AK & 3K Series w/K30 Control Owners Manual
AMEREC STEAMBATH GENERATORS
(FOR USE WITH AMEREC AK AND 3K MODEL
GENERATORS)
FOR THE SAFETY OF YOU AND YOUR FAMILY PLEASE READ THE
WARNINGS TO THE RIGHT AND ALL INSTRUCTIONS BEFORE USING
YOUR STEAMBATH.
POST "WARNING" LABEL OUTSIDE STEAMBATH FOR SAFETY
WARNINGS. REQUIRED POSTING ON DOOR OF STEAM ROOM
OR ADJACENT TO DOOR FOR ALL COMMERCIAL INSTALLATIONS.
SAVE THIS MANUAL
Thank you for purchasing your new AMEREC steam generator. If we can be of any assistance
do not hesitate to call our Service Department at 1-800-331-0349.
WARNING
4209-22 10-27-09
Electric Shock Hazard - High voltage exists
within this equipment. There are no user
serviceable parts in this equipment. All
installation and service to this equipment
should be performed by qualified licensed
personnel.
Do not exceed 30 minutes in a steambath.
Excessive exposure can be harmful to your
health. Excessive exposure can produce a
rapid pulse, light-headedness, weakness or
fainting. If you become uncomfortable or
experience any of the above conditions exit
the steambath immediately.
Steambaths can put stress on the body.
Therefore a steambath should be used only
under a doctor's direction if you:
Are pregnant
Have a heart condition
Have high blood pressure
Have circulatory problems
Are under the influence of alcohol
Are under the influence of drugs
Have diabetes
Are under the care of a physician
Are in generally poor health
Children should only use the steambath
under close adult supervision.
Scald Hazard: Do Not Touch the steam head
or trim during operation as they are HOT.
Stay at least 12 inches away from the hot
steam escaping from the steam head.
Be careful when entering a steambath.
Escaping steam from an overheated steam
room may cause injury.
REDUCE THE RISK OF
1. Exit immediately if uncomfortable, dizzy or sleepy. Staying too long in
a heated area is capable of causing overheating.
REDUCE THE RISK OF
Use care when entering or exiting the steam room, floor may be slippery.
NOTE: For additional safety instructions, see owner’s manual.
CAUTION!
Do not contact steam head. Stay at least 12" away
from hot steam escaping from the steam outlet.
OVERHEATING AND SCALDING
2. Supervise children at all times.
3. Check with a doctor before use if pregnant, diabetic, in poor health or
under medical care.
4. Breathing heated air in conjunction with consumption of alcohol, drugs
or medication is capable of causing unconsciousness.
SLIPPING AND FALL INJURY
WARNING
AK Series w/K30 Control Owners Manual
4209-22 10-27-09
page 2
IMPORTANT SAFETY INSTRUCTIONS
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. WARNING - To reduce the risk of injury, do not permit children to use this
product unless they are closely supervised at all times.
3. WARNING - To reduce the risk of injury:
a. The wet surfaces of steam enclosures may be slippery. Use care when
entering or leaving.
b. The steam head is hot. Do not touch the steam head and avoid the
steam near the steam head.
c. Prolonged use of the steam system can raise excessively the internal
human body temperature and impair the body’s ability to regulate its
internal temperature (hyperthermia). Limit your use of steam to 10 - 15
minutes until you are certain of your body’s reaction.
d. Excessive temperatures have a high potential for causing fetal damage
during the early months of pregnancy. Pregnant or possibly pregnant
women should consult a physician regarding correct exposure.
e. Obese persons and persons with a history of heart disease, low or high
blood pressure, circulatory system problems, or diabetes should consult
a physician before using a steambath.
f. Persons using medication should consult a physician before using a
steambath since some medication may induce drowsiness while other
medications may affect heart rate, blood pressure and circulation.
4. WARNING - Hyperthermia occurs when the internal temperature of the body
reaches a level several degrees above the normal body temperature of 98.6
degrees F. The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness and fainting. The effect
of hyperthermia include:
a. Failure to perceive heat:
b. Failure to recognize the need to exit the steambath:
c. Unawareness of impending risk:
d. Fetal damage in pregnant women:
e. Physical inability to exit the steambath: and
f. Unconsciousness.
WARNING - The use of alcohol, drugs or medication can greatly increase the
risk of hyperthermia.
SAVE THESE INSTRUCTIONS
4209-22 10-27-09
AK Series w/K30 Control Owners Manual page 3
The K-30 model steam generator control features
a 30 minute press on timer lighting up the word
"STEAM" and a thermostatic control preset to
reach 120 degrees Fahrenheit. The primary
control can be mounted either inside or outside
the steam room and an optional 2nd control is
available to mount in an alternate location. The
preset temperature can be adjusted in a range
between 100 degrees and125 degrees Fahrenheit.
Once the set temperature is reached the ''soft
steam'' feature automatically engages cutting
steam production back to a single element to
provide softer billowing steam during more of
the steam bath. If the steam room temperature
drops more than 5 degrees both elements will
automatically engage.
1. Be sure the power circuit and water supply to
the generator are on.
2. Firmly press the ON/OFF button on the control
until the word “STEAM” lights up.
3. The generator should produce steam in 5
to 10 minutes and will turn off automatically in
30 minutes. You may also press the control a
second time to turn off the “STEAM” light and
shut down the generator.
4. If you wish to change the preset temperature
see the instructions in section 3.
5. Wait for the steam room to reach a comfort-
able temperature.
6. Remove clothing and jewelry.
7. Enter the steam room and close the door to
prevent steam from escaping.
8. Enjoy the warm steam releasing tense muscles
and refreshing the entire body.
9. If your steam room has a shower, a pleasant
experience can be achieved by taking a warm
shower with the steam.
10. After a steambath a warm shower will give
you a feeling of relaxation and is conducive to a
good night’s rest. A cold shower will refresh you
and is a good way to start a busy day or prepare
you for an evening out.
1. To adjust the set temperature remove the
snap-on decorative control cover by lifting from
thebottomas shownin diagram#1. (If anoptional
second control is connected only the “primary”
control plugged, into connector J7, can be used
to adjust the temperature) .
2. Using a small slotted screw driver turn the
adjustment pot in the desired direction. See dia-
gram #2. One quarter turn equals approximately
5 degrees of temperature change. Caution: Over
stressing the adjustment pot can damage the
control.
3. Snap the control cover plate back on by sliding
the top of the cover plate onto the control housing
and pushing on the bottom of the control cover
plate. See diagram #3. The new temperature
setting will become effective the next time the
steam is turned on.
DIAGRAM 3DIAGRAM 2
WALL
DECORATIVE CONTROL
COVER PLATE
CONTROL
HOUSING
SECTION 1: STEAM GENERATOR OVERVIEW
SECTION 2: OPERATION OF YOUR K30 CONTROL
SECTION 3: TEMPERATURE ADJUSTMENT
DIAGRAM 1
AK Series w/K30 Control Owners Manual
4209-22 10-27-09
page 4
The steam generator, steam head, fittings and
plumbing connections should be inspected regu-
larly for water leaks and damage. The AK steam
generator is equipped with a manual drain valve
for flushing sediments from the generator tank.
This procedure should be scheduled monthly or
more often depending on local water conditions
and steam bath usage.
Flushing Procedures:
1. The generator should be cool.
2. Press the control ON.
3. Open the manual drain valve.
4. The unit will drain without heating the
water.
5. Allow the water to run for a full 10 minutes.
6. Push the control OFF. When the water stops
flowingout thedrain, closethe manualdrain valve.
The troubleshooting guide is meant as a general aid only. There are no user serviceable parts in the generator. All repairs should be performed by a
qualified service person. For additional assistance or the number of the factory authorized service person nearest you call AMEREC’s Service Depart-
ment at 1-800-331-0349.
SECTION 4: MAINTENANCE OF YOUR AK STEAM GENERATOR
SECTION 5: TROUBLE SHOOTING GUIDE
4209-22 10-27-09
AK Series w/K30 Control Owners Manual page 5
P.O. Box 2258, Woodinville WA 98072
425-951-1120 Fax: 425-951-1130
email address: amerec @ amerec .com
1
28
12
4
43
29
15
24
23
2
16
7
8
22
19
5
18
17
20
14
6
13
3
39
33
44
21
34
9
35
36
11
50
