Alliance Laundry Systems 25 Series Manuale utente

Operation/Programming/Maintenance

www.comlaundry.com

Part No. 70400201

September 2006

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

Drying Tumblers

25 Pound Capacity

30 Pound Capacity

35 Pound Capacity

Stacked 30 Pound Capacity

Through Serial No. 0602004143

Refer to Page 5 for Model Numbers

70400201 1

Installation must conform with local codes or in the absence of local codes with:

In the U.S.A., installation must conform to the latest edition of the American National Standard Z223.1/

NFPA 54 “National Fuel Gas Code” and Standard ANSI/NFPA 70 “National Electric Code.”

In Canada, installation must comply with Standards CSA-B149.1 or Natural Gas and Propane Code CSA

C22.1, latest edition, Canadian Electric Code, Part I.

In Australia, installation must comply with the Australian Gas Association Installation Code for Gas

Burning Appliances and Equipment.

IMPORTANT: Information must be obtained from a local gas supplier on instructions to be followed if the

user smells gas. These instructions must be posted in a prominent location. Step-by-step instructions of the

above safety information must be posted in a prominent location near the tumbler for customer use.

FOR YOUR SAFETY, the information in this

manual must be followed to minimize the

risk of fire or explosion or to prevent

property damage, personal injury or death.

W033

• Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

• WHAT TO DO IF YOU SMELL GAS:

– Do not try to light any appliance.

– Do not touch any electrical switch; do

not use any phone in your building.

– Clear the room, building or area of all

occupants.

– Immediately call your gas supplier from

a neighbor’s phone. Follow the gas

supplier’s instructions.

– If you cannot reach your gas supplier,

call the fire department.

• Installation and service must be

performed by a qualified installer, service

agency or the gas supplier.

W052

FOR YOUR SAFETY

Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

W053

WARNING

POUR VOTRE SÉCURITÉ, veillez à bien

respecter les indications de ce manuel afin

de minimiser les risques d’incendie ou

d’explosion ou d’écarter les dangers de

dommages matériels, corporel ou de mort.

W033FR

• Ne pas entreposer ni utiliser d’essence ni

d’autres vapeurs ou liquides

inflammables dans le voisinage de cet

appareil ou de tout autre appareil.

• QUE FAIRE SI VOUS SENTEZ UNE

ODEUR DE GAZ :

– Ne pas tenter d’allumer d’apareil.

– Ne touchez à aucun interrupteur. Ne

pas vous servir des téléphones se

trouvant dans le bâtiment où vous vous

trouvez.

– Évacuez la pièce, le bâtiment ou la

zone.

– Appelez immédiatement votre

fournisseur de gaz depuis un voisin.

Suivez les instructions du fournisseur.

– Si vous ne pouvez rejoindre le

fournisseur de gaz, appelez le service

des incendies.

• L’installation et l’entretien doivent être

assurés par un installateur ou un service

d’entretien qualifié ou par le fournisseur

de gaz.

W052Q

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser d’essence ou

autres gaz et liquides inflammables au

voisinage de cet appareil ou de tout autre.

W053FR

MISE EN GARDE

270400201

Notes

70400201 3

means without the expressed written consent of the publisher.

Table of

Contents

Introduction......................................................................................... 5

Model Identification ............................................................................. 5

Customer Service.................................................................................. 6

Wiring Diagram.................................................................................... 6

Serial Plate Location............................................................................. 6

Safety Information.............................................................................. 7

Explanation of Safety Messages........................................................... 7

Important Safety Instructions ............................................................... 8

Operating Instructions ....................................................................... 11

Emergency Stop Button on CE Models................................................ 11

Operating Instructions .......................................................................... 11

Control Instructions .............................................................................. 12

Electromechanical Coin Control...................................................... 12

Manual Timer................................................................................... 13

Diagnostic Microprocessor Control................................................. 14

DMP Coin ........................................................................................ 15

DMP OPL Models ........................................................................... 17

Maintenance ........................................................................................ 21

Daily ..................................................................................................... 21

Monthly................................................................................................. 23

Quarterly............................................................................................... 23

Bi-Annually .......................................................................................... 23

Before You Call for Service ............................................................... 26

Customer Service.................................................................................. 26

470400201

Notes

70400201 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Introduction

Model Identification

Information in this manual is applicable to these models.

Includes models with control suffixes:

Gas Steam Electric

25 Pound

CHD25G2-CA025L

CHD25G2-CA025N

CHD25G2-CT025L

CHD25G2-CT025N

CHD25G2-CU025L

CHD25G2-CU025N

DR25G2-BA025L

DR25G2-BA025N

DR25G2-BT025L

DR25G2-BT025N

DR25G2-BU025L

DR25G2-BU025N

IPD25G2-IT025L

IPD25G2-IT025N

CHD25S2-CT025S

CHD25S2-CU025S

DR25S2-BT025S

DR25S2-BU025S

IPD25S2-IT025S

CHD25E2-CT025E

CHD25E2-CU025E

DR25E2-BT025E

DR25E2-BU025E

IPD25E2-IT025E

30 Pound

CHD30G2-CA030L

CHD30G2-CA030N

CHD30G2-CT030L

CHD30G2-CT030N

CHD30G2-CU030L

CHD30G2-CU030N

DR30G2-BA030L

DR30G2-BA030N

DR30G2-BT030L

DR30G2-BT030N

DR30G2-BU030L

DR30G2-BU030N

IPD30G2-IT030L

IPD30G2-IT030N

CHD30S2-CT030S

CHD30S2-CU030S

DR30S2-BT030S

DR30S2-BU030S

IPD30S2-IT030S

CHD30E2-CT030E

CHD30E2-CU030E

DR30E2-BT030E

DR30E2-BU030E

IPD30E2-IT030E

T30

CHD30STG2-CAT30L

CHD30STG2-CAT30N

CHD30STG2-CTT30L

CHD30STG2-CTT30N

CHD30STG2-CUT30L

CHD30STG2-CUT30N

DRST30G2-BAT30L

DRST30G2-BAT30N

DRST30G2-BTT30L

DRST30G2-BTT30N

DRST30G2-BUT30L

DRST30G2-BUT30N

IPD30STG2-ITT30L

IPD30STG2-ITT30N

CHD30STS2-CTT30S

CHD30STS2-CUT30S

DRST30S2-BTT30S

DRST30S2-BUT30S

IPD30STS2-ITT30S

CHD30STE2-CTT30E

CHD30STE2-CUT30E

DRST30E2-BTT30E

DRST30E2-BUT30E

IPD30STE2-ITT30E

35 Pound

CHD35G2-CA035L

CHD35G2-CA035N

CHD35G2-CT035L

CHD35G2-CT035N

CHD35G2-CU035L

CHD35G2-CU035N

DR35G2-BA035L

DR35G2-BA035N

DR35G2-BT035L

DR35G2-BT035N

DR35G2-BU035L

DR35G2-BU035N

IPD35G2-IT035L

IPD35G2-IT035N

CHD35S2-CT035S

CHD35S2-CU035S

DR35S2-BT035S

DR35S2-BU035S

IPD35S2-IT035S

CHD35E2-CT035E

CHD35E2-CU035E

DR35E2-BT035E

DR35E2-BU035E

IPD35E2-IT035E

3O – DX4 OPL

3V – DX4 vended

3X – DX4 prep for coin

DO – DMP OPL

DV – DMP vended

CD – rotary coin drop

CX – prep for coin

MT – manual timer

Introduction

70400201

6© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Customer Service

If literature or replacement parts are required, contact

the source from which the machine was purchased or

contact Alliance Laundry Systems at (920) 748-3950

for the name and address of the nearest authorized

parts distributor.

For technical assistance, call (920) 748-3121.

Wiring Diagram

The wiring diagram is located in the junction or

contactor box.

Models starting Serial No. 0309_____ or later will

have the wiring diagram part number in the lower

portion of the electrical data on the serial plate.

Serial Plate Location

When calling or writing for information about your

product, be sure to mention model and serial numbers.

Model and serial numbers are found on serial plate on

rear of machine, and inside door hinge. Refer to

Figure 1.

Figure 1

TMB2025N

1Serial plate

TMB2025N

25, 30 AND 35 POUND TUMBLERS T30

Conversion Table

Multiply By To Obtain Multiply By To Obtain

Btu 0.252 kCal Pounds/sq. inch 0.06895 Bars

Btu 1055 Joules Pounds/sq. inch 0.070 kg/sq. cm

Inch 25.4 Millimeters Pounds (lbs.) 0.454 Kilograms

Inches W.C. 0.036 Pounds/sq. inch Boiler Horsepower 33,479 Btu/hr.

Inches W.C. 0.249 kPa Boiler Horsepower 34.5 lbs. steam/hr.

lb/inch2(psi) 6.895 kPa CFM 0.471 liters/second

ft328.32 Liters kW 3414 Btu/hr.

70400201 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Safety Information

Explanation of Safety Messages

Precautionary statements (“DANGER,” “WARNING,”

and “CAUTION”), followed by specific instructions,

are found in this manual and on machine decals. These

precautions are intended for the personal safety of the

operator, user, servicer, and those maintaining the

machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANT: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

IMPORTANT: Warranty is void unless tumbler

is installed according to instructions in the

Installation Manual. Compliance with minimum

specifications and requirements detailed herein,

and with applicable local gas fitting regulations,

municipal building codes, water supply regulations,

electrical wiring regulations, and any other

relevant statutory regulations. Because of varied

requirements, applicable local codes should be

thoroughly understood and all pre-installation

work arranged for accordingly.

NOTE: The WARNING and IMPORTANT

instructions appearing in this manual are not

meant to cover all possible conditions and

situations that may occur. It must be understood

that common sense, caution and carefulness are

factors which CANNOT be built into this tumbler.

These factors MUST BE supplied by the person(s)

installing, maintaining or operating the tumbler.

Always contact your dealer, distributor, service agent

or the manufacturer on any problems or conditions you

do not understand.

Indicates an imminently hazardous

situation that, if not avoided, will cause

severe personal injury or death.

DANGER

Indicates a hazardous situation that, if not

avoided, could cause severe personal

injury or death.

WARNING

Indicates a hazardous situation that, if not

avoided, may cause minor or moderate

personal injury or property damage.

CAUTION

Failure to install, maintain, and/or operate

this machine according to manufacturer’s

instructions may result in conditions which

can produce serious injury, death and/or

property damage.

W051R1

WARNING

Safety Information

70400201

8© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Important Safety Instructions

Save These Instructions

1. Read all instructions before using the tumbler.

2. Refer to the GROUNDING INSTRUCTIONS

for the proper grounding of the tumbler.

3. Do not dry articles that have been previously

cleaned in, washed in, soaked in, or spotted with

gasoline, dry cleaning solvents, other flammable

or explosive substances as they give off vapors

that could ignite or explode.

4. Do not allow children on or in the tumbler. This

appliance is not intended for use by young

children or infirm persons without supervision.

Young children should be supervised to ensure

that they do not play with the appliance.

5. Before the tumbler is removed from service or

discarded, remove the door to the drying

compartment and the door to the lint

compartment.

6. Do not reach into the tumbler if the cylinder is

revolving.

7. Do not install or store the tumbler where it will

be exposed to water and/or weather.

8. Do not tamper with the controls.

9. Do not repair or replace any part of the tumbler,

or attempt any servicing unless specifically

recommended in the user-maintenance

instructions or in published user-repair

instructions that you understand and have the

skills to carry out.

10. Do not use fabric softeners or products to

eliminate static unless recommended by the

manufacturer of the fabric softener or product.

11. To reduce the risk of fire, DO NOT DRY plastics

or articles containing foam rubber or similarly

textured rubberlike materials.

12. Always clean the lint filter daily.

13. Keep area around the exhaust opening and

adjacent surrounding area free from the

accumulation of lint, dust and dirt.

14. The interior of the tumbler and the exhaust duct

should be cleaned periodically by qualified

service personnel.

15. If not installed, operated and maintained in

accordance with the manufacturer’s instructions

or if there is damage to or mishandling of this

product’s components, use of this product could

expose you to substances in the fuel or from fuel

combustion which can cause death or serious

illness and which are known to the State of

California to cause cancer, birth defects or other

reproductive harm.

16. Tumbler will not operate with the loading door

open. DO NOT bypass the door safety switch to

permit the tumbler to operate with the door open.

The tumbler will stop tumbling when the door is

opened. Do not use the tumbler if it does not stop

tumbling when the door is opened or starts

tumbling without pressing or turning the START

mechanism. Remove the tumbler from use and

call for service.

17. Tumbler will not operate with lint panel open.

DO NOT bypass lint panel safety switch to

permit the tumbler to operate with the lint panel

open.

18. Do not put articles soiled with vegetable or cooking

oil in the tumbler, as these oils may not be

removed during washing. Due to the remaining

oil, the fabric may catch on fire by itself.

19. To reduce the risk of fire, DO NOT put clothes

which have traces of any flammable substances

such as machine oil, flammable chemicals,

thinner, etc. or anything containing wax or

chemicals such as in mops and cleaning cloths, or

anything dry-cleaned at home with dry-cleaning

solvent in the tumbler.

20. Use the tumbler only for its intended purpose,

drying fabrics.

21. ALWAYS disconnect and lockout the electrical

power to the tumbler before servicing. Disconnect

power by shutting off appropriate breaker or fuse.

22. Install this tumbler according to the

INSTALLATION INSTRUCTIONS. All

connections for electrical power, grounding, and

gas supply must comply with local codes and be

made by licensed personnel when required.

Hazardous Voltage. Can cause shock, burn

or cause death. Allow machine power to

remain off for two minutes prior to working

in and around AC inverter drive.

W359

WARNING

Altri manuali per 25 Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Alliance Laundry Systems Asciugatrice

Alliance Laundry Systems

Alliance Laundry Systems 907003062 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen DF7000WG Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 513006R3 Guida

Alliance Laundry Systems

Alliance Laundry Systems D0582 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems HSA030N Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 512685R5 Guida

Alliance Laundry Systems

Alliance Laundry Systems UniLinc 35 Series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems LES33AW Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 513257R1 Guida

Alliance Laundry Systems

Alliance Laundry Systems DRY2195N Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 000 BTU Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 50 Pound Series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems Drying Tumbler Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems DRY724C_SVG Guida

Alliance Laundry Systems

Alliance Laundry Systems 0904004427 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems DV6010WE Guida

Alliance Laundry Systems

Alliance Laundry Systems Drying Tumblers 175 Pound Capacity Istruzioni operative

Alliance Laundry Systems

Alliance Laundry Systems DR5004WE Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems HE-HG Seies Istruzioni per il montaggio

Alliance Laundry Systems

Alliance Laundry Systems CHD25G2-CA025L Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen DF7000SE Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TMB1276C Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems DRY725C Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems AE Series Manuale utente

Manuali Asciugatrice popolari di altre marche

Bosch

Bosch WTA79200GB Manuale utente

Amana

Amana W10233410A Manuale utente

Miele

Miele TWH 780 WP Manuale utente

Asko

Asko T760 Manuale utente

Bosch

Bosch Logixx 10 WTB76556GB Scheda tecnica

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manuale di istruzioni

Electrolux

Electrolux EW2H328R2 Manuale utente

Beko

Beko DS8433RX1M Manuale utente

Dawlance

Dawlance Spinner DS 6000 C Manuale utente

Electrolux

Electrolux TP5080TW Manuale utente

AEG

AEG TR838P4OB Manuale utente

Indesit

Indesit IDV 75 Manuale utente

Infiniton

Infiniton SD-DG85C Manuale utente

BOMANN

BOMANN WT 5019 Manuale utente

Asko

Asko T793C Manuale utente

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuale utente

Frigidaire

Frigidaire CAQE7077KW0 Manuale del proprietario

Bosch

Bosch WTX8HKM9SN Manuale utente
