APRILIA MX 50 Guida utente

8202422

CATALYTIC MUFFLER

USE ONLY UNLEADED PETROL IN CONFORMITY WITH THE DIN 51607 STANDARD, MIN. O.N. 95

(N.O.R.M.) AND 85 (N.O.M.M.) AND HIGH PERFORMANCE SYNTHETIC OIL FOR 2 STROKE ENGINES.

THE USE OF FUELS AND LUBRICANTS DIFFERENT FROM THOSE INDICATED CAUSES SEVERE

FUNCTIONAL INCONVENIENCES TO THE VEHICLE AND THE VOIDING OF THE aprilia GUARANTEE.

To have the catalytic converter functioning correctly for long periods and to reduce possible

problems regarding the contamination of the thermal unit and of the exhaust, it is necessary to

avoid covering long distances with the engine running at constantly low rpm.

It is sufficient to alternate these periods with periods in which the engine runs at relatively high rpm,

even if only for a few seconds, but rather frequently.

What has been stated above assumes particular importance for the cold starting of the engine: in this

case, in order to reach a rpm regime sufficient to enable the “priming” of the catalytic reaction, you just

need to make sure that the temperature of the thermal unit has reached at least 50°C, which generally

occurs a few seconds after starting the engine.

CATALYTIC SILENCER

The catalytic version of the MX50 is fittedwith asilencer with metal catalyticconverter of the “platinum-

rhodium bivalent” type. This device provides for the oxidation of the CO (carbon monoxide) and of the

HC (unburned hydrocarbons) contained in the exhaust gases, changing them into carbon dioxide and

steam, respectively. Due to the catalytic reaction, the high temperature reached by the exhaust gases

results in the burning of the oil particles, thus keeping the silencer clean and eliminating the exhaust

fumes.

Avoid parking the catalytic vehicle near dry brush wood or in places easily accessible to chil-

dren, as the catalytic silencer becomes extremely hot during use; be very careful and avoid any

kind of contact before it has completely cooled down.

First edition: January 2004

Reprint:

Produced and printed by:

DECA S.r.l.

Via Risorgimento, 23/1 - Lugo (RA) - Italy

Tel. +39 - 0545 35235

Fax +39 - 0545 32844

E-mail: deca@decaweb.it

www.decaweb.it

On behalf of:

aprilia s.p.a.

via G. Galilei, 1 - 30033 Noale (VE) - Italy

Tel. +39 - 041 58 29 111

Fax +39 - 041 44 10 54

www.aprilia.com

This manual contains all the main information and the

instructions required for normal use and mainte-

nance of your vehicle.

For controls and check-ups that cannot be carried out

easily with the standard equipment supplied, we ad-

vise you to consult our Dealers who can assure you

of quick and careful servicing.

To keep your aprilia vehicle always in perfect operat-

ing conditions, we advise you to insist on Original

Spares and to have repairs carried out only by aprilia

Authorized Outlets and Official Dealers.

When ordering spare parts from the Dealers, always

quote the spares code which is stamped on a sticker

placed under the saddle. It is a good idea to make a

note of the identification code in the space provided

in this manual, so that you will always have a record

of it even if the identification sticker comes off.

All information is purely indicative and may be sub-

ject to variation without notice.

Carefully observe the instructions preceded by the

following warning signs:

Safety norms and regulations to protect

the driver and other people from severe

injuries or grave risks.

Caution norms and suggestions to avoid

damaging the vehicle and/or hurting

yourself or other people.

Indications to make the operations easier.

Technical information.

CONTENTS

Pag.

CATALYTIC MUFFLER ............................................... 2

CATALYTIC SILENCER .............................................. 3

ARRANGEMENT OF THE CONTROLS.................... 18

INSTRUCTIONS FOR USE ....................................... 41

MAINTENANCE......................................................... 46

IDENTIFICATION DATA............................................ 49

ELECTRICAL SYSTEM ............................................. 68

CLEANING................................................................. 74

LONG INACTIVITY .................................................... 74

TECHNICAL FEATURES .......................................... 75

VERSION:

+Italy /Holland *Croatia

4United

Kingdom

6Switzerland #Australia

>Austria &Denmark RUnited States

of America

MPortugal ,Japan gBrazil

(Finland 2Singapore 1South Africa

$Belgium PSlovenia KNew Zealand

AGermany FIsrael %Canada

CFrance eSouth Korea

'Spain -Malaysia

)Greece @Chile

BASIC SAFETY RULES

To drive the vehicle it is necessary to be in posses-

sion of all the requirements prescribed by law (driving

licence, minimum age, psychophysical ability, insu-

rance, state taxes, vehicle registration, number plate,

etc.).

Gradually get to know the vehicle by driving it first in

areas with low traffic and/or private areas.

The use of medicins, alcohol and drugs or psychotro-

pic substances notably increases the risk of acciden-

ts.

Be sure that you are in good psychophysical condi-

tions and fit for driving and pay particular attention to

physical weariness and drowsiness.

Most road accidents are caused by the driver»s lack

of experience.

NEVER lend the vehicle to beginners and, in any ca-

se, make sure that the driver has all the requirements

for driving.

Rigorously observe all road signs and national and

local road regulations.

Avoid abrupt movements that can be dangerous

for yourself and other people (for example: rearing

up on the back wheel, speeding, etc.), and give

due consideration to the road surface, visibility

and other driving conditions.

Fig. 1

Fig. 2

Avoid obstacles that could damage the vehicle or

make you lose control.

Avoid riding in the slipstream created by preceding

vehicles in order to increase your speed.

Always drive with both hands on the han-

dlebars and both feet on the footrests (or

on the rider’s footboards), in the correct

driving posture.

Avoid standing up or stretching your lim-

bs while driving.

The driver should pay attention and avoid distrac-

tions caused by people, things and movements (ne-

ver smoke, eat, drink, read, etc.) while driving.

Use only the vehicle»s specific fuels and lubricants

indicated in the "LUBRICANT CHART"; check all

oil, fuel and coolant levels regularly.

Fig. 3

Fig. 4

If the vehicle has been involved in an accident, make

sure that no damage has occurred to the control le-

vers, pipes, wires, braking system and vital parts.

If necessary, have the vehicle inspected by an Con-

cessionario Ufficiale aprilia who should carefully

check the frame, handlebars, suspensions, safety

parts and all the devices that you cannot check by

yourself.

Always remember to report any malfunction to the te-

chnicians to help them in their work.

Never use the vehicle when the amount of dam-

age it has suffered endangers your safety.

Never change the position, inclination or colour of:

number plate, direction indicators, lights and horns.

Any modification of the vehicle will result in the invali-

dity of the guarantee.

Fig. 5

Fig. 6

A12

345

Any modification of the vehicle and/or the removal of

original components can compromise vehicle perfor-

mance levels and safety or even make it illegal.

We recommend respecting all regulations and natio-

nal and local provisions regarding the equipment of

the vehicle.

In particular, avoid all modifications that increase the

vehicle»s performance levels or alter its original cha-

racteristics.

Never race with other vehicles.

Avoid off-road driving.

CLOTHING

Before starting, always wear a correctly fastened

crash helmet. Make sure that it is homologated, in

good shape, of the right size and that the visor is cle-

an.

Wear protective clothing, preferably in light and/or re-

flecting colours. In this way you will make yourself

more visible to the other drivers, thus notably redu-

cing the risk of being knocked down, and you will be

more protected in case of fall.

This clothing should be very tight-fitting and fas-

tened at the wrists and ankles; strings, belts and

ties should not be hanging loose; prevent these

and other objects from interfering with driving by

getting entangled with moving parts or driving

mechanisms.

Fig. 7

Fig. 8

ONLY ORIGINALS

ACCESSORIES

The owner of the vehicle is responsible for the choi-

ce, installation and use of any accessory.

Avoid installing accessories that cover horns or lights

or that could impair their functions, limit the suspen-

sion stroke and the steering angle, hamper the ope-

ration of the controls and reduce the distance from

the ground and the angle of inclination in turns.

Avoid using accessories that hamper access to the

controls, since this can prolong reaction times during

an emergency.

Big fairings and windshields installed on the vehicle

may produce aerodynamic forces that affect the sta-

bility of the vehicle, especially when riding at high

speed.

Make sure that the equipment is well fastened to the

vehicle and not dangerous during driving.

Do not install electrical devices and do not modify

those already existing to avoid electrical overloads,

because the vehicle could suddenly stop or there

could be a dangerous current shortage in the horn

and in the lights.

aprilia recommends the use of genuine accessories

(aprilia genuine accessories).

Fig. 9

Fig. 10
