Apelson ICONFLEX60F Manuale utente
Fl ex l- zo ne F le xl -z on e
User Manual
Instruction Manual
Induction Hob
MODEL: ICONFLEX60F
2
Safety Warnings
This instructions are for your safety. Please read
them thoroughly prior to installation and retain
them for future reference.
The appliance is not to be used by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction.
Children being supervised not to play with the
appliance.
The appliance incorporates an earth
connection for functional purposes only.
WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of
electric shock.
WARNING:A steam cleaner is not be used.
Metallic objects such as knives, forks, spoons
and lids should not be placed on the hob
surface since they can get hot.
After use, switch off the hob element by its
control and do not rely on the pan detector.
The appliance is not intended to be operated
by means of external timer or separated
remote-control system.
3
Danger offire: Do not store items onthe
cooking surfaces.
CAUTION:The cooking process has to be
supervised. Ashort term cooking process has
to besupervised continuously.
WARNING: Unattended cooking on a hob with
fat oroil can be dangerous and may result in a
fire.
If the supply cord is damaged, it must be
replaced bythe manufacturer,its service
agentor similarly qualified persons in order to
avoid a hazard.
WARNING:Before obtaining access to
terminals, all supply circuits must be
disconnected.
This appliance can be usedbychildren aged
from 8 years and above and persons with
reduced physical, sensory ormental
capabilities or lack ofexperience and
knowledge if they have been given
supervision or instruction concerning useof
theappliance in a safe way and understand
the hazards involved. children shall notplay
with the appliance. cleaning anduser
maintenance shall notbemade bychildren
without supervision.
4
WARNING: The appliance and its accessible
parts become hot during use.
Care should betaken to avoid touching
heating elements.
Children less than 8 years of ageshall bekept
away unless continuously supervised.
NEVER try toextinguish a fire with water,but
switch off the appliance and then cover flame
e.g. with a lid ora fire blanket.
WARNING: Use only hob guards designed by
the manufacturer ofthe cooking appliance or
indicated bythe manufacturer ofthe
appliance in the instructions for use as
suitable or hob guards incorporated in the
appliance. The use ofinappropriate guards
can cause accidents.
Ensure the Power cord isn’t accessible after
installation.
5
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Installation
Manual in order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
Product Overview
Top View
User interface
Fl ex l-zon e Fl ex l- zo ne
6
User interface
Reference Description
AZone select key
BChild lock key
CON/OFF key
D Power/Timer slider regulating key
E
Boost control key/Keep warm
key
F
Timer key/Pause key
Heating zone Power
Heating Zone Max.Power（220-240V~ 50/60Hz）
2000/2800W（Booster）
1500/2000W（Booster）
1500/2000W（Booster）
2000/2800W（Booster）
Total Rating Power 7200W
7
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents
AWord on Induction Cooking
Induction cooking is a safe, advanced, efficient, and economical cooking
technology. It works by electromagnetic vibrations generating heat directly in
the pan, rather than indirectly through heating the glass surface. The glass
becomes hot only because thepan eventually warms it up.
Before using your New Induction Hob
Read this guide, taking special note of the ‘Safety Warnings’ section.
Remove any protective film that may still be on your Induction hob.
Using the Touch Controls
The controls respond to touch, so you don’t need to apply any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that there is no object (e.g.
a utensil or a cloth)covering them. Even a thin film of water may make the
controls difficult to operate.
8
Choosing the right Cookware
•Only use cookware with abase suitable for induction
cooking. Look for the induction symbol on the
packaging or on the bottom of the pan.
•You can check whether your cookware is suitable by carrying out
amagnet test. Move amagnet towards the base of the pan. If it
is attracted, the pan is suitable for induction.
•If you do not have amagnet:
1. Put some water in the pan you want to check.
2. If does not flash in the display and the water is heating, the pan is suitable.
•Cookware made from the following materials is not suitable: pure stainless steel, aluminum or
copper without a magnetic base, glass, wood, porcelain, ceramic and earthenware.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size asthecooking zone. Use pans whose diameter is as large as the
graphic of the zone selected. Using apot aslightly wider energy will be used at
its maximum efficiency. If you use smaller pot efficiency could beless than
expected. Pot less than 140 mmcould be undetected by the hob. Always
centre your pan on thecooking zone.
Always lift pans off the Induction hob – do not slide, or they may scratch the
glass.
9
Using your Induction
select key by pressing “ ” key. The symbol 0. selected will stay fully it.
•You have not placed a pan on the correct cooking zone or,
•The pan you’re using is not suitable for induction cooking or,
•The pan is too small or not properly centred on the cooking zone.
No heating takes place unless there is a suitable pan on the cooking zone.
The display will automatically turn off after 1 minutes if no suitable pan is
placed on it.
alternately withthe heatIf the display flashes
setting
This means that:
Hob
To start cooking
1. Touch the ON/OFF key（A）for 3 seconds.
After power on, the buzzer beeps once, all displays
show “ – “, indicating that the induction
hob has entered the state of standby mode.
2. Place a suitable pan on the cooking zone that
you wish to use.
• Make sure the bottom of the pan and
Of the cooking zone are clean and dry.
the surface
3. According to the heating zone where the pan is placed, select a relevant zone
4. Adjust heat setting by touching the slider regulating key(D) control.
• If you don’t choose a heat setting within 1 minute, the induction hob will
automatically switch off. You will need to start again at step 1.
• You can modify the heat setting at any time during cooking.
10
When you have finished cooking
Touching the relevant zone select key(A) that you wish to switch off.
Press the “-”key will decrease the power to “0” level,
or press the "+" and "-"at the same time, the power level will decrease to
0 straight away.
Beware of hot surfaces
will show which cooking zone is hot to touch. It will disappear when the
surface has cooled down to a safe temperature. It can also be used as an
energy saving function if you want to heat further pans, use the hotplate that is
still hot.
Using the Boost function
Actived the boost function
1. Select the heating zone by touching the zone select key (A).
2. Touching the boost control key(E),the zone indicator show “P” and
the power reach Max.
Cancel the Boost function
1. Touching the relevant zone select key(A) that you wish to cancel.
2. Touching the slider regulating key(D) to cancel the Boost function, then the
cooking zone willrevert to level 9.
• The
function can work in any cooking zone.
• The cooking zone returns to level 9 after 5 minutes.
1.Tou
ch th
e cooking zone selection button that you wish to use keep warm,an
indicato
r next to the key will flash.
2.Touch the button and hold for 3 seconds, the cooking zone indicator will
display .
3. If you want to cancel the keep warm, select the cooking zone you wish to
operate，and then touch the button and hold for
zone will be off.3 seconds. The cooking
Using the Keep warm Function
