Ascom i75 VoWiFi Handset

Features

• VoWiFi Handset with voice, personal alarm

and messaging functions

• Robust

• Large, mechanically protected, and scratch-

proof display

• Illuminated display

• Headset connector

• Push button alarm

• No-movement and man-down as option

• Time and date indication

• Vibrator alert

• Ring signal easily silenced

• Two different text sizes

• Identity and personal settings stored in hand-

set

• Up to 10 modes with personalized settings

• 3 programmable soft keys for each mode

• 10 programmable hot keys

• Sending/receiving messages

• Voice mail indication1

• Manual or automatic keypad lock

• Field upgradable firmware

• Shared phone, supports virtual SIM

• Verified compliance with Cisco Systems, Inc.

Cisco Compatible Extension, (CCX version 2)

Technical Specifications

Physical

Dimension (l × w × d): 134 × 60 × 27

Weight: 145 g (standard battery included)

Material: Case: PC/ABS and TPE (free from silicone and latex)

Keypad: PC/ABS, illuminated by white LEDs

Colour: Dark grey and Dark steel blue (Protector)

Light grey and Dark steel blue (Medic Protector)

Display (w × h): 128 × 64 pixel LCD, illuminated by white LEDs

Clip: Hinge type (standard) or swivel type

Environmental

Operating temperature: 0°C – +40°C

Storage temperature: -20°C – +70°C

Charging temperature: ≥ +5ºC

Volume

Ring signal: Adjustable in 5 steps + silent (approx. 100 dB @ 10 cm)

Earpiece: Adjustable in 10 steps

1 System dependent (refers to the voice mail indication feature )

TD 92318GB

2006-12-05/ Ver. C

Battery

Type: 1000 mAh or 1800 mAh (Li-Ion)

Speech time1/ stand-by time: Up to 10/40 h (1000 mAh)

Up to 18/60 h (1800 mAh)

Charging time: 2 – 4 h (1000 mAh)

3 – 6 h (1800 mAh)

Connectors

Headset connector: Contact dealer for information of headset

Battery connector: For battery charging

Settings

Languages: 11 (Danish, Dutch, English, Finnish, French, German, Italian,

Norwegian, Portuguese, Spanish, and Swedish)

Local Phonebook

Maximum name length: 22 characters

Maximum number length: 22 digits

Entries: 100

Telephony

Indication: Display, Ring signal (5 different), flashing LED, and vibrator

Answer call: Button press or automatically

Call list storage capacity: 20 received, dialled and missed calls with time stamp

Protocol: H.323 with Supplementary Services H.450.1, H.450.2,

H.450.3, H.450.4, H.450.6, H.450.7, H.450.8 and H.450.9

SIP supporting RFC1889, RFC2327, RFC2833, RFC3261,

RFC3264, RFC3265, RFC3515 and RFC3842

Messaging

Message length: System dependent

Storage capacity: 20 messages (maximum 20000 characters)

Alarm

Location types: Associated WLAN access point as standard

Alarm types: 2 push button alarms

No-movement and/or Man-down as option

WLAN

Number of subscriptions: 4 systems, manual selection

Quality of Service (QoS): WMM, 802.11e

Supported networks: 802.11b/g

Security

802.11i

Encryption methods: 64/128 bits WEP

TKIP

AES-CCMP

1 Dependent of Active mode, PS-Poll mode, U-APSD WLAN environment and configuration (refers to the speech time)

TD 92318GB

2006-12-05/ Ver. C

Authentication methods: 802.1X

Original 802.11 open/shared key authentication

WPA-PSK

WPA2-PSK

LEAP

PEAP-MSCHAPv2

EAP-MD5

Roaming enhancement

Pre-authentication

PMKSA cashing

CCKM

Endurance

Enclosure protection: IP40, EN 60529

Free fall test: IEC 60068-2-32 Ed procedure 1, Dropped 12 times from 1.5 m

Compliance to European regulations and standards

EU directives: 73/23/EEC(LVD), 89/336/EEC(EMC) and

1999/5/EC (R&TTE)

Product marking:

RF Spectrum: EN 300 328

SAR (Specific Absorption Rate): EN 50360,

Normal operation 0.0196 W/kg (10 gram)

Safety: EN 60950-1

EMC: EN 301 489-17 and EN 301 489-1

Compliance to US regulations and standards

Product marking: FCC ID: BXZKATY

US: 9FVISNANKATY

HAC

RF Spectrum: FCC CFR 47 Part 15, paragraph 15.247

SAR (Specific Absorption Rate): FCC/OET Bulletin 65

Supplement C (2001) and IEEE Std.

1528-2003, December 2003 /

ANSI/IEEE Std. C95.1-1999

Normal operation 0.036 W/kg (1 gram)

Body worn operation 0.117 W/kg (1 gram)

Safety: IEC 60950-1, CB Bulletin No. 107A, May 2004

EMC: FCC Part 15 Class B

Hearing aid: 47 CFR Part 68, Subpart D and TIA-968-A

Compliance to Canadian regulations and standards

Product marking: IC:3724B-KATY

RF Spectrum: RSS-210

SAR (Specific Absorption Rate): IEEE Std C95.3-1999

Normal operation 0.036 W/kg (1 gram)

Body worn operation 0.117 W/kg (1 gram)

Safety: IEC 60950-1

CB Bulletin No. 107A, May 2004

Hearing aid: CS-03

TD 92318GB

2006-12-05/ Ver. C

Specifications are subject to change without notice.

Functions

Vibrator

Microphone on/off during call

Loudspeaking

Headset connector

Messaging

Acknowledge

Interactive messaging

Group messaging

Voice mail

Datasend

Datawith prefix

Personal alarm

Alarm with data

Automaticcall after alarm

Acousticlocation signal (ALS)

Push-button alarm

Location, access points

Man-down & No-movement alarm

Availability information/Absence

Field upgradable software

* System dependent feature

Yes

Yes*

Yes

Option

Yes

i75 Protector / Medic Protector
