PAGE 1 • 2051101-INS-RA • 800.798.0813 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM

Notes and Maintenance

Before you begin installation, read all instructions thoroughly.

Proper tools will improve the quality of installation and reduce the time required.

For stainless steel, polish may be used to clear small scratches

and scuffs on the ﬁnish. Mild soap may be used also to clean the product.

For black ﬁnishes, mild soap may be used to clean the product.

Level of Difﬁculty

Easy

INSTALLATION MANUAL 2051101

Scan

for helpful

install tips

Product Image

Front Front

Rear Rear

Parts List

1Driver / left, running board

1Passenger / right, running board

2Mounting bracket, front

2Mounting bracket, middle

2Mounting bracket, rear

24 Hex head bolt, 8mm

24 Flat washer, 8mm

24 Lock washer, 8mm

12 Hex nut, 8mm

Tools Required

Ratchet Socket, 13mm

Extension

ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 800.798.0813 • 2051101-INS-RA • PAGE 2

Step 1

Starting on the driver-side, locate

the three mounting locations and the

front bracket for the driver side.

Step 2

Locate the front two threaded mounting

locations. Place the front bracket up to

the vehicle and secure it using two 8mm

hex bolts, two 8mm lock washers and

two 8mm ﬂat washers.

Step 3

Repeat step 2 to install the middle and

rear brackets over the mounting hole

locations from step 1.

Step 4

Remove the ﬂat washers, lock washers

and hex nuts from the running board.

Carefully place the running board

onto the mounting brackets.

Slide each hex bolt into the appropriate

slot on the mounting bracket.

PAGE 3 • 2051101-INS-RA • 800.798.0813 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM

Step 5

Attach the running board to the brackets

using six 8mm lock washers, six 8mm

ﬂat washers and six 8mm nuts.

Snug the hardware,

but do not fully tighten.

Step 6

Adjust the running board, centering

it between the front and rear wheel wells.

With the running board in position, it is

recommended that all brackets ﬁrst be

tightened to the vehicle, followed by the

running board connections.

Step 7

Repeat steps 1 through 6 on the

passenger side of the vehicle.

Congratulations on the installation

of your brand new ARIES AeroTread™

running boards.

With the running boards installed, periodic

inspections should be performed to ensure

all mounting hardware remains tight.

To protect your investment, see the

'Notes and Maintenance' section on the

ﬁrst page of this instruction manual.
