Alliance Laundry Systems CS2000 Manuale elenco delle parti

-0-

INSTRUCTIONS FOR INSTALLATION, USE AND

MAINTENANCE

CS2000

ASEP2000

(VERSION ASEP2000.8 EN 01/01/08)

MACHINE N°/SERIAL NUMBER :

1300624

January 2008

-1-

Model Identification

Information in this manual is applicable to the following models:

UHM027D

UHM033D

UHM049D

UHM067D

These technical documents contain information that is privileged

and confidential.

You are hereby notified that any disclosure or copying is strictly

prohibited. We will proceed against any breach of this condition.

-2-

TECHNICAL DOCUMENT

ASEPTIC AND CS WASHING MACHINE SERIES 2000

CONTENTS

1. General working procedure p. 6

1.1 Description p. 6

1.2 Construction p. 7

1.2.1 Chassis-frame p. 7

1.2.2 Tub and drum p. 7

1.2.3 Suspensions p. 7

1.2.4 Porthole p. 7

1.2.5 Bearings, transmission and motor p. 7

1.2.6 Programming p. 8

1.3 Working principle p. 8

1.4 Security p. 8

1.4.1 Total protection against opening doors p. 8

1.4.2 Protection against unbalance p. 9

1.4.3 Heater protection p. 9

1.4.4 Security related to the gas heating system p. 9

1.5 Heating p. 10

2. Technical information regarding the installation p. 11

2.1 Technical specifications p. 11

2.2 Installation p. 12

2.2.1 Maintenance and unpacking p. 12

2.2.2 Characteristics of the room p. 13

2.2.3 Connections p. 14

2.2.4 First start-up p. 17

2.3 Adaptation of the device to another type of gas p. 17

2.3.1 Actions to be taken p. 17

2.3.2 Table of adjustments and flow rates p. 18

-3-

3. Technical information for the user p. 19

3.1 Details of the various elements p. 19

3.1.1 Opening and closing the doors p. 19

3.1.2 Soap trays p. 20

3.1.3 Unbalance and direction of rotation p. 20

3.2 Usage of washing machines with micro control p. 21

4. Periodic maintenance p. 21

4.0 Every day p. 21

4.1 Every week p. 21

4.2 Every month p. 21

4.3 Every 3 months p. 21

4.4 Every 6 months p. 22

4.5 Every year p. 22

5. Maintenance instructions p. 23

5.1 Remove sealing kit p. 23

6. Troubleshooting p. 24

6.1 Checks p. 24

6.2 Other break-downs p. 24

7. Problems during operation and start-up p. 25

-4-

LIST OF DIAGRAMS

N° diagram Index Date Description Type machine

AS2000-0001 06/01/00 Washer dryer, front view CS, ASEP2000

AS2000-0003 B 19/12/01 Side view CS, ASEP2000

AS2000-0009 A 29/03/00 Tub detail CS, ASEP2000

AS2000-0011 A 25/04/03 Drainage circuit CS ET ASEP2000

AS2000-0015 A 27/06/02 Display DF, CS, ASEP micro

AS2000-0016 06/01/00 Electrical heating unit DF, CS, ASEP

AS2000-0017 A 03/01/02 Water levels DF, CS, ASEP

AS2000-0018 A 25/04/03 Unlocking of tub door, washer DF, CS, ASEP

AS2000-0022 C 01/02/01 Installation scheme of aseptic

washer elec and steam 2000/27

AS2000/27 E / V

AS2000-0023 C 01/02/01 Installation scheme of aseptic

washer elec and steam 2000/33

AS2000/33 E / V

AS2000-0024 C 01/02/01 Installation scheme of aseptic

washer elec and steam 2000/49

AS2000/49 E / V

AS2000-0025 C 01/02/01 Installation scheme of aseptic

washer elec and steam 2000/67

AS2000/67 E / V

AS2000-0026 A 17/12/01 Soap tray – Water inlet CS, ASEP2000

AS2000-0027 A 01/10/01 Installation scheme of aseptic

washer gas 2000/27

AS2000/27 GAS

AS2000-0028 A 01/10/01 Installation scheme of aseptic

washer gas 2000/33

AS2000/33 GAS

AS2000-0029 B 24/05/01 Installation scheme of aseptic

washer gas 2000/49

AS2000/49 GAS

AS2000-0030 A 01/10/01 Installation scheme of aseptic

washer gas 2000/67

AS2000/67 GAS

CS2000-0022 D 27/06/02 Installation scheme of aseptic

washer elec and steam 2000/27

CS2000/27 E / V

CS2000-0023 D 27/06/02 Installation scheme of aseptic

washer elec and steam 2000/33

CS2000/33 E / V

CS2000-0024 D 27/06/02 Installation scheme of aseptic

washer elec and steam 2000/49

CS2000/49 E / V

-5-

CS2000-0025 D 27/06/02 Installation scheme of aseptic

washer elec and steam 2000/67

CS2000/67 E / V

CS2000-0027 B 27/06/02 Installation scheme of aseptic

washer gas 2000/27

CS2000/27 GAS

CS2000-0028 B 27/06/02 Installation scheme of aseptic

washer gas 2000/33

CS2000/33 GAS

CS2000-0029 C 27/06/02 Installation scheme of aseptic

washer gas 2000/49

CS2000/49 GAS

CS2000-0030 B 27/06/02 Installation scheme of aseptic

washer gas 2000/67

CS2000/67 GAS

ELECTRICAL DIAGRAMS AND SPARE PARTS LIST

Refer to technical manual

-6-

1. GENERAL WORKING PROCEDURE

1.1 Description

•Correct usage in accordance with design:

oThe dirty laundry is loaded into the front part of the machine and the clean

laundry is unloaded from the rear part of the machine, using portholes

situated opposite to the loading ports (for the Aseptic machines) or into the

front part of the machine (for the CS machines).

oWhen a separating wall is constructed at the middle plane of the machine this

will then avoid any contact between the dirty and the clean laundry.

•Simple usage:

oLoading and unloading of the laundry through one or two large ports opening

by 180°.

•Easy-to-use programs:

oControl of the machine by a microprocessor with five standard programs -

washing types. It provides the possibility to create 25 other programs

according to your requirements.

•No concrete base is required. However, a stable and level floor is absolutely

necessary.

•No vibrations are transmitted to the floor.

•The machine only requires one electrical connection, one connection for the

heating system of the machine (electricity or steam or gas) and one channel for

the drainage of used water.

•Various types of detergents may be used:

oClassical detergent in powder form or liquid detergent supplied by a dosing

pump.

Note: The supplier of the liquid detergents must carry out the adaptation of the

dosing pumps and their electrical connection (since the system is specific for

each type of product).

-7-

1.2 Construction

1.2.1 Chassis - frame

•Mechanically soldered frame of hot de-scaled steel plating, protected against

oxidation by phosphation, and covered with epoxy paint.

•Protection panels in stainless steel plating with 1.2 mm thickness.

•The design of the lower part of each tub port inhibits the laundry from slipping in-

between the tub and the drum.

1.2.2 Tub and drum

•The tub consists of a rolled stainless steel plate, closed at its extremities by 2

flanges, also stainless steel. The tub flanges are bolted to the tub and a seal

assures waterproofing.

•The drum consists of a perforated and pressed stainless steel plate. The plate is

then rolled and nested in two bead plates, also stainless steel. 4 beaters

mounted peripherally around the interior allow the laundry to be stirred correctly.

This assembly is held together by 4 tension rods that traverse the drum from one

end to the other.

1.2.3 Suspensions

The tub - drum assembly is suspended by four springs that are attached to the frame

and held in place by eight stabilisators, thus absorbing all vibration.

1.2.4 Porthole

The large-size portholes are of stainless steel and equipped with SECURIT panes of

tempered glass. Thus they permit a visual control of the washing operation.

1.2.5 Bearings, transmission and motor

•The connecting rod bearings are waterproof and have a hardened steel base.

•The transmission consists of one belt, providing a driving mechanism without

slippage.

•The asynchronous motor with variable frequency provides a gradual

acceleration, without shocks, which avoids drawing a large current when initiating

centrifugal motion.

-8-

1.2.6 Programming

Of the integral type with a microprocessor, regulation of:

•Four soap trays.

•Admission of hot, cold and/or soft water.

•Bath levels adjustable.

•Temperature adjustable from 0 to 90°C with microprocessor.

•Reduced mechanical washing motion for delicate laundry.

•Normal mechanical washing motion.

•Intermediate and final centrifuge.

1.3 Working principle

The following operations: loading the dirty laundry, loading the various detergents, and

starting and controlling the operations by means of the control panel, are all done on the

"dirty laundry" side of the machine.

Once the program is finished, the drum ports are automatically aligned with the "clean

laundry" side for the Aseptic machines (the laundry may then be unloaded on the other

side of the separation wall, in another room, without risking contamination of the clean

laundry by contact with the dirty laundry) or “dirty laundry” side (for the CS machines).

1.4 Security

1.4.1 Total protection against opening doors

This protection is designed to prevent accidents that might be caused by opening a

porthole while the drum is rotating.

•Depending on the machine type, either one or two magnetic latches inhibit the

opening of the porthole(s) of the tub.

•The microprocessor orders their release automatically.

•After centrifuging the release of the latches is retarded by about 90 seconds.

In case of an electrical outage and after verifying that the drum has come to a complete

stop, it is possible to unlock the doors by take away the front panel under the door and

pulling down the small cord.

-9-

1.4.2 Protection against unbalance

The suspended aseptic or CS machines are fitted with one or two unbalance

protections, according to their load capacity. These avoid excessive oscillations caused

by a strong unbalance by interrupting the centrifugal motion.

Effect of the protections in case of a strong unbalance

•During the final centrifuge, the centrifugal motion is interrupted and the drainage

is maintained, but the cycle is frozen. The message “E9 or unbalance fault” is

shown on the display. One must restart the cycle and move fast forward through

the program to arrive at the centrifuge phase again.

1.4.3 Heater protection

The bath heating system is not switched on unless the pressure meter, installed for this

purpose, detects the correct water level.

1.4.4 Security related to gas heating system

Four security systems guarantee the correct operation of the system.

•When no flame is detected in the burner, the igniter and control plug of the flame

causes the closure of the electronic valve in the gas feed, while message “E13”

appears on the micro control display. After waiting for about 20 seconds you may

then restart the system by a key combination for machine with micro control. If

the default appears again, one of the following faults has occurred:

oNo gas feed: check whether the gas feed valves are open.

oIgniter plug broken.

•The thermostat (chimney obstructed” interrupts the power supply to the

command module, in case the chimney is obstructed, and informs you of this

fault on the terminal display showing “E10 or chimney obstructed”. After several

minutes, you may restart the cycle by pressing “start”. Check your chimney when

the fault persists.

•The thermostat “heating security” also interrupts the command module when the

temperature in the heater is abnormal and informs you of this fault on the

terminal display showing “E11 or heating security”.

•The thermostat “water failure security” also interrupts the command module when

the heating element overheats and informs you of this fault on the terminal

display showing “E12 or water failure security”.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Alliance Laundry Systems Rondella

Alliance Laundry Systems

Alliance Laundry Systems NetMaster HC18NC2 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems AWNE8 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems CPD6C Manuale di installazione e funzionamento

Alliance Laundry Systems

Alliance Laundry Systems LWS16M series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems H370I Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems SC70 Guida

Alliance Laundry Systems

Alliance Laundry Systems W446I Guida

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen FR7002WN Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems W446I Guida

Alliance Laundry Systems

Alliance Laundry Systems 802749R2 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems H370I Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TLW12C SVG Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 801529 Manuale di servizio

Alliance Laundry Systems

Alliance Laundry Systems V-Series Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems EA2011 Series Istruzioni per il montaggio

Alliance Laundry Systems

Alliance Laundry Systems 801479R2 Guida

Alliance Laundry Systems

Alliance Laundry Systems F232135R12 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems LWS02M series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems CHF455 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems FLW1526C Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems WFF100 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems AWN432SP113TW01 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems F232136R5 Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems UW POCKET HARDMOUNT UW35B2 Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
