USER
GUIDE
CAMPUS 300
801.250B
USG/300/AE-B
12.05.95
Not the actual front page
USER
GUIDE
CAMPUS 300
USER GUIDE LCD PANEL
2
USER GUIDE LCD PANEL
3
TABLE OF CONTENTS
INTRODUCTION..................................................................................... 5
MAIN FEATURES.................................................................................... 5
SUPPLIED MATERIAL............................................................................. 6
SETTING UP THE LCD PANEL............................................................... 7
COMPUTER............................................................................... 8
USING THE LCD PANEL......................................................................... 9
REMOTE CONTROL.................................................................. 9
CONNECTORS.........................................................................11
LOCKING THE PANEL..............................................................11
FEATURES ............................................................................................12
PRACTICAL HINTS AND TIPS ...............................................................15
MAINTENANCE......................................................................................17
SERVICE................................................................................................17
TECHNICAL DATA.................................................................................18
CONNECTORS......................................................................................21
FCC STATEMENT..................................................................................22
ENVIRONMENTAL STATEMENT............................................................23
SERVICE INFORMATION.......................................................................24
CONNECTION LAYOUT.........................................................................25
(Foldout Page)
USER GUIDE LCD PANEL
4
1
This publication is printed on recycled paper.
The information contained in this user guide is preliminary, and the products described
herein are subject to change without prior notice.
The symbols and are used in this publication to indicate
Warning and Note respectively.
USER GUIDE LCD PANEL
5
2INTRODUCTION
This LCD Data panel is a state of the art projection device that can be
connected to most computers.
Applications include presentations, software training, educational use,
advertising, information boards and other situations where a small or large
audience shares information.
3MAIN FEATURES
-2.1 million colors
-VGA and MAC compatible
-User settings memorized
-Correct VGA text
-Infrared remote control
-Housing footprint fits OHP glass exactly
-Low weight
-Dual Safecool system
-False light blocking
-4 meters Y cable
USER GUIDE LCD PANEL
6
4SUPPLIED MATERIAL
A complete set includes the following components :
1. LCD Data Panel 6. Power Cable
2. VGA Cable 7. Remote Control
3. Cable-Adapt. MAC mon 8. Batteries
4. Cable-Adapt. MAC comp. 9. Box
5. Power -5, 12, 5 V 10. User Guide
USER GUIDE LCD PANEL
7
5SETTING UP THE LCD PANEL
Switch off all equipment before connecting the components. Be aware of
static electricity that may build up, especially in the dry season and when
operating on synthetic carpets. Discharge any static electricity by touching
a metallic surface before you start.
Place the LCD panel on top of a transmissive overhead projector (OHP).
Select a high intensity type projector, for instance 400 W halogen or metal-
halide. Best results are obtained in a dimmed room with no direct sunlight
shining in.
The following are guidelines for first time set-up:
Connect the cables and power supply as described in the rear foldout page
(see Connection Layout).
Attach power to the LCD panel, turn the overhead projector and computer
on. For more information on set-up see the following sections on
Computer.
USER GUIDE LCD PANEL
8
5.1 COMPUTER
Connect the LCD panel, computer, monitor and power supply as shown in
the rear foldout.
Connect cable (1) between the LCD panel and the computer. Use the Y-
split on the computer end to connect the monitor.
If you have a Macintosh computer, insert applicable adapters (2) and (3)
as shown.
Connect the power supply to the LCD panel (4).
TO SET UP FROM THE REMOTE CONTROL:
STEP OPERATION
1Press RESET for default settings
2Adjust TUNE for a stable image. *)
3Position the image correctly using the four POSITION keys
5Adjust CONTRAST and BRIGHTNESS as desired
*) If a stable image is not achieved using TUNE, try to adjust the
BRIGHTNESS/CONTRAST setting as described later.
USER GUIDE LCD PANEL
9
6USING THE LCD PANEL
The LCD panel has a set of connectors that you need to know in order to
operate the device correctly.
6.1 REMOTE CONTROL
The infrared remote control (RC) is the main user interface to the device.
The RC is used to set the LCD panel correctly (to get the best possible
viewing conditions) and to control the presentation.
The figure shows the different keys of the remote control.
* Grey area does not apply for this product.
Set-up should be done once with the application(s) you are running most
frequently. Allow some minutes for the equipment to warm up before
adjusting. Most settings will automatically be memorized individually for
each source for future use.
