Lenni - Lucey Installation Manual for Standard Table

Welcome to APQS Family!

Thank you for selecting APQS as your longarm quilting company! As a family-owned company, we work

hard to make our “new” family members feel welcome, and we provide lifetime customer support. We

are honored to serve you.

This manual includes the necessary information to assemble your Lenni or Lucey Quilting System.

If you are missing any parts or have received incorrect or damaged parts, please call our Customer

Service Team at 800-426-7233 so we can resolve the problem quickly for you. You can also reach us by

email at service@apqs.com.

Even if you are not assembling the machine yourself, please read the assembly instructions and

familiarize yourself with their contents. You’ll learn the different part names and will better understand

your set up should you ever need to call us for service.

Every machine purchased directly from APQS includes a free, 6-hour beginner class. Visit our Event

Calendar to locate a beginner class near you, or contact your local dealer for more information.

Be sure to join the APQS Quilting Channel on YouTube – you’ll find video tutorials on everything from

how to thread your machine to how to quilt feathers, along with helpful maintenance videos. Don’t

forget to “like” us on Facebook and follow the “We Love APQS” Facebook page!

You’ll also find helpful tips on the APQS website at www.apqs.com. Visit the “Resources” and the

“Service and Support” tabs for more videos, our blog, and the answers to the most frequently asked

service questions.

If you have any questions, please contact us. We are here to help!

APQS

1-800-426-7233

Lenni – Lucey Standard Table Manual

9-22-21

APQS.com

Table of Contents

APQS Customer Service & Suport ..............................................................................................5

APQS Certified Technicians ........................................................................................................5

Warranty Information ................................................................................................................5

Assembly Preparation Tips.........................................................................................................6

General Assembly Order ............................................................................................................8

Assembly Tools...........................................................................................................................9

Shipping Box Content...............................................................................................................10

Standard Table Step 1: Assemble the Rails & Legs.................................................................11

Standard Table - Step 2: Determine Table Orientation & Attach Legs to Rails.......................13

Standard Table - Step 3: Install the Table Top ........................................................................20

Standard Table - Step 4: Install the Roller End Arms...............................................................22

Step 5 (a): Install the Carriage (Bliss Track) .............................................................................25

Step 5 (b): Install the Carriage (NON-Bliss Track)....................................................................27

Step 6: Install the Sewing Head...............................................................................................31

Standard Table - Step 7: Install the Rollers .............................................................................34

Standard Table - Step 8: Install the Roller Hardware...............................................................37

Step 9: Install the Thread Stand & Laser Bolt...........................................................................40

Step 10: Install the Rear Handles .............................................................................................41

Step 11: Connect Cables and Power (Non-Quilt Path).............................................................43

Step 12: Machine Operation of Lenni & Lucey ........................................................................46

APQS Bobbin Winder Setup & Maintenance ...........................................................................53

Daily Machine Maintenance ....................................................................................................64

General Machine Maintenance................................................................................................69

Fuses ....................................................................................................................................69

Main Fuse Location and Replacement (ALL APQS Machines)..............................................69

Circuit Board Fuse ................................................................................................................72

Fuse Replacement (CSA Models) ........................................................................................76

Hopping Foot Height Verification........................................................................................80

Lenni – Lucey Standard Table Manual

9-22-21

APQS.com

Hopping Foot Height Adjustment .......................................................................................81

Stitch Encoders ....................................................................................................................84

Carriage Encoder – Deluxe Non-Bliss Table .........................................................................84

Carriage Encoder – Bliss Table ........................................................................................86

Head Encoder – All Tables...............................................................................................88

Motor Brushes .....................................................................................................................90

Needle Up/Down Speed Adjustment (Needle Positioner) .................................................93

Tension Assembly Maintenance..........................................................................................97

Tension Check Spring Replacement ....................................................................................99

Bobbin Thread Cutter – Millie & Millie 30 ........................................................................109

Wave Washer and/or Cutting Blade Replacement...........................................................113

Timing Belt Adjustment.....................................................................................................118

Timing Your APQS Machine...............................................................................................121

Hook Assembly Maintenance Instructions .......................................................................140

Quick Troubleshooting Guide............................................................................................142

Quilting Basics ........................................................................................................................149

Lenni – Lucey Standard Table Manual

9-22-21

APQS.com

Learn more about your APQS Machine …

•Click on the Education Tab on our website for information about Beginner Classes in your area, starting a

business, inspiration, blogs and more.

•Need help? Click on our Support Tab for FAQs, service information and helpful how-to videos.

•Ready to quilt? Want some design ideas? Subscribe to the APQS Quilting Channel on YouTube to see

hundreds of APQS videos that show you everything from loading the machine to quilting feathers!

•Join us on the APQS Forum for fun conversation, information sharing, and every day tips and hints.

Everyone is welcome; we’d love to see photos of your projects, hear about your successes, and even

welcome your questions and suggestions on improving our machine and company. To join, visit the APQS

website at www.apqs.com . Select the “Education” tab on the home page and click on “Forum” in the

drop-down menu.Or, or “like” us on Facebook at “We Love APQS”.

Lenni – Lucey Standard Table Manual

9-22-21

APQS.com

Need More Help?

APQS Customer Service & Suport

We want you to have the best possible quilting experience. We take pride in leading the industry with our

superior customer service and support, and we can’t help you if we don’t hear from you.

Monday-Friday, 8 a.m. – 5 p.m. CST

800-426-7233

[email protected]

APQS Online Store

Visit our Online Store for needles, bobbins, thread, oil, replacement parts, and accessories for your APQS Longarm

machine.

APQS Certified Technicians

In addition to factory-direct support, APQS has trained several APQS Dealers with

advanced troubleshooting and support skills. These APQS Certified Technicians work

closely with the factory team to solve problems and help you get back to quilting as

quickly as possible. Look for the Certified Technician symbol on the APQS Retailer

listings to see if one is near you.

Warranty Information

New APQS Machines sold directly through APQS includes a Limited Lifetime Warranty to the original owner. Demo

machines and Certified Used machines carry different warranties. For information about your warranty coverage

or how to make a warranty claim, consult the warranty document included with your machine, visit our Lifetime

Warranty Page, or contact APQS Customer Service at 800-426-7233.

8-1-2021

APQS.com

Lenni – Lucey Standard Table Manual

Assembly Preparation Tips

Even if you are not assembling the machine yourself, please read through the assembly instructions thoroughly to better

understand your machine.

Before assembling your machine, answer these questions:

Where will the machine be located, and how will it be oriented in the room?

It is important before you move the shipping boxes into your sewing room to identify where your longarm will be placed.

Consider where you want the ‘needle side’ of your machine placed in relation to your space. When facing the ‘needle

side’ of the machine, the left or right side of the table can rest next to a wall giving you more space on the opposite side.

Before bringing in the long roller/rail boxes (shipping boxes 1 & 2), these boxes are heavy and it is easiest to open the

boxes and move the rollers and rails separately. The three rollers with canvas are labeled on the right side of the rollers.

The roller with no canvas is the Leveler Bar and is not labeled, be sure the labeled end of this canvas/bar is brought into

your sewing space with the label end going toward the right of your ‘needle side’ of the table.

Be aware of your chosen orientation and which way the rollers need to be carried into your sewing space (you may need

to flip the rollers around in your room if they were brought in incorrectly and if you don’t have room to flip them, you may

need to take them to a space where they can be flipped around).

FRONT

Freehand (needle) side

REAR

Pantograph

Top View

Pick Up Roller

Leveler Bar

(no label)

Quilt Top Roller

Backing Roller

Rollers are labeled on the

right side of each canvas,

these labels need to be

placed to the right of the

‘needle’ side of the

carriage.

The labeled end of each roller

canvas is placed to the right side

of your table. The Leveler Bar

does not have canvas and is not

The carriage rails are also directional in that the flat side of

both rails should face each other when bringing them into

your sewing space. In other words, the C shape of the rails

should face outward.

8-1-2021

APQS.com

Lenni – Lucey Standard Table Manual

Do you have easy access to electrical outlets?

Your quilting machine draws no more power than a normal household appliance. However, a surge protector can reduce

the damage risk from electrical spikes. If you need to use an extension cord to reach an outlet, use a standard “heavy duty”

14-gauge extension cord. It should be a three-prong grounded cord. Do not bypass the grounding feature by using a two-

prong adapter for your outlet. To protect yourself and your machine, have a certified electrician re-wire your outlet if it is

not properly grounded. Even with a surge protector, consider unplugging your machine from the outlet during severe

electrical storms to prevent a surge from damaging the electronics.

Are you adding the Quilt Path computerized system?

See Quilt Path Installation Manual. We strongly encourage you to invest in a Dual-Conversion, Pure Sine Wave

Uninterruptible Power Supply (UPS). This auxiliary unit protects your machine and computer from power drops and

surges, but also provides clean power to the system if your power fails, allowing you enough time to properly save your

work and shut down the system. The UPS MUST be a Pure Sine Wave model to work correctly with your machine. Here

are to models recommended by APQS Engineers:

Opti-UPS Durable Series DS1500B 1500VA

Tripp Lite SU1000XLA

Are you adding the optional hydraulic lift or overhead lighting to your table?

See Hydraulic Lift or Overhead Lighting Intallation Manuals. These instructions will tell you when it will be best to add

those parts and are referenced so you can go to the appropriate Installation Manuals. Full instructions for accessory

installations are included ON-LINE and are in your shipping material.

What flooring material is in your room?

Wood or parquet floors may be easily scratched if you try to move the machine after putting it together. Consider cutting

a small square of tightly woven carpet to act as a “coaster” for each leg, then placing the carpet face down under each leg

as you put the table together. If your room has plush carpet and padding, the table’s weight may eventually break down

the pad under the legs. You may want to place additional padding under the legs, just as you might under a heavy sofa. If

you park your machine at one end of your table routinely, heavy carpet pad could eventually break down on that end,

throwing your machine out of level. Re-check the table if you have difficulty moving the machine. In addition, machines

on hard concrete or tile floors benefit from padding under the legs to reduce residual vibration reflected back up the legs

from the hard flooring.

8-1-2021

APQS.com

Lenni – Lucey Standard Table Manual

General Assembly Order

Your new quilting machine is not difficult to assemble. It can

usually be accomplished in just a few hours. While the basic

assembly is possible alone, extra hands are very helpful

throughout the process.

Assembly Process Overview

1. Add the rear Aluminum Table Rail to the two Table Legs

If installing optional casters, put them on before this step

2. Install the Rail Cross Tubes.

3. Add the front Aluminum Table Rail to the two Table Legs

If installing optional Quilt Path, Overhead Lighting or a Hydraulic Lift, add those BEFORE installing the Table Top.

4. Install the Tabletop pads and bumpers, then add the Table Top

5. Assemble and mount the Carriage

6. Assemble and install the Sewing Head

7. Install the Pick-Up Roller and Leveler Bar

8. Deluxe or Standard Table

9. Deluxe Table - add the optional Auto Quilt Advance

10. Standard Table - install one Roller Brake

11. Install the Quilt Top and Quilt Backing Rollers

12. Add the Roller Brake to these two Rollers

13. Complete the electrical connections

8-1-2021

APQS.com

Lenni – Lucey Standard Table Manual

Assembly Tools

Helpful but not required:

Wire Cutter to cut zip ties

Power Screwdriver the #2 Bit

Assembly Tools (includes tools for optional accessories)

8-1-2021

APQS.com

Lenni – Lucey Standard Table Manual

Shipping Box Content

Box ID

Contents

(2) Aluminum Rails

(3) Fabric Rollers, (1) Leveler bar

Lexan Tabletop

Carriage, Table Assembly Hardware, Cross Tubes, Optional Accessories (e.g. Auto Quilt Advance)

Table Leg

Sewing Head (Handles, Thread Stand, Power Cord, Optional Bliss Carriage Axle, Optional Accessories)

8, 9, 10

(optional accessories not shown) -- Overhead Lighting, Hydraulic Lift, Quilt Path (Quilt Path will be labeled

as the highest number in the shipment. For example, if you do not order the Overhead Lighting or Lift, but

you DO order Quilt Path, “Box 8” will be your Quilt Path unit. If you order Overhead Lighting AND Quilt

Path, the lighting will be “Box 8” and your Quilt Path will be “Box 9”.)

①

②

⑦

⑥

⑤

④

③

IMPORTANT: Please keep the sewing head box ⑦ plus all foam inserts and all packing

boxes/materials that were inside the head box. These are necessary to protect your machine

for moving or to safely ship the head to your APQS Certified Technician or back to APQS for

factory service.

All other packing boxes can be recycled or discarded.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali APQS Macchina da cucire

APQS

APQS Millie MY19 Manuale utente

Manuali Macchina da cucire popolari di altre marche

Riccar

Riccar RL634DE Manuale utente

Singer

Singer 2517 Manuale utente

Pfaff

Pfaff 3307-1 SERIES Manuale utente

Janome

Janome Quilt Maker Pro 18 VERSA Manuale utente

Siruba

Siruba C007JP Manuale utente

Husqvarna Viking

Husqvarna Viking Designer SE Manuale utente

Singer

Singer 148-5 Manuale utente

IKEA

IKEA SY Manuale utente

Pfaff

Pfaff 571 Manuale utente

Singer

Singer 15-91 Manuale utente

Brother

Brother BB370 Manuale utente

Pegasus

Pegasus WT100 Series Manuale utente

Reliable

Reliable 7100DB Manuale utente

Pfaff

Pfaff 937 Manuale utente

Singer

Singer 6038 Manuale utente

Singer

Singer 413K Manuale utente

Pfaff

Pfaff 1471 E1 Manuale utente

Kenmore

Kenmore 16677 - Serger Sewing Machine Manuale utente
