General
e BioComp-series bio boiler is economical, manageable and environmentally friendly. All
the boilers in the series are available as either right or left handed, with maintenance and ash
removal hatches in front. e boiler is equipped with an integrated ash chamber as standard.
e boiler can be equipped with Ariterm MultiJet-, BioJet- and HakeJet burners, or Axon-
pellet burner. e fuels that can be used with the boiler, depending on the burner, are wood
chip, pellet, sawdust etc.
e standard package of the BioComp -boiler includes an automatic convection part cleaning,
a flue gas fan and a plate heat exchanger with pump. e automatic convection part cleaning
significantly aids/reduces maintenance work required and guarantees good efficiency. e flue
gas fan ensures the required underpressure in the fire chamber. Large maintenance and cleaning
hatches facilitate the cleaning of the BioComp -boiler. Available accessories include e.g. fire
chamber ash screw and ash box.
This manual applies to models: Left Right
BioComp 40 kW 5033589 5033590
BioComp 60 kW: 5033591 5033592
BioComp 80 kW: 5033593 5033594
BioComp 120 kW: 5033595 5033596
BioComp 150 kW: 5033597 5033598
Special models
BioComp 200 kW: 5033614
BioComp 250 kW: 5033617
BioComp 300 kW: 5033619
Contents of delivery (Page 23)
e boiler delivery includes:
• Bio boiler with hatches
• Cleaning equipment
• Smoke duct and flue gas fan for 40 - 150 kW models
• Automatic convection cleaning
• Plate heat exchanger and pump for 40 - 150 kW models
Accessories:
• Arimatic 151 control centre for 40 - 150 kW models
• Arimatic 500 control centre for 200 - 300 kW models
• BioComp 40 -control (automatic cleaning, heat exchanger pump, flue gas fan)
• Fire chamber ash screw and ash box
• Fire chamber ash screw with extra length
• Secondary ash screw
• Convection part ash screw and ash box
• Electric resistance with thermostat 6 or 9 kW (to be installed on the boiler’s electric resis-
tance connection)
• Oil burner equipment (hatch set for BioComp 60 kW model)
• Axon/PX52 pellet burner equipment (hatch set for BioComp 40 model)
• BeQuem 40 pellet burner set BioComp 40 kW-malliin (burner flange)
• BioJet/HakeJet adapter flange (BioComp 60/80/120/150/200/250/300 -models)
