Asko HG1615ab Manuale utente

Instructions for use

Gas hob

HG1615ab / HG6ABE1A

HG1675sb / HG6ABE1B

EN Manual EN 3 - EN 9

Pictograms used:

Important information

Tip

EN 3

OPERATION

Description

Ignition and adjustment

1. zone indication

2. 0 position

3. High setting

4. Low setting

Each burner is fully adjustable between high and low settings.

• Press the control knob and turn it anticlockwise. The burner will ignite.

• Keep the control knob fully depressed for at least 3 seconds

between high and low settings. The thermocouple safety pilot has

been activated.

1. standard burner

2. rapid burner

3. simmer burner

4. pan support

5. glass top or stainless steel

drip tray

6. control knob

Top view of appliance

EN 4

Use

Pans

• Always ensure than the flames stay under the pan. A lot of energy

is lost if flames burn around the pan. The handles may also become

too hot.

• Do not use pans with a base diameter smaller than 12 cm. Smaller

pans are not as stable.

Pan support

Place the pan supports vertically, without sliding over the drip tray. Use

the leads to position the pan supports on the drip tray.

Small pan grid

The small pan grid supplied or obtainable as an accessory makes it

possible to use very small pans.

Burner

Use the leads (1) to put together the burner parts.

OPERATION

error

good

small pan grid

EN 5

MAINTENANCE

Maintenance

Regular maintenance after use prevents spilt food from setting too long

and creating stubborn stains. Use a mild detergent for this. First clean

the control knobs, burners and pan supports and only then the drip tray

or glass cover. This prevents the drip tray or glass cover to becoming

dirty again after cleaning.

Please note! Do not clean burner parts in the dishwasher. Dishwasher

detergent can corrode burner parts!

Persistent stains on enamel (pan supports, burner caps)

Persistent stains can best be removed with a fluid detergent or a plastic

scouring sponge. Never use scouring powder, scouring pads, sharp

objects or aggressive cleaning products.

Persistent stains on the glass cover

Clean the glass cover with a special cleaning product for ceramic hobs.

Water stains or limescale are best cleaned using cleaning vinegar.

Persistent stains on the stainless steel (drip trays)

Persistent stains on stainless steel are best removed with a special

stainless steel cleaning product. Always wipe with the structure of the

steel to prevent scraping away the protective layer (damage caused

in this way does not fall under the guarantee!) The surface of stainless

steel drip trays can discolour slightly over time.

Consult the www.asko.com website for additional maintenance

and cleaning instructions!

EN 6

ERRORS

Fault list

If your gas hob does not work properly, this does not always mean that

it is defective. Try to deal with the problem yourself first by checking

the points below or check the ‘www.asko.com' website for more

information.

SYMPTOM POSSIBLE CAUSE SOLUTION

You smell gas near

the appliance.

The appliance connection

is leaking.

Close the main gas switch. Contact the your

installer.

A burner does not

ignite.

Plug not in socket.

Fuse defective/fuse

switched off in fuse

cupboard.

Spark plug (1) dirty/damp.

Burner parts not placed

correctly.

Burner parts dirty/damp.

Main gas tap closed.

Fault in gas mains.

Gas bottle or tank is empty.

Wrong type of gas used.

Put the plug into the socket.

Put in a new fuse or switch on the fuse in the

fuse box.

Clean/dry the spark plug.

Use the centring leads to put the burner parts

together.

Clean/dry the burner parts. Make sure that

the outflow holes are open.

Open the main gas tap.

Consult you gas supplier.

Connect a new gas bottle or have the tank

refilled.

Check whether the gas used is suitable for

the appliance. Contact your installer if it is not

correct.

The burner does not

burn evenly.

Burner parts not placed

correctly.

Burner parts dirty/damp.

Wrong type of gas used.

Use the centring leads to put the burner parts

together.

Clean/dry the burner parts. Make sure that

the outflow holes are open.

Check whether the gas used is suitable for

the appliance. Contact your technician if it is

not correct.

Burner extinguishes

after igniting.

The control knob has not

been depressed long or

deep enough (at least

3 seconds).

Thermocouple (2) is dirty.

Keep the control knob fully depressed for

at least 3 seconds between high and low

settings. This can take longer the first time

because of the gas supply.

Clean/dry thermocouple.

EN 7

ERRORS

SYMPTOM POSSIBLE CAUSE SOLUTION

Timer indicates

error code F0 – F6

(if present).

There is an object, water or

dirt on the buttons. Button

used for too long.

Ensure that there is nothing on the buttons.

Ensure that the buttons are clean and there is

no water on them.

Contact the technician if the error code does

not disappear.

Ceramic glass plate

broken.

Object fallen onto it. Close the gas main switch and pull the plug

out of the socket. Contact the your installer.

Please note! Do not throw a broken

ceramic glass plate in the glass recycling

bin but take this to the Municipality's

waste recycling centre.

EN 8

ENVIRONMENTAL CONSIDERATIONS

Disposal of the appliance and packaging

Sustainable materials have been used during manufacture of this

appliance.

The appliance packaging is recyclable. The following may have been

used:

• cardboard;

• paper;

• polyethylene film (PE);

• CFC-free polystyrene (PS-rigid foam);

• polypropylene tape (PP).

Dispose of these materials in a responsible manner and in accordance

with government regulations.

To designate the requirement for separate collection of household

electrical appliances, the symbol of a crossed-out dustbin is applied to

the product.

This means that at the end of its working life, the product must not

be disposed of as urban waste. It must be taken to a special local

authority differentiated waste collection centre or to a dealer providing

this service. Disposing of a household appliance such as this hob

separately avoids possible negative consequences for the environment

and health and enables the constituent materials to be recovered,

resulting in significant savings in energy and resources.

Please note! Do not throw a broken ceramic glass plate in the glass

recycling bin but take this to the Municipality's waste recycling

centre.

Declaration of conformity

We hereby declare that our products satisfy the applicable European

directives, orders and regulations, as well as the requirements stated in

the referenced standards.

EN 9

ENVIRONMENTAL CONSIDERATIONS

Information according regulation (EU) 66/2014

Measurements according EN 30-2-1

Model identification HG1615ab HG1675sb

Type of hob

Number of gas burners 4 4

Energy efficiency per gas burner

(EEgas burner) in %

1 = 61.5

3 = 62.1

4 = 62.1

1 = 61.5

3 = 62.1

4 = 62.1

Energy efficiency for the gas hob

(EEgas hob) in % 61,9 61,9

Gas hob

EN 10
