Archos 55b Platinum Manuale utente
1
Help & assistance
Congratulations for the purchase of an ARCHOS device! This quick start guide helps you
to start using your device properly. If you have more questions concerning the use of your
device, visit us at:
twitter.com/archos
www.facebook.com/archos
Blog https://blog.archos.com/
http://faq.archos.com/
www.archos.com, click Support > After-sales support
www.archos.com, click Support > Downloads > Declaration of conformity
As we are often updating and improving our products, your device’s software may have a slightly
different appearance or modified functionality than presented in this quick start guide.
2
Warranty
Unboxing
ARCHOS 55b Platinum
Quick start guide
Warranty, legal and safety notice
Charging cable
Charger adapter
3
Describing your device
Front camera Phone speaker
Headphone jack
Back camera
Flash light
ON/OFF
Volume
Back
Home
Recent apps
Loudspeaker
Micro-USB
port
4
After you have unpacked your mobile phone box:
1. Remove the device’s back cover using the notch.
2. Insert your SIM card or Memory card in the corresponding slot.
3. Insert the device’s battery.
4. Replace the back cover.
3G/2G slot 1 Micro-SIM
3G/2G slot 2 Mini SIM
Micro-SD card slot 3
When inserting your SIM card or micro-SD card,
make sure to follow the illustration, otherwise you
may damage the slot or the card.
THE MINI SIM SLOT IS BELOW THE MICRO-SIM SLOT.
Assembling
5
Charging your battery completely
Plug the charging cable in the Micro-USB port and the adapter in a power outlet.
Leave the device until the battery is fully charged.
Turning ON
1. Press and hold the ON/OFF button to turn on the device.
2. Follow the instructions to set up your device.
Activating mobile date connection (3G)
1. Touch and pull down the status bar to display it.
2. Touch again the bar to reveal the quick settings.
3. Select the Settings icon.
4. In Wireless & networks, select Data usage, then the SIM card tab.
5. Slide the Mobile data switch to turn on/off.
Activating WiFi connection
1. Touch and pull down the status bar to display it.
2. Touch again the bar to reveal the quick settings.
3. Select the WiFi icon to activate the WiFi connection .
4. Select “WiFi” below the WiFi icon.
5. Touch the name of network you want to connect to.
Private networks are shown with a lock icon and will require you to enter your
password.
Starting up
6
-My device is frozen: press the ON/OFF button for more than 10 seconds or remove and replace the
battery, then turn on the device.
-My device encounters dysfunctions: go to Settings > About phone > Check for update system to
check for updates. If your device is up-to-date, try to reset the device from Settings > Factory data
reset > Backup & restore. We recommend to save your files before resetting.
-My WiFi reception is too low: make sure you are not far from the WiFi hotspot. Update the firmware
of the device: http://www.archos.com/support. Reset and redefine your connection parameters.
Contact your WiFi connection provider.
-My device bootlogo is playing in a loop: you need to completely reset your device. Go to faq.archos.
com and select your device. In Backup & Recovery, select How to reinitialize my ARCHOS.
FOR MORE ANSWERS ABOUT YOUR TECHNICAL DIFFICULTIES, DO NOT HESITATE TO VISIT: FAQ.ARCHOS.
COM
Troubleshooting
7
Félicitations! Vous venez d’acquérir un appareil ARCHOS! Ce guide de démarrage rapide vous aide à
bien débuter l’usage de votre appareil. Si vous avez d’autres questions sur l’usage de votre appareil,
visitez nos liens ci-dessous :
twitter.com/archos
www.facebook.com/archos
Blog https://blog.archos.com/
http://faq.archos.com/
www.archos.com, click Support > After-sales support
www.archos.com, cliquez Support > Téléchargements > Déclaration de conformité
Comme nous mettons à jour et améliorons régulièrement nos produits, le logiciel de votre appareil
peut présenter une interface ou des fonctionnalités légèrement différentes de celles décrites dans
ce guide.
Contactez-nous
8
Warranty
Déballage
ARCHOS 55b Platinum
Guide d’utilisation rapide
Livret des garanties et des
mentions légales et sécuritaires
Câble de charge
Adaptateur
9
Description de l’appareil
Caméra avant Combiné
Prise jack
Caméra
arrière
Flash
ON/OFF
Volume
Retour
Accueil
Applications
récentes
Haut-parleur
Port
micro-USB
10
Insertion de cartes et de la batterie
Après avoir déballé le téléphone :
1. Enlevez la coque arrière en utilisant l’encoche.
2. Insérez votre carte SIM ou carte mémoire dans l’emplacement correspondant.
3. Insérez la batterie dans le téléphone.
4. Remettez en place la coque arrière.
3G/2G emplacement 1 Micro-SIM
3G/2G emplacement 2 Mini SIM
Carte micro-SD emplacement 3
Lorsque vous insérez une carte SIM ou une carte
micro-SD, conformez-vous au schéma pour ne pas
endommager la carte ou l’emplacement.
L’EMPLACEMENT MINI SIM EST SITUÉ EN-DESSOUS
DE L’EMPLACEMENT MICRO-SIM.
Assemblage
Downloading apps with Play store
1. Connect to Internet and select the Play Store app.
2. Add or create a Google account if necessary.
3. Search for apps to download.
