MINI AIR EASi 2
air cushion system
使用手册
服务热线：0592-6271616
HANDBOOK
基本参数
拆开外箱后，请确认箱内有以下配件：
出厂原装配件
电 源：AC110V-220V；50-60Hz
额定功率：120W
运行速度：8m/min
设备重量：5kgs
外观颜色：灰色
外形尺寸：405×220×195mm
A、插上电源线，按下开关至
“I”档位，接通电源。
B、设备正常通电后，控制面板的液晶显示器进
入主界面：
C、主界面停留5秒后，自动进入操作界面
D、安装卷膜
a）管芯套入卷膜支撑杆
注：将有进气口一侧朝下套入
拨至“I”档，
电源启动
EAB 表示设备编号
图一
图二
图三
图四
操作说明
S.T 表示温度大小
FAN 表示风量大小
扳手组一套
隔热布（2条）
电源线（1条）
MINI AIR
air cushion system
HANDBOOK
TEL：+86-400-700-6166
Easi handbook ... 1Easi handbook ... 2
When open the box, please make sure the
following accessories are in the box:
Technical Data
Power: 110V-220V
Rated: 90W
Speed: 3m/min
Net Weight: 2.5kgs
Color: White
Dimension: 405×220×195mm
The factory
original accessories
A. Connect the power line and
switch on, the power light
will illuminate. (picture 1)
B. You will automatically enter the start page on the
control panel.
C. After approx. 5 seconds the system will automatically
enter the main page.
D. Installation of film roll
switch on
picture 1
picture 2
picture 3
picture 4
Operating Instructions
EA refer to device ID
S.T refer to Temperature
FAN refer to Air volume
a) Put the film roll on the roll
hoder. (picture 4)
Note: the black line side
should be placed facedown.
扳手组一套
隔热布（2条）
电源线（1条）
MINI AIR EASi 2用户手册 ... 3MINI AIR EASi 2用户手册 ... 4
Better Cushion
Better Protection
www.amesonpak.com
2019版
服务热线：0592-6271616
43
1
2
IN/OUT START/STOP
6
5
启动/暂停键
进膜键
降低温度
增加温度 增加风量
降低风量
图六
b）卷膜绕过导膜杆，如（图五）所示。
c）将卷膜套入充气管，直至硅胶轮处，按住设备操作面板上黄色
的”IN/OUT ”(进退膜键）将卷膜从气管内拉出。如（图五）所
示。
参数设置
图五
风量与温度参数设置参考值
推荐参数
Wrapper 风量
葫芦球
大双排
小双排
200x100mm
200x150mm
200x200mm
四连排
大波浪
小波浪
38
30
35
38
17
16
15
40
40
Filler 风量
200x130mm 16
电子说明书
更多推荐参数
设备操作 维护视频
Better Cushion
Better Protection
www.cushionpak.com
Version 2019
Easi handbook ... 3Easi handbook ... 4
b) Roll film bypasses S line support shaft (picture 5)
c) When the film reached the roller, press still (hold on) the
IN/OUT button, the film will go through itself.
d) Check whether the film is set into the blowing port, and
press the “START\STOP” button to start work. (picture 5)
Adjust the temperature using the + and – button
on the left side of the panel.
Adjust the air volume using the + and – button
on the right side of the panel.
picture 5
picture 6
Data Setting
43
1
2
IN/OUT START/STOP
6
5
Start/Stopin/out
Recommended parameter
Wrapper FAN
bubbles
bubble wave
tube wave
200x100mm
200x150mm
200x200mm
tube multi
tube small
tube large
38
38
38
38
17
16
15
35
30
Filler FAN
200x130mm 16
TEL：+86-400-700-6166
Video for Operation
and Maintenance
E-handbook
