Remove the appropriate video output board by

loosening the lower mounting screw and gently lifting

up on the BNC bracket (c) until the board disengages

from the motherboard connector (d) . Move the

board slightly toward the rear of the unit until it

disengages from the backplane connector (e). Lift

the board from the unit. Refer to diagram 2.

VM2000 Text Overlay Board 1-1

Sensormatic

SENSORVISION SYSTEMS

VIDEO MANAGER 2000

Text Overlay Board

Installation Instructions

V8000-0750-01 Rev A

WARNING SHOCK HAZARD!

CAUTION STATIC

SENSITIVE COMPONENTS!

DISCONNECT AC POWER TO

THE VM2000 CONSOLE.

FOLLOW PROPER HANDLING

PROCEDURES TO PREVENT

COMPONENT FAILURE.

Parts

The following steps are the procedures for the

installation of the Text Overlay Board:

a. left top cover

b. video output board

Refer to Diagram 3 for connecting the correct text

overlay board to the correct connectors on the video

output board and setting the appropriate jumper pins.

Insert the top edge connector (a) on the video

output board into the backplane connector while

aligning the two bottom edge connectors (b) with the

motherboard connectors as shown in Diagram 4.

Shut the console OFF and uplug the power cord.1.

Remove the left top cover (a) located over the

video output board (b) as shown in diagram 1.

c. BNC bracket

d. motherboard connector

e. backplane connector

Sensormatic

Description Qty. Part No.

0301-0337-011PCB ASSY, VIDEO

MGR2, TEXT OVERLAY

8000-0750-01 Rev A1

VM2000 Text Overlay Board1-2

Sensormatic

SENSORVISION SYSTEMS

Installation Instructions, continued

V8000-0750-01 Rev A

Press down on the BNC bracket of the board until

the board is seated in the motherboard connectors

as shown by diagram 4 .

a. top edge connector

b. bottom edge connector

Replace the right top cover plate and tighten the

fastening screws.

Connect the video output cables to the appropriate

video output connectors.

Note: If you are unsuccessful booting up the

system, then refer to the Service section of the

VM2000 Installation and Service Manual under

Boot Failures. For checking operation of the new

video inputs, refer to the User's Manual.

6. Verify that the edge connector on the video output

board is properly seated into the backplane

connector and that the bottom edge connectors are

aligned with the motherboard connectors.

Notes:

Plug in the power cord and switch the power ON to

reboot the system.

10.

OUTPUT #4 TEXT OVERLAY OUTPUT #3 TEXT OVERLAY OUTPUT #2 TEXT OVERLAY OUTPUT #1 TEXT OVERLAY

PLACE JUMPER

HERE IF NO OVERLAY

PLACE JUMPER

HERE IF NO OVERLAY

PLACE JUMPER

HERE IF NO OVERLAY

PLACE JUMPER

HERE IF NO OVERLAY

111 1

1 111

OUTPUT #1

OUTPUT #2

OUTPUT #3

OUTPUT #4

Sensormatic

8000-0750-01 Rev A1
