Ameriwood HOME 5360307COM Manuale utente

5360307COM

NightStand

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B345360307COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butis

requiredfortheassemblyofyourunit.

LeftPanel

35360307010

RightPanel

35360307020

Top

35360307030

Bottom

35360307040

DrawerFront

35360307050

DrawerBottom

39991340042110D

drawerSide

39991167346200C

DrawerBack

39991167041140B

BackPanel

K536030700

ABCD

DWR

SIDE DWR

BACK

5

ameriwoodhome.com

BoardIdentification

Notactualsize

DWR

SIDE

DWR

BACK

DWR

SIDE

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butis

requiredfortheassemblyofyourunit.

6

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x4)

#A22570

cam lock

(x4)

#A22510

cam bolt

(x4)

#A21660

wood dowel

(x20)

#A12120

#8 x 7/16" pan head

(x10)

#A11080

#6 x 7/16" flat head

(x20)

#A21110

nail

(x2)

#A17400

7/8" pan head

(x4)

#A23030

confirmat

(x4)

#A21970

drive fastener

(x2)

#A54520

drawer bracket

LeftCabinetMember

RightCabinetMember

LeftDrawerMember

RightDrawerMember

(x1)

#A56770

DrawerSlideKit

11a

11b

11c

11d

(x1)

#A52695

handle

(x4)

#A44500

foot

7

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

135

(x1)

#A56770

Markedwitha"L"

LeftCabinetMember

(x3)

#A11080

(x2)

#A21660

(x2)

#A22570

finishededge

11a

8

ameriwoodhome.com

STEP2

(x2)

#A22570

(x2)

#A21660

(x3)

#A11080

Markedwitha"R"

(x1)

#A56770

finishededge

11b

RightCabinetMember

Proper orientation of CAM LOCK

Tip

Assembly

Quick

11b

9

ameriwoodhome.com

STEP3

(x4)

#A22510

10

ameriwoodhome.com

STEP4

UNLOCKLOCK

finishededge
