American Standard Evolution 6060VC Manuale utente

H99

Components Required:

❏ Bath Filler*: (specify nish)

❏ Bath Drain: 1583.470 (specify nish)

Custom Accessories Available:

❏ Corner Apron: 0707.200 (specify color)

❏ Tile Bead Kit: 751755-100

For color/nish availability and other faucet choices, please

see the Product Selector and Pricing Guide.

NOTE: The Safe-T-Heater is designed to maintain water tem-

perature during operation. It will not heat cold water to desired

bathing temperature.

EVOLUTION™ CORNER

Comfortable two person design with dual back

support positions, integral seat and installed grab

bar. Includes factory installed Safe-T-Heat

Whirlpool Heater.

❏ 6060V Whirlpool

• Acrylic with berglass reinforcement

• 2.1 HP self-draining pump/motor

• Ten ow adjustable jets including:

- Two adjustable Comfort Jets™ Hi Flo

- Eight adjustable Comfort Jets™

• Three silent air volume controls

• Side-mounted On/Off control

• Complete factory installed and tested

whirlpool system

• Pre-installed Safe-T-Heater Whirlpool Heater

❏ 6060VC Whirlpool W/EverClean® System

• Same as above with the EverClean System

Nominal Dimensions:

1384 x 1384 x 546mm

(54-1/2" x 54-1/2" x 21-1/2")

Installed Size:

1949 x 1661 x 546mm

(76-3/4" x 65-3/8" x 21-1/2")

Compliance Certications -

Meets or Exceeds the Following Specications:

• Underwriters Laboratories - Hydromassage

Bathtubs UL 1795

• ASME A112.19.7M for Whirlpool Appliances

• ANSI Z124.1 for Plastic Bathtubs

• ASTM E162 for Flammability

• NFPA 258 for Smoke Density

American Standard whirlpools with EverClean®

incorporate a patented silver-ion additive right

into the circulation piping to protect the pipes

from mold, mildew, algae and fungus that could

cause deterioration or staining of the pipes.

SEE REVERSE FOR PRODUCT DIMENSIONS

AND SPECIFICATIONS

EVOLUTION™

CORNER WHIRLPOOL

HIGH GLOSS

* See American Standard Faucet Selector

Revised 2/08

H100

EVOLUTION™

CORNER WHIRLPOOL

HIGH GLOSS

NOTES:

BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND OR PENINSULA TYPE INSTALLATION.

SUPPORT OF BATH BY INTEGRAL FEET. NO ADDITIONAL SUPPORT REQUIRED. SUPPORT AND ENCLOSING MATERIAL

BY OTHERS.

■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.

OPTIONAL 2-WALL TILING BEAD KIT No.TILE-BEAD MUST BE ORDERED SEPARATELY.

▲ CUTOUT TEMPLATE PROVIDED IN SHIPPING BOX. MAY BE REQUESTED SEPARATELY.

PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.

IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1

These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided leaet.

(203mm)

19-1/2"(C)

(495mm)

65-3/8"

(1661mm)

18"(A)

(457mm)

21-1/2"(H)

(546mm)

DIMENSIONS OF FIXTURES ARE NOMINAL AND MAY VARY WITHIN THE RANGE

OF TOLERANCES ESTABLISHED BY ANSI STANDARDS Z124.1 AND A112.19.7.

C/L OF

OVERFLOW

(178mm)

76-3/4"

(1949mm)

54-1/2"

(1384mm) 65-3/8"

(1661mm)

(76mm)

(178mm)

15"

(381mm)

5-5/8"

(143mm)

17-3/4"

(451mm)

10"

(254mm)

13-3/4"

(349mm)

CUT OUT

IN FLOOR

FOR DRAIN

OUTLINE OF

CUTOUT

INSTALLED SIZE

WEIGHT

WEIGHT w/WATER

GAL. TO OVERFLOW

WHIRLPOOL MIN. OPERATING VOL.

BATHING WELL AT SUMP

BATHING WELL AT RIM

WATER DEPTH TO OVERFLOW

FLOOR LOADING

(PROJECTED AREA)

GENERAL SPECIFICATIONS FOR 6060V WHIRLPOOL

WHIRLPOOL ELECTRICAL SPECIFICATIONS

PUMP

76-3/4 x 65-3/8 x 21-1/2 In. (1949 x 1661 x 546mm)

108 Lbs. (49 Kg.)

824 Lbs. (374 Kg.)

86 Gal. (325 L)

71 Gal. (269 L)

48 x 26-1/2 In. (1219 x 673mm)

63 x 50 In. (1600 x 1270mm)

15 In. (381mm)

24 Lbs./Sq.Ft. (116 Kgs./Sq.m)

2.1 HP, 14.4 AMPS,120V.

E-Z INSTALL WHIRLPOOL HEATER 12.0 AMPS,120V.

Revised 2/08
