American Standard EverClean 2675.002 Manuale utente

COLONY 5’™

WHIRLPOOL AND BATHING POOL

HIGH GLOSS ACRYLIC

COLONY 5’WHIRLPOOL AND BATHING POOL

❏2675.018 Whirlpool featuring System I:

•Acrylic with fiberglass reinforcement

•Dual, molded-in armrests at lumbar area

•1.0 HP single speed, self-draining pump/motor

with dry run seal

•Factory installed power cord with plug

•Six multi-directional and individually flow-rate

adjustable color-coordinated jets

•Deck-mounted, color-coordinated air switch

On/Off control

•Single, color-coordinated air volume control

•Factory installed and tested whirlpool system

❏2675.018C Stay Clean™Whirlpool Massage

Featuring System I:

•Same as 2675.018 except with the

StayClean™whirlpool system featuring

Antimicrobial AlphaSan®

❏2675.002 Bathing Pool

•Same as above without whirlpool system

Nominal Dimensions: 1524 x 832 x 502mm

(5’x 32-3/4”x 19-3/4")

Revised 1/99

To Be Specified - Required:

❏Color:

❏Bath Faucet: (specify finish)

❏Bath Drain: 1583.470 (specify finish)

To Be Specified - Optional:

❏5 Foot Acrylic Apron: 9260.018 (specify color)

❏5 Foot Apron: 9360.018 (specify color)

❏Grab Bar Kit: 9822.200-two per kit (specify finish)

❏Jet Trim Ring Kit: 9860.200-two per kit (specify finish)

❏Universal Tile Bead Kit: 751755-100

NOTE: Roughing-in dimensions and product

specifica-tions shown on reverse side of page.

Compliance Certifications -

Meets or Exceeds the Following Specifications:

•Underwriters Laboratories - Hydromassage

Bathtubs UL 1795

•ASME A112.19.7M for Whirlpool Appliances

•ANSI Z124.1 for Plastic Bathtubs

•ASTM E162 for Flammability

•NFPA 258 for Smoke Density

For color/finish availability and other faucet choices,

please see the Product Selector and Pricing Guide.

COLONY 5’™

WHIRLPOOL AND BATHING POOL

HIGH GLOSS ACRYLIC

NOTES:

BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE

INSTALLATION. SUPPORT OF BATH BY SUMP BEDDING. SUPPORT AND ENCLOSING MATERIAL BY OTHERS.

■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.

OPTIONAL 3WALL TILING BEAD KIT AND APRON NO. 9260.018 OR 9360.018, AND GRAB BAR KIT NO. 9822.200

AVAILABLE AND MUST BE ORDERED SEPARATELY.

FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.

PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.

IMPORTANT: Dimensions of fixtures are nominal and may vary within the range of tolerances

established by ANSI Standard Z124.1.These measurements are subject to change or cancellation. No

responsibility is assumed for use of superseded or voided pages.

464 mm

(18-1/4)

38 mm

(1-1/2)

502 mm

(19-3/4)

1-1/2 O.D.TAILPIECE

BATH

SUPPORT

MATERIAL

■ LEVELING STRINGER

NOT FOR SUPPORT

ROUGH

FLOOR

1524 mm

(60)

832 mm

(32-3/4)

OUTLINE OF CUTOUT

1486 mm x 794 mm

(58-1/2 X 31-1/4 )

416 mm

(16-3/8)

216 mm

(8-1/2)

305 mm

(12)

38 mm

(1-1/2)

(6) JETS

79 mm

(3-1/8)

CUTOUT IN FLOOR FOR DRAIN

PUMP

FINISHED

WALL

305 mm

(12)

OPTIONAL TO

FINISHED FLOOR

USUALLY BETWEEN

1651 & 1981mm

(65 & 78) C/L OF

OVERFLOW

102 mm

(4)

C/L OF

SPOUT

C/L OF

VALVES

C/L OF

SHOWER ARM

70 mm

(2-3/4) 117 mm

(4-5/8)

1-1/2 N.P.T.M.

THREADS

19 mm

(3/4)

229 mm

(9)

C/L OF

SUPPLIES

SEE FITTING

SPECS FOR

DIMENSIONS

(1) AIR VALVE

ON/OFF

SWITCH

PROVIDE ACCESS TO PUMP FOR

SERVICING ON ALL INSTALLATIONS

464 mm

(18-1/4)

38 mm

(1-1/2)

502 mm

(19-3/4)

1-1/2 O.D.TAILPIECE

BATH

SUPPORT

MATERIAL

■ LEVELING STRINGER

NOT FOR SUPPORT

ROUGH

FLOOR

1524 mm

(60)

832 mm

(32-3/4)

OUTLINE OF CUTOUT

1486 mm x 794 mm

(58-1/2 X 31-1/4 )

416 mm

(16-3/8)

216 mm

(8-1/2)

305 mm

(12)

38 mm

(1-1/2)

79 mm

(3-1/8)

CUTOUT IN FLOOR FOR DRAIN

FINISHED

WALL

305 mm

(12)

OPTIONAL TO

FINISHED FLOOR

USUALLY BETWEEN

1651 & 1981mm

(65 & 78) C/L OF

OVERFLOW

102 mm

(4)

C/L OF

SPOUT

C/L OF

VALVES

C/L OF

SHOWER ARM

70 mm

(2-3/4) 117 mm

(4-5/8)

1-1/2 N.P.T.M.

THREADS

19 mm

(3/4)

229 mm

(9)

C/L OF

SUPPLIES

SEE FITTING

SPECS FOR

DIMENSIONS

60 x 32-3/4 x 19-3/4 In.(1524 x832 x 502mm)

95 Lbs. (43 Kg.)

604 Lbs. (275 Kg.)

61 Gal. (230 L.)

42 Gal. (159 L.)

20 x 39 In. (508 x 991mm)

27-1/2 x 56 In.(699 x 1422mm)

14-1/4 In. (362mm)

44 Lbs./Sq. Ft. (213 Kgs/Sq. m.)

15.6

29.6

GENERAL SPECIFICATIONS FOR 2675 WHIRLPOOL

INSTALLED SIZE

WEIGHT

WEIGHT w/WATER

GAL. TO OVERFLOW

WHIRLPOOL MIN. OPERATING VOL.

BATHING WELL AT SUMP

BATHING WELL AT RIM

WATER DEPTH TO OVERFLOW

FLOOR LOADING

(PROJECTED AREA)

PTS.

CUBE (FT3)

WHIRLPOOL ELECTRICAL SPECIFICATIONS

1.1 HP, 9.9 AMPS, 120V.SYSTEM I PUMP

60 x 32-3/4 x 19-3/4 In.

(1524mm x 832 mm x 502mm)

70 Lbs. (32 Kg.)

579 Lbs. (261 Kg.)

61 Gal. (230 L.)

20 x 39 In. (508 mm x 991mm)

27-1/2 x 56 In.(699 mm x 1422mm)

14-1/4 In. (362mm)

42 Lbs./Sq. Ft. (202 Kgs/Sq. m.)

15.6

29.6

GENERAL SPECIFICATIONS FOR 2675 BATHING POOL

INSTALLED SIZE

WEIGHT

WEIGHT w/WATER

GAL. TO OVERFLOW

BATHING WELL AT SUMP

BATHING WELL AT RIM

WATER DEPTH TO OVERFLOW

FLOOR LOADING

(PROJECTED AREA)

PTS.

CUBE (FT3)
