Ameriwood HOME 4842222COM Manuale utente

4842222COM

BarCabinet

B344842222COM1

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:2

ESTIMATEDASSEMBLYTIME:2HOURS

3

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

BeforeYouStart

Quick

Tip

Assembly

5

BoardIdentification

Notactualsize

LeftPanel

34842222010

RightPanel

34842222020

LeftPartition

34842222030 RightPartition

34842222040

DrawerBack(x2)

39991120035540B

DrawerBottom(x2)

39991341036610D

DrawerFront(x2)

34842222120

DrawerSide(x4)

39991120346200C

ABCD

DWR

SIDE

DWR

BACK

DWR

BTM

Divider(x2)

34842222090

Bottom

34842222070

Top

34842222060

UpperPartition

34842222050

Shelf

34842222080

DividerShelf(x4)

34842222100

Door(x2)

34842222110

AdjustableShelf(x2)

34842222130

6

BoardIdentification

Notactualsize

DWR

BACK

DWR

BTM

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

BackPanel

K484222200

DWR

SIDE L

DWR

SIDE

7

PartList

ActualSize

(x14)

#A22610

cambolt

(x14)

#A22620

camlock

(x14)

#A21670

wooddowel

(x10)

#A23030

confirmatscrew

(x20)

#A11080

7/16"flat

headscrew

(x16)

#A12120

7/16"round

headscrew

(x4)

#A52365

knob

(x4)

#A17400

7/8"bolt

(x8)

#A21970

drivefastener

(x12)

#A12420

5/8"round

headscrew

123

(x34)

#A21110

nail

(x8)

#A80250

shelfsupport

Note: Your model may

contain extra hardware.

(x4)

#A54510

drawerbracket

notactualsize

8910

8

PartList

NotActualSize

(x4)

#A54800

footbracket

(x4)

#A44320

foot (x2)

drawerslidekit

#A56770

rightdrawermember

leftdrawermember

rightcabinetmember

leftcabinetmember

14a

14b

14c

14d

(x1)

#A84050

Safety Bracket Kit

18d

18c

18b

18a

(x4)

#A65640

hinge

9

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2)

#A22610

123

(x2)

#A22620

(x2)

#A21670

(x3)

#A11080

(x1)

#A56770

leftcabinetmember

Markedwitha"L"

18a

finishededge

10

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

12 3

(x2)

#A22610

(x2)

#A22620

(x2)

#A21670

(x3)

#A11080

(x1)

#A56770

rightcabinetmember

Markedwitha"R"

18b

finishededge
