Ameriwood HOME 9605341COM Manuale utente

9605341COM

bookcase

B349605337COM0

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Follow Ameriwood Home

Tube

You

Date of Purchase ___ / ___ / ___

Lot Number:

Assembly Difficulty Meter

Easy Tough

Secure Your Furniture

Keep your home and family safe

with the wall anchor kit that is

included with the product.

Serious or fatal crushing injuries can

occur from tipping furniture.

WARNING: Manufacturer assumes no liability

for improper installation or excessive loads

placed on screws or bracket. This wall anchor

is not a substitute for proper adult supervision.

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Tube

You

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not actual size

Tube

You

Left Panel

39605341010 Right Panel

39605341020

Top

39605341030

Bottom

39605341040

Upper Apron

39605341050

Lower Apron

39605341060 x2

Vertical Molding

39605341070

Upper Molding

39605341080

Lower Molding

39605341090

Fixed Shelf

39605341100

Adjustable Shelf

39605341110

Back Panel

K960534100

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

ameriwoodhome.com

Board Identification

Not actual size

Tube

You

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

ameriwoodhome.com

Part List

Actual Size

Tube

You

Not Actual Size

(x12)

#A22620

cam lock

(x12)

#A22610

cam bolt

(x6)

#A21660

wood dowel

(x16)

#A12955

1-1/8" flat head

(x8)

#A80250

shelf support

(x6)

#A53600

angle bracket

(x12)

#A12210

#8 x 1/2" pan head

(x36)

#A21110

nail

2 3 45

(x1)

#A84050

safety bracket kit

(x3 sheets)

#J21341

paste-ons

ameriwoodhome.com

STEP1

Tube

You

(x2)

#A22620

234

(x4)

#A22610

(x1)

#A21660

(x5)

#A12955

end view

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP2

Tube

You

234

(x2)

#A22620 (x4)

#A22610

(x1)

#A21660

(x5)

#A12955

end view

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP3

Tube

You

(x4)

#A22620 (x2)

#A21660

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP4

Tube

You

(x4)

#A22620 (x2)

#A21660 (x3)

#A12955

end view

Proper orientation of CAM LOCK

Tip

Assembly

Quick
