ARTHUR HOLM D1Twin Manuale utente

User Guide

Danish craftmanship

Mediterranean soul

Technology Serving Design

D1Twin

HDCP compliant retractable double sided motorised

solutions

TABLE OF CONTENTS

REGULATIONS AND SECURITY 5

SAFETY INSTRUCTIONS 5

SYSTEM DESCRIPTION 7

PACKING INSTRUCTIONS 10

CONTROLS 11

OSD MENU 13

ISD MENU 16

INPUT CONNECTORS 22

AHnet PROTOCOL 24

VIDEO SIGNALS 28

AHLink 29

INFORMATION ON DISPOSAL 32

WARRANTY TERMS AND CONDITIONS 33

WELCOME

Thank you very much for purchasing an Arthur Holm product.

Please, read these installation and operating instructions carefully and

keep them in a safe place for future consultations.

We remain at your entire disposal if you have any suggestions.

Henrik Holm

General Manager

[email protected]

ABOUT US

The Company

Arthur Holm has its origins in the Danish furniture designer Jorgen Alex

Jensen, who was active during the sixties and the seventies. His design

inspiration and his concept of ergonomics have been continued by his

family, the design force behind Arthur Holm product range. The result of

combining Scandinavian design tradition with Mediterranean creativity,

exibility and emotion is a wide product range built on more than 25 years

of craftsmanship.

Arthur Holm oers a professional product range where tomorrow’s

technology is shaped into valued materials with design exibility and

customisation, specially created to enhance communication and

collaboration in reception, conference and meeting areas.

The art of customisation

Arthur Holm oers a range of ingenious products whose designs are based

on quality materials and the latest technology. Products which endow

meeting and conference rooms with silent, ergonomic, innovative and

aesthetic solutions that integrate into the furniture, hang from the walls as

works of art or are used as interactive points of information.

The world of Arthur Holm

Arthur Holm oers a selection of unique, elegant, versatile, exible and

ergonomic products that are being used in meeting and conference

rooms, reception areas, auditoriums and public zones of leading

companies throughout the world.

The numbers speak for themselves! We currently own 33 product

patents,have presence in over 45 countries with products and solutions

inmore than 25,000 installations.

It will be our pleasure to work with you, designing your unique and

personalised environment. Our broadcast electronic engineers will

provide the latest technology while our design team will oer you the most

exclusive appearance.

Our team puts its heart, passion and pride in all our designs.

SAFETY INSTRUCTIONS

Plugs

• Do not dismantle any part of the monitor power connector.

• Disconnect the power plug from the AC outlet when the monitor is not

going to be used for an indenite period of time.

Power and extensions cords

• Use the appropriate power cord with the correct plug type.

• Do not overload wall outlets or power cords.

• Make sure the total ampere passed through an extension cord does not

exceed the maximum allowed by the cable used.

• Do not place anything on the power cord.

• Do not locate this product where a person may walk or trip over the

cord.

REGULATIONS AND SECURITY

ATTENTION: Do not disassemble or modify the device in any way. This

symbol warns of the presence of dangerous un-insulated voltages inside

some of the components, of sucient magnitude to expose people to risk

of electronic shock.

This symbol draws attention to important use and maintenance instructions

in the manual that accompanies the unit.

This symbol indicates that the equipment conforms to the norms

established by the European Community.

This symbol indicates D.C. current.

Wiring connected to hazardous voltage requires installation by qualied

personnel or the use of ready-made exible cables.

For your security, your equipment must be connected to an electrical out-

let with grounding connection protection.

Since the plug is used to disconnect the device, the operating electrical

outlet must be in an easily accessible place.

Environment

• Install the equipment on an elevated, at surface.

• Install the equipment in a ventilated area.

• Avoid exposing the equipment to:

∙ Rain or water

∙ Excessive heat, cold or humidity

∙ Area exposed to direct sunlight

∙ Dirty areas

∙ Equipment generating strong magnetic elds

• Avoid placing open containers of liquid, near the equipment.

• Keep a minimum distance of 30 mm in order to have good ventilation.

• Never place above the device any sources of ames such as lighted

candles, etc.

• If you are using the device in extreme weather conditions and/or

tropical climates, the equipment should be installed in a room which

ensures a reasonable level of temperature and humidity.

• To prevent damage the equipment must be rmly anchored to the

surface, as shown on the installation instructions.

SAFETY INSTRUCTIONS

SYSTEM DESCRIPTION

General

Dynamic1Twin is a vertically retractable monitor with a double screen.

2 monitors are placed back to back in a compact anodised aluminium

frame to display different content for a 2 way communication. It is

designed for reception desks, information counters or meeting and

conference room tables with limited space. The screens are only visible

when required, disappearing inside the table desk when not needed by

simply pressing a button or by remote control.

Dynamic1Twin has an extremely fast lift system with a very low noise

level. Very easy to install, these monitors require no maintenance. To

protect the user, these monitors are equipped with a safety system

which stops the movements in case of resistance detection. They are

remotely controllable and diagnosable through the ERT interfaces in an

very easy and cost effective way.

Highlights

• Double sided display

• Passive cover plate

• Interactive Setup Display

• Maintenance free

• Energy saving design

• Safety system

• Serial control & Remote diagnostic

• Wireless connectivity for setup and control

SYSTEM DESCRIPTION

Available Models

MODEL DESCRIPTION

AH17D1HDA2F

HDCP compliant vertically retractable double Full

HD 17,3" monitor to be integrated into furniture. Solid

aluminium monitor housing in natural anodised nish

and up-table cover plate made of brushed stainless

steel. DVI-I and DVI-D inputs per each monitor (2).

Interactive Setup Display allowing the control, setup

and diagnose of the monitors. Monitors provide RS-

422 I/O allowing the remote control of movements,

speeds, safety settings, brightness, contrast and

backlight. The monitors are equipped with AH-AMMC:

an auto mechanical movement calibration system.

AH19D1HDA2F

HDCP compliant vertically retractable double Full

HD 18,5" monitor to be integrated into furniture. Solid

aluminium monitor housing in natural anodised nish

and up-table cover plate made of brushed stainless

steel. DVI-I and DVI-D inputs per each monitor (2).

Interactive Setup Display allowing the control, setup

and diagnose of the monitors. Monitors provide RS-

422 I/O allowing the remote control of movements,

speeds, safety settings, brightness, contrast and

backlight. The monitors are equipped with AH-AMMC:

an auto mechanical movement calibration system.

AH22D116A2F

HDCP compliant vertically retractable double Full

HD 21,5" monitor to be integrated into furniture.

Solid aluminium monitor housing in natural anodised

nish and up-table cover plate made of brushed

stainless steel. DVI-I and DVI-D inputs per each

monitor (2). Interactive Setup Display allowing the

control, setup and diagnose of the monitors. Monitors

provide RS-422 I/O allowing the remote control

of movements, speeds, safety settings, brightness,

contrast and backlight. The monitors are equipped

with AH-AMMC: an auto mechanical movement

calibration system.

Box Contents

Before the installation of your retractable monitor, please check the

contents of the shipping box, it must contain the following items:

• Monitor

• Power cord

• Remote control (1 per 5 monitors)

• Power supply 100-2 40Vac, 50-60Hz. Output 12V

• User guide

Important note: This device can only work with the power supply

included in the shipping box. This power supply can not be replaced by

any other rather than the original one.

Connections

Before connecting the power:

1. Install the unit on a table or desk, in vertical position.

2. Open the hatch and remove the two foam protection pieces.

Power connection:

1. Plug the power cable from the power supply into an AC socket of

100-240 Vac, 50-60Hz.

2. Plug the 12V D.C. cable into the socket on the unit.

Caution! Never place this monitor in horizontal position.

SYSTEM DESCRIPTION

PACKING INSTRUCTIONS
