Ameriwood HOME 7601817COM Manuale utente

7601817COM

MantelwithFireplace

B347601817COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

37601015010 RightPanel

37601015020

CenterTop

37601322030

CenterBottom

37601015040

LeftInnerPanel

37601000050

RightInnerPanel

37601000060

CenterKick

37601015070

CenterSupport

37601000080

CenterUpperRail

37601015090

CenterLowerRail

37601015100

CenterVerticalRail

37601015130 LowerFrontPanel

37601015140

LeftInsetRail

37601015150 LeftOuterPanel

37601015170

VerticalRail(x2)

37601015110

UpperFrontPanel

37601015120

RightInsetRail

37601015160

RightOuterPanel

37601015180

6

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftTop

37601322190 RightTop

37601322200 SideBottom(x2)

37601015210

LeftKick

37601015230

AdjustableShelf(x4)

37601015220

Thesepiecesarepaperboardconstruction.

Theyarenotmadefromwood,butare

requiredfortheassemblyofyourunit.

BackPanel(x2)

K760101500

BACK

PNL

STU

RightKick

37601015240

SideKick(x2)

37601015250 LeftDoor(x2)

37601015270

RightDoor(x2)

37601015280

7

ameriwoodhome.com

BoardIdentification

Notactualsize

8

ameriwoodhome.com

BoardIdentification

Notactualsize

BACK

PNL

BACK

PNL

9

ameriwoodhome.com

PartList

ActualSize

(x38)

#A22700

camlock

(x38)

#A22710

cambolt

(x22)

#A21670

wooddowel

(x10)

#A22770

quickloc

(x2)

#A12820

1"screw

(x11)

#A12120

screw

(x56)

#A21110

nail

(x16)

#A80250

shelfsupport

(x4)

#A23030

confirmat

(x8)

#A17250

5/8"bolt

(x4)

#A89020

plasticbumper

(x4)

#A11170

5/8"screw

(x24)

#A21980

hiddenfacefastener

910

10

ameriwoodhome.com

NotActualSize

PartList

17d

17c

17b

17a

17e

(x1)

#A84000

safetystrapkit

(x1)

#A95080

fireplaceinsert

(x4)

#A50875

handle

(x8)

#A65640

hinge

(x2)

#A54270

metalplate

15 16
