Apricorn Aegis Portable Manuale utente
Quick Start Guide
Attention: Use only the included cables with yourAegis Max. You might
damage the drive if you use a cable not included with theAegis Max.
In the rare case that theAegis Max
does not power up on a single
USB connection, the included USB
Y-cable may be required (pictured
right). Simply plug the two Y-cable
USB connectors (black and grey
connectors) into the two USB ports
on your notebook, connect the
Aegis Max, and the drive will power.
PoweringtheAegisMax
using the USB Y-cable
Package contents
Aegis Max• Travel pouch• USB Power Cable•
Quick Install
Aegis Max
USB Y-Cable• Software CD•
Ensure your computer’s power is turned on.1. Plug the Aegis Max cable into a USB port on your computer.2. The3. New Hardware Foundmessagemayappearbrieyonyourcomputerscreen.
The Aegis Max drive icon will appear in4. My Computer for Windows or on the
Desktop for Mac.
Your newAegis Max is now5. ready for use.
Data Protection Suite Software
For Windows®7, XP and Vista
Microsoft®SyncToy download
SyncToy is an easy to use, highly customizable program
that helps simplify the task of the copying, moving, and
synchronization of different directories. Most common operations can be
performed with just a few clicks of the mouse, and additional customization
is available without additional complexity. SyncToy can manage multiple
setsoffoldersatthesametime;itcancombinelesfromtwofoldersin
one case, and mimic renames and deletes in another case. Unlike other
applications,SyncToyactuallykeepstrackofrenamestolesandwill
make sure those changes get carried over to the synchronized folder.
PerfectforsynchronizinglesbetweenyourcomputerandyourAegis
Portable Hard Drive.
SMART-ER®Internal Hard Drive Health Monitor
SMART-ER is an indispensable utility that works in the background
to continuously monitor the health of your internal hard disk drives
and free space. SMART-ER automatically reports any deviation from
optimal performance, allowing you to take preemptive action BEFORE hard
drive failures occur. Once SMART-ER detects a problem, it immediately
notiesyouandofferssuggestedcorrectiveaction.
Installation instructions
Insert Apricorn CD into your1. CD-ROM drive.
Setup screen will pop-up.2.
Click the program you wish3. to install.
Follow instructions for4. installation.
PC System Requirements
Pentium®II CPU or later, 128 MB RAM
Standard USB port
CD-ROM or CD-RW drive
Windows 7, XP or Vista
For the Mac®OS
Installation instructions
Insert Apricorn CD into your1. CD-ROM drive.
When the CD appears on your2. desktop, double click to open.
Double click on the appropriate3. software package to begin
installation. This will open the
package and mount a drive on
your desktop.
Open this drive by clicking on
4. the newly created disk icon.
To install drag installation5. icon to the Applications and
run.
Follow instructions for setup6. in the Read Me or User’s
Guide.
ShirtPocket SuperDuper!
With ShirtPocket SuperDuper! Lite, creating a bootable clone of
your hard drive couldn’t be simpler. Compatible with both Intel and
Power PC Macs and featuring a user-friendly interface that is easy to use,
SuperDuper! is the most advanced disk copying program available for the
Mac OS.
Apricorn Encrypter for Mac
Apricorn’s Encrypter is a simple and easy to use utility that allows
for the creation of encrypted virtual volumes. Using AES 128-bit
encryption, Apricorn Encrypter creates a disk image where you can securely
save important documents, pictures and music, keeping them safe.
Mac System
Requirements
Apple®G3 or later
Standard USB or FireWire
port (depending on model)
CD-ROM or CD-RW drive
Mac OS X 10.x or later
Disconnecting the Aegis Max
Windows®7, XP and Vista
Locate the system tray on your Windows Desktop (system tray is the1. part of the task bar that displays the date and time).
Click on the “Safely Remove Hardware” icon in the system tray. A2. dialog box will appear.
Click on “Safely Remove Hard Disk - Drive (:D)” in the dialog box (your3. drive letter may differ).
Wait for a few seconds until the system prompts “The hard disk storage4. device can now be safely removed from the system.”
Click OK and then unplug the Aegis Max.5.
Apricorn provides the following helpful resources for you:
1. Apricorn’s Website (http://www.apricorn.com)
This gives you the ability to check for up-to-date information.
3. Or call the Technical Support Department at 1-800-458-5448.
Apricorn’s Technical Support Specialists are available from 8:00 a.m. to
5:00p.m.,PacicStandardTime,MondaythroughFriday.
Technical Support
© Apricorn, Inc. 2010. All rights reserved.
12191 Kirkham Road
Poway, CA, U.S.A. 92064
Mac®OS
The drive will need to be dismounted. This can be done by dragging1. the drive to the Trash Can.
Wait for a few seconds. Once the Aegis Max icon has disappeared, you2. can safely remove the drive.
NOTE:Toprotectagainstunexpecteddataloss,Windowschecksthatalllesonthe
disk are closed before allowing the USB device to be removed. If you receive an error
message that says “The device cannot be stopped right now. Try stopping the device again
later.”CloseallWindowsandProgramsthatareusinglesfromthedrive,thenrepeatthe
procedure above.
