Altusen KL0116 Manuale utente

FCC Information

This is an FCC Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate measures.

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

All brand names and trademarks are the registered property of their respective owners.

2003-07-23

Package Contents

The complete KL0116 16-Port LCD Console KVM Switch package contains

the following components:

M1 KL0116 KVM Switch

M2 Custom KVM Cable Sets

M1 Firmware Upgrade Cable

M1PowerCord

M1 Rack Mounting Kit (Optional)

M1 User Manual

M1 Quick Start Guide

M1 Warranty / Registration Card

Check to make sure that all the components are present and in good order. If

anything is missing, or was damaged in shipping, contact your dealer.

Read this manual thoroughly and follow the installation and operation proce-

dures carefully to prevent damage to the switch or any of the devices that con-

nect to it.

2003-07-23

Contents

About this Manual

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Getting Help

ALTUSEN Technical Support . . . . . . . . . . . . . . . . . . . viii

ALTUSEN Authorized Resellers . . . . . . . . . . . . . . . . . . viii

Chapter 1

Introduction

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . 4

Computers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

KL0116 Front View . . . . . . . . . . . . . . . . . . . . . . . . . . 6

KL0116 Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 2

Installation

Single Stage Installation . . . . . . . . . . . . . . . . . . . . . . . 11

Daisy Chaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Hot Plugging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Switching Station Positions: . . . . . . . . . . . . . . . . . . . 14

Hot Plugging CPU Ports: . . . . . . . . . . . . . . . . . . . . . 14

Powering Off and Restarting . . . . . . . . . . . . . . . . . . . . . 14

Port ID Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2003-07-23

iii

Chapter 3

Hotkey Operation

Hotkey Port Access . . . . . . . . . . . . . . . . . . . . . . . . . 17

Invoking Hotkey Mode . . . . . . . . . . . . . . . . . . . . . 17

Selecting the Active Port . . . . . . . . . . . . . . . . . . . . . 18

Auto Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Skip Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Hotkey Beeper Control . . . . . . . . . . . . . . . . . . . . . . . . 21

Hotkey Summary Table . . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 4

OSD Operation

OSD Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

OSD Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

OSD Main Screen Headings . . . . . . . . . . . . . . . . . . . 25

OSD Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

F1 GOTO: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

F2 LIST: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

F3 SET: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

F4 ADM: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

F5 SKP: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

F6 BRC: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

F7 SCAN: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

F8 LOUT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Chapter 5

The Firmware Upgrade Utility

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Starting the Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . 40

Upgrade Succeeded . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Upgrade Failed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Firmware Upgrade Recovery . . . . . . . . . . . . . . . . . . . . . 43

2003-07-23

Chapter 6

Remote Console Operation

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Appendix

KL0116 Connection Table . . . . . . . . . . . . . . . . . . . . 47

OSD Factory Default Settings . . . . . . . . . . . . . . . . . . . . 48

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

LCD Operation Reference . . . . . . . . . . . . . . . . . . . . . . 50

Clear Login Information . . . . . . . . . . . . . . . . . . . . . . . 51

Module Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Removing the KVM Module . . . . . . . . . . . . . . . . . . . 52

Removing the Keyboard and Touchpad . . . . . . . . . . . . . 53

Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Standard Rack Mounting . . . . . . . . . . . . . . . . . . . . . 54

Optional Rack Mounting . . . . . . . . . . . . . . . . . . . . . 54

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

2003-07-23

About This Manual

This User Manual provides information concerning the installation, configura-

tion, and operation of the KL0116 16-Port LCD Console KVM Switch.

Overview

Chapter 1, Introduction, introduces you to the KL0116. Its purpose, features

and benefits are presented, and its front and back panel components are described.

Chapter 2, Installation explains how to set up your installation —from a basic

single stage hookup to a complete three stage operation.

Chapter 3, Hotkey Operation, details the procedures used in the Hotkey

operation of your KL0116 installation.

Chapter 4, OSD Operation, provides a complete description of the KL0116’s

OSD (On Screen Display), and explains the procedures usded to manipulate it.

Chapter 5, The Firmware Upgrade Utility, describes how to upgrade the

KL0116’s firmware with the latest available version.

Chapter 6, Remote Console Operation, explains how to operate the

KL0116 from a remote console (up to 150 meters / 500 feet away).

An Appendix provides technical and other important information regarding the

KL0116.

2003-07-23

Conventions

This manual uses the following conventions:

Courier Indicates text that you should key in.

[ ] Indicates keys you should press. For example, [Enter] means to

press the Enter key. If keys need to be chorded, they appear

together in the same bracket with a plus sign between them:

[Ctrl+Alt].

1. Numbered lists represent procedures with sequential steps.

MBullet lists provide information

>Indicates selecting an option on a menu. For example, Start >

Run means to open the Start menu, and then select Run.

Indicates critical information.

Getting Help

For additional help, advice, and information, ALTUSEN provides several sup-

port options. If you need to contact ALTUSEN technical support with a prob-

lem, please have the following information ready beforehand:

MProduct model number, serial number, and date of purchase.

MYour computer configuration, including operating system, revision level,

expansion cards, and software.

MAny error messages displayed at the time the error occurred.

MThe sequence of operations that led up to the error.

MAny other information you feel may be of help.

2003-07-23

vii

ALTUSEN Technical Support

North America Technical

Phone Support Registered ALTUSEN product owners are entitled to

telephone technical support. Call the ALTUSEN

Technical Support Center: 949-453-8885.

International Technical Phone

Support 1. Contact your local dealer.

2. Call the ALTUSEN Technical Support Center:

1-949-453-8885.

Email Support Email your questions and concerns to:

[email protected]

Online Troubleshooting The ALTUSEN support website:

http://www.altusen.com/support

provides online troubeshooting that describes the

most commonly encountered problems and offers

possible solutions to them.

Online Documentation User Manuals are available electronically at the

ALTUSEN support website:

http://www.altusen.com/support

Software Updates Download the latest drivers and firmware for your

product from the ALTUSEN support website:

http://www.altusen.com/support

Product Information

For information about all of ALTUSEN’s products and how they can help you

connect without limits, visit ALTUSEN on the webat http://www.altusen.com

ALTUSEN Authorized Resellers

ALTUSEN provides the following ways to find an authorized reseller in your area:

MIn the United States of America, call: 866-ALTUSEN

MIn Canada and South America, call: 949-453-8885

MIn all other locations, call: 886-2-8692-6959

MVisit ALTUSEN on the web at http://www.altusen.com for a list of locations

and telephone numbers

2003-07-23

viii

Chapter 1.

Introduction

Overview

The ALTUSEN 16-Port LCD Console KVM Switch offers a highly efficient

network management solution. Custom designed high-density CPU connectors

allow a 16-port KVM switch to fit into a 1U high rack space. Additional AL-

TUSEN switches can be daisy chained to the KL0116, allowing up to 512 com-

puters to be controlled from its LCD console.

The KL0116 offers many advanced features, such as intuitive On Screen Dis-

play (OSD), Hotkeys, excellent video resolution, two level User password secu-

rity with different security clearances, and flash ROM for firmware upgrades.

The ALTUSEN KL0116 offers a space-saving, streamlined approach to KVM

switch technology, integrating a keyboard, LCD monitor, and touchpad in a 1U

high slide-out housing. The LCD display is built into the cover, and the key-

board and trackball are built into the base. Simply slide the KVM module sec-

tion out; flip the cover up; and you are ready to go to work. The KL0116’s

modular design also allows you to detach the KVM module from the switch

module for maintenance.

For further convenience, the switch can be operated from an independent, exter-

nal KVM console with the addition of an ALTUSEN Console Extender (not in-

cluded). The KL0116 also features high density 15 pin connectors instead of

the usual 25 pin connectors. This space-saving innovation allows installation of

a full, 16 port switch in a 1U system rack.

An included Firmware Upgrade Utility protects your KL0116 investment. You

can stay current with the latest functionality imporvements by downloading

firmware update files from the ALTUSEN website as they become available,

and use the utility to quickly and conveniently perfrom upgrades.

Setting up the KL0116 is fast and easy, consisting of plugging cables into their

appropriate ports. Because the KL0116 intercepts keyboard input directly, there

is no software to configure, and therefore no complex installation routines or in-

compatibility problems.

2003-07-25

You can easily access to any computer on the installation either by entering

Hotkey combinations from the keyboard, or by using the powerful menu driven

OSD system. A convenient Auto Scan feature also permits automatic scanning

and one-by-one monitoring of the activities of selected computers.

2003-07-25

Indice

Altri manuali Altusen Interruttore

Altusen

Altusen Altusen Hideaway KL1116 Manuale dell'operatore

Altusen

Altusen KH-88 Manuale dell'operatore

Altusen

Altusen KVM Over the NET KN2124v Manuale utente

Altusen

Altusen ALTUSEN PN9108 Manuale utente

Altusen

Altusen ALTUSEN KH1508 Manuale dell'operatore

Altusen

Altusen KVM Over the NET KN2116a Manuale utente

Altusen

Altusen KM0532 Manuale utente

Altusen

Altusen ALTUSEN KH1508 Manuale utente

Altusen

Altusen KM0832 Manuale utente

Altusen

Altusen Altusen Hideaway KL1116 Manuale utente

Altusen

Altusen Altusen KH-0116 Manuale dell'operatore

Altusen

Altusen ALTUSEN PN9108 Manuale utente

Altusen

Altusen ALTUSEN KH2508 Manuale utente

Altusen

Altusen ALTUSEN PN9108U Manuale utente

Altusen

Altusen KM0216 / KM0432 Manuale utente

Altusen

Altusen ALTUSEN KH2508 Manuale utente

Altusen

Altusen KH-88 Manuale utente

Altusen

Altusen KN2108 Manuale utente

Altusen

Altusen KVM Over the NET KN2116a Manuale utente

Altusen

Altusen KN9000 Manuale utente

Altusen

Altusen KM0032 Manuale utente

Altusen

Altusen Altusen KVM on Net KN2108 Manuale utente

Altusen

Altusen Altusen KVM on Net KN2108 Manuale utente

Altusen

Altusen KVM Over the NET KN2124v Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
