Allied Telesis www.alliedtelesis.com

Datasheet | integrated Multiservice Access Platform

FX10BX

AT-TN109-A 10 Port 100Mbps BX FTTx Service Module

Fiber to the Home/Business over

Single Fiber

The FX10BX is one of three Allied Telesis

802.3ah Active FTTH/B service modules for the

iMAP product family.This card provides 10 ports

at 100Mbps (full-duplex) over a single fiber

(Single-mode). Also available are dual fiber

options in either Single-mode or Multi-mode vari-

ations.The Gigabit feed into the iMAP backplane

allows the FX10 modules to operate completely

at wirespeed.

The additional Layer 2+ switching allows Service

Providers to meet the demands of multi-cast IP

video,Video on Demand, voice and data services.

With the FX10 modules, you can be assured

future bandwidth needs of HDTV will be

addressed as consumer demand increases.

Allied Telesis’ OAM solution allows for individual

full configuration and monitoring of each port.The

FX10 modules provide configuration tools to:

•Control or limit subscriber access

•Enforce port security rules

•Limit services to a port

•Manage QoS across the card

•Supportnetwork double-tagging

•Control ingress or egress service rates

Amultitude of applications can be supported

with the fiber-based 100Mbps access interfaces

including:

•FTTH for Voice,Video and Data Services

•FTTB for IP PBX, Ethernet and VPN services

•Campus LAN networkuplinks

Whether it is derived voice or HDTV IP Video,

the FX10 will satisfy all bandwidth and mission

critical services with ease.

Part of Allied Telesis’ IP Broadband

Access Family

Whether it is broadband ADSL2+, FTTH, POTS

or T1/E1 circuits, the iMAP family is the ideal

platform for last mile service delivery.The

FX10BX line card can be used with any of the

iMAP family of carrier grade, IP Multiservice

Access platforms:

•iMAP 9700 (9RU, 17 service slots)

•iMAP 9400 (3RU, 7 service slots)

•MiniMAP 9100 (1RU, 3service slots)

Provisioning, management, and diagnostics of

subscriber ports can be accomplished from

either the iMAP command line interface or the

NMS.

The FX10BX has been designed to survivethe

most rugged environmental conditions. It can be

confidently deployed in either a central office or

in outdoor enclosures withstanding extremes of

heat, cold, and lightning exposure.

Allied Telesis provides a large portfolio of

FTTx, Ethernet and xDSL transport and access

equipment. In addition, Allied Telesis provides a

complete set of xDSL and FTTx CPE solutions

in the formof Gateways, Layer 2/ Layer 3

switches, routers or media converters to

terminate the broadband link.

Key Features

Port-based

•VLANs

•VLAN translation

•Double-tagging (HVLAN)

•Filtering

•Ingress metering

•Egress port rate limiting

•Counters

•Classification and remarking

•RMON

QoS

•Four queues

•Priority scheduling

Security

•MAClimiting (up to 64)

•MACFlooding – VLAN-based

Services

•STP and RSTP

•Video-optimized – IGMP Snooping

•Upstream forwarding only

Support for

•Business services

•Residential service

•Single fiber,Single-mode

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000040 Rev. C

FX10BX |AT-TN109-A 10 Port 100Mbps BX FTTx Service Module

Ordering Information

Specifications:

Interface Specifications

Number of ports: 10

AT-TN109 Single-mode single fiber

Tx 1550nm, Rx 1310nm

19dB Optical Budget

SFF with SC Connector

Backplane capacity: 1Gbps

Physical design: Front Access

Protocols and Specifications

IEEE 802.1d,w Rapid Spanning Tree

IEEE 802.1D Bridging

IEEE 802.1Q VLAN Bridging

IEEE 802.1p Prioritization

IEEE 802.3ah EFM OAM

IEEE 802.3ad Link Aggregation

IETF RFC 1112 IP Multicasting/IGMP Snooping v1

IETF RFC 2236 IP Multicasting/IGMP Snooping v2

DHCP Relay Agent option 82 (RFC 3046)

Power Requirements

Maximum power: 36W

Environmental Specifications

Operating Temp: -40C to 65C

Storage Temp: -40C to 75C

Relative Humidity: 5% to 95%, non-condensing

RegulatoryApprovals

FCC Part 15 Class A/ANSI C63.4

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

VCCI Class A; ITE/ CISPR 22:1997 Class A

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998

EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996

EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999

UL/cUL 60950: IEC60950

NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2

USDARUS

*Where XX =10 for U.S.power cord

=20 for no power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord

Allied Telesis’ iMAP family of integrated

Multiservice Access Platforms

FX10BX

Model Description Part #

FX10BX 10 ports, 100Mbps BX Single-mode Single fiber AT-TN109-A

iMAP 9x00 Chassis

Model Description Part #

iMAP 9700 17-slot chassis with DC power with faceplates AT-TN-250GF

iMAP 9700 17-slot chassis with DC power without faceplates AT-TN-250G

iMAP 9400 7-slot chassis with DC power with faceplates AT-TN-251GF

iMAP 9400 7-slot chassis with DC power without faceplates AT-TN-251G

MiniMAP 9101 3-slot mini chassis with DC power AT-TN-9101-A-80

MiniMAP 9102 3-slot mini chassis with AC power AT-TN-9102-A-XX*

iMAP Common Control

Model Description Part #

CFC24 24GbE switch controller card AT-TN-401-B

GE3 3x GbE WAN interface card AT-TN-301-A

CFC56 56 GbE switch controller card AT-TN-407-A

XE1 10 GbE WAN interface card AT-TN-308-A

CFC12 12GbE switch controller card AT-TN-408-A

Related iMAP FTTX Line Cards

Model Description Part #

FTTX (MM) 10-port 100Mbps multimode fiber line card AT-TN-104-A

FTTX (SM, Dual Fiber) 10-port 100Mbps singlemode fiber line card AT-TN-107-A

FTTX (SM, Single Fiber) 10-port100Mbps singlemode, single fiber line card AT-TN-109-A

GE8 8-port GbE line card AT-TN-117-A

GEPON2 2-port GEPON line card AT-TN-118-A

Filler Full size service slot filler plate AT-TN-M000-A

Related FTTX CPE

Model Description Part #

RG613BD intelligent Multiservice Gateway, 3x LAN, 2x FXS, Single

fiber WAN interface

AT-RG613BD

RG623BD intelligent Multiservice Gateway, 3x LAN, 1x ISDN BRI,

Single fiber Single-mode WAN interface

AT-RG623BD

RG656BD intelligent Multiservice Gateway, 6x LAN, 3x FXS, Single

fiber WAN Single-mode Interface

AT-RG656BD
