’ folder.

Highlight and select the ‘CoPilot’ icon to startCoPilot.

Getting Started

Customer Support Helpline

(+44 (0)207 404 4222

Trouble Shooting

QIam having trouble obtaining a GPS signal

If you can’t get a GPS signal after setting up your receiver,

ensure that your Bluetooth GPS receiver is switched on,

charged-up and working properly by switching off and on.

Green and blue lights will appear if the GPS receiver is fully

charged.

QCoPilot did not find the address that I entered

If a specific address is not within the CoPilot database, try

using the ‘Map’ option from the ‘Select Stop’ screen.

(This enables you to pin point anywhere on the map and

add it to your itinerary.)

Trouble Shooting

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 4

Nokia N70 Keys

Power key

Left selection key

Right selection key

5-way scroll key

Menu key

Clear key

Memorycardslot

CoPilot User Interface

Next turn arrow

Route ahead highlighted

Driver’s current position

Distance to next turn

Options menu

GPS status indicator

Live services indicator

Keys and User Interface

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

Trouble Shooting

21 CoPilot Live 6 Symbian S60

QIam experiencing problems switching on

Bluetooth

Close CoPilot by selecting ‘Exit’ from the menu.

Switch your phone off and then on again using the power

button.

RestartCoPilot and select Welcome > GPS > Options > Turn

On Bluetooth.

Q‘No devices found’ in search for GPS

Close CoPilot by selecting ‘Exit’ from the menu.

Ensurethat your Bluetooth GPS receiver is switched-on,

charged-up and working properly.

Please switch the GPS receiver off and on. Green and blue

lights will appear if the GPS receiver is fully charged and

working properly.

RestartCoPilot and select ‘GPS’ from the CoPilot Welcome

screen.

Press ‘Options’, and select ‘Search for GPS’.

Your Bluetooth receiver should appear with the name

BTGPS xxxx xxxx.

Trouble Shooting

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 5

Product Key Code

3CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

The first time you run CoPilot on your phone you will be

prompted to enter your product key.

Please scratch off the silver panel on your product key card to

reveal your unique product key code.

Carefully input your unique 25 digit product key code. Press

'Next'.

Unique Product Key Code Entry

Live Destination Sending

Send new destinations to the driver

People can even send new destinations to the driver from the

http://live.alk.eu.com website which the driver can either

accept or reject at the touch of a button.

If the driver accepts the new locations they are automatically

added straight into the driver’s itinerary.

If a new destination is rejected then the itinerary remains

unchanged and the driver continues as planned.

Live Destination Sending

Live website

Live destination sent to

driver’s Nokia N70

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 6

License Activation

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

You will need to activate

your CoPilot license within 3

days of installation.

Press ‘Options’ and select

one of the three activation

methods:

1. Automatic

Press ‘Next’.

Enter your email address

and press ‘Next’. CoPilot

will automatically connect

to the Internet using the

GPRS/3G capabilities of

the Nokia N70.

‘License activated success-

fully’ will be displayed,

press ‘Done’ and continue.

2. Manual

Using a PC/laptop

connected to the

Internet, visit

http://activate.alk.com

Type in your Product Key

and the License Number

displayed on-screen, then

enter your email address

and press ‘Submit’ to receive

your activation code.

Press ‘Next’. Enter the

activation code into your

phone and press ‘Done’.

‘License activated success-

fully’ will be displayed,

press ‘Done’ and continue.

3. Telephone

Please select your location

from the Menu.

Call the CoPilot Customer

Supportteam.

You will need to provide

your Product Key and the

License Number displayed

on-screen to receive your

activation code.

Enter the activation code

into your phone and press

‘Done’.

‘License activated success-

fully’ will be displayed,

press ‘Done’ and continue.

License Activation

Live Messaging

19 CoPilot Live 6 Symbian S60

Real-time messaging

People can also send messages to your phone while tracking

your location on a map from the http://live.alk.eu.com website.

Messages will appear on the driver’s Nokia N70’s screen.

Simple timed-out responses are displayed and allow the driver

to respond at the touch of a button to avoid driver distraction.

Live Messaging

Live website

Live Message on driver’s

Nokia N70

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 7

Bluetooth Set-up

Bluetooth GPS Receiver Set-up

CoPilot uses Global Positioning Satellites (GPS) to locate your

position on a map and to provide turn-by-turn guidance to a

destination.

It is essential that you pair the Bluetooth GPS receiver with

your phone to obtain a GPS fix so you can enjoy satellite

navigation on your Nokia N70.

Switch on your Bluetooth GPS receiver.

When prompted to switch on Bluetooth on your device,

choose ‘Yes’. Please check that Bluetooth is automatically

turned on.

Create a name for your phone. Press ‘OK’.

Press ‘Options’, and select ‘Search for GPS’. A list of

Bluetooth devices will be displayed. Select the Bluetooth

device starting with ‘BTGPS xxxxx’.

Check that a GPS Signal is Found. Press ‘Done’.

You arenow ready to enter a destination and start

navigating.

5CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

You can invite people to track your current location on a map

via the Internet in real-time.

Simply login to your CoPilot Live account. Select Live Setup >

Invites. In the Updating List screen, press Options > New.

In the New Invitation screen, please enter the name and email

address of the person you wish to invite to track your location.

Type in a message and press ‘Done’.

Aweb tracking email hyperlink will be sent to the person’s

PC/laptop, therefore enabling them to track your location

on a map and monitor your estimated time of arrival to a

destination.

Live Location Tracking

CoPilot Live 6 Symbian S60

Driver’s current

position

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 8

Bluetooth Set-up

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

GPS performance hints and tips

CoPilot uses the Bluetooth GPS receiver to enable you to obtain

aGPS fix for CoPilot to calculate your route and provide

navigation guidance.

The first time you use the GPS receiver it may take several

minutes to determine your position.

There is no GPS signal inside buildings, tunnels, garages, multi-

storey and basement car parks.

When using the GPS receiver for a journey, please ensure that

it is fully charged and mounted securely with a clear line of

sight to the sky e.g. by placing on a vehicle dashboard.

Scrolling GPS status indicator

Good GPS reception

Fair GPS reception

No GPS reception

Note: If you need to re-bond your Bluetooth receiver

with your Nokia N70, please select Welcome > GPS >

Options > Turn On Bluetooth.

You will then need to search for your Bluetooth device

by pressing Options > Search for GPS. Select the

Bluetooth device starting with BTGPS xxxxx. Press ‘Done’.

Traffic Incident Indicators

Press ‘9’ to see a list of all current incidents. In the Traffic

screen, highlight an incident and select Options > Details.

You can make an informed decision about whether you

would prefer to:

Ignore the alertand and continue to drive along your

planned route through the traffic congestion

Avoid the traffic incident by allowing CoPilot to automatically

re-route you around it.

*+Traffic availability subject to country and varies by region. An additional

traffic subscription may be required. Additonal costs can be incurred for

mobile data charges, prices will vary according to mobile network operator.

Live Traffic

Traffic

Jam

Accident Road

Construction

General

Incident

Weather

Live Traffic

17 CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 9

CoPilot Welcome Menu

Take a look at the CoPilot Welcome Screen

The Welcome screen is displayed, either when you first launch

CoPilot, or by selecting the Options left hand soft key > Help

>Welcome.

Once you are there, you’ll discover on-screen step by step

address entry for navigating to a destination; real-time traffic

information; Live location tracking and messaging plus lots

more.

CoPilot Welcome Menu

7CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

T-Mobile customers receive a complimentary 24 month

subscription to real-time traffic information*+.

Traffic incidents are reported in real-time into CoPilot using

the phone’s mobile Internet connection.

How to set-up Traffic Reports

To receive alerts for traffic incidents reported along your

planned route select, Settings > Live > Traffic. In the ‘Traffic

Settings’ screen, set the options as specified below:

Using Live Traffic

In Guidance Mode, press Options > Traffic > Check Route.

CoPilot Live will alertyou when traffic incidents are reported

on your road ahead by displaying a yellow traffic warning

indicator in its maps and itinerary.

Enable Traffic - Yes

Automatically Check for Traffic - Yes

Live Traffic

CoPilot Live 6 Symbian S60

Customer Support Helpline

(+44 (0)207 404 4222

symbian booklet 050406_new 5/4/06 12:04 Page 10

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali ALK Software

ALK

ALK CoPilot Symbian S60 Manuale utente

ALK

ALK CoPilot Live 11 Laptop Manuale utente

ALK

ALK iDEN i88s Manuale utente

ALK

ALK Pocket PC 4 Manuale utente

ALK

ALK Pocket PC 6 Bluetooth Manuale utente

ALK

ALK CoPilot A780 Manuale utente

ALK

ALK CoPilot CoPilot Live Smartphone Manuale utente

ALK

ALK CoPilot Pocket PC 5 Manuale utente

ALK

ALK Pocket PC 6 Bluetooth Manuale utente

ALK

ALK PC*MILLER I58SR Manuale utente

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
