Asus Zenfone Max M1 Manuale utente
User Guide
15060-0JL00100
E14051
Revised Edition / March 2018
Model: ASUS_X00PD (ZB555KL)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the complete E-Manual and more
detailed information, refer to https://www.asus.
com/support/.
Front features
Receiver
Front camera
Touch screen
display
Flash
LED indicator
Proximity
sensor and
light sensor
Side features
Front camera
Audio jack
Power
key
Nano SIM1, Nano
SIM2, Micro SD
card slot
Eject hole
Volume
key
Speaker
Microphone
Micro USB port
Microphone
Rear features
Flash
Rear camera
Fingerprint
sensor
Charging your ASUS Phone
To charge your ASUS Phone:
1. Connect the USB connector into the power
adapter’s USB port.
2. Connect the other end of the USB cable to your
ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Forsafetypurposes,useONLY the bundled power
adapter and cable to avoid damaging your device
and prevent the risk of injury.
• Forsafetypurposes,useONLY the bundled power
adapter and cable to charge your ASUS Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
of the USB cable is +5V 2A, 10W.
IMPORTANT!
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the USB cable to
your computer’s USB port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC (95oF).
3
1
2
Installing a Nano SIM/ microSD
card
To install a Nano SIM/ microSD card:
3. Push the tray to close it.
1. Push the bundled eject pin into the hole on the
card slot to eject the tray out.
2. Insert the Nano SIM or microSD card into the
appropriate slot.
IMPORTANT! When two SIM cards are inserted, only
oneSIMcardslotsupports4G/3G/2Gservice.Theother
SIM card slot only supports 2G/3G service.
CAUTION!
• Donotusesharptoolsorsolventonyourdeviceto
avoid scratches on it.
• UseonlyastandardNanoSIMcardonyourASUS
Phone.
NOTES:
• TheNanoSIMcardslotssupportGSM,WCDMA,
FDD-LTE,andTDD-LTEnetworkbands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHC card formats.
Federal Communications
Commission Statement
Thisdevicecomplieswithpart15oftheFCCRules.
Operation is subject to the following two conditions:
(1)Thisdevicemaynotcauseharmfulinterference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changesormodicationsnotexpresslyapprovedby
the party responsible for compliance could void the
user‘s authority to operate the equipment.
Thisequipmenthasbeentestedandfoundto
comply with the limits for a Class B digital device,
pursuanttopart15oftheFCCRules.Theselimits
are designed to provide reasonable protection
against harmful interference in a residential
installation.Thisequipmentgenerates,usesandcan
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
- Consultthedealeroranexperiencedradio/TV
technician for help.
Theantenna(s)usedforthistransmittermustnotbe
co-located or operated in conjunction with any other
antenna or transmitter.
Thecountrycodeselectionisfornon-USmodels
only and is not available to all US models. Per FCC
regulation, all WiFi products that are marketed in US
mustbexedtoUS-operatedchannelsonly.
TheresponsiblepartywithintheUSAper47CFR
Part2.1077(a)(3):
ASUS COMPUTER INTERNATIONAL (America)
Address: Corporate Way, Fremont, CA 94539, USA
Telephone:+1-510-739-3777
RF Exposure Information (SAR)
Thisdevicehasbeentestedandmeetsapplicable
limitsforRadioFrequency(RF)exposure.
SpecicAbsorptionRate(SAR)referstotherateat
which the body absorbs RF energy. SAR limits are
1.6 Watts per kilogram (over a volume containing
a mass of 1 gram of tissue) in countries that follow
the United States FCC limit and 2.0 W/kg (averaged
over 10 grams of tissue) in countries that follow the
CounciloftheEuropeanUnionlimit.TestsforSAR
are conducted using standard operating positions
withthedevicetransmittingatitshighestcertied
power level in all tested frequency bands.
ToreduceexposuretoRFenergy,useahands-free
accessory or other similar option to keep this device
away from your head and body. Carry this device
at least 15 mm away from your body to ensure
exposurelevelsremainatorbelowtheas-tested
levels. Choose the belt clips, holsters, or other
similar body-worn accessories which do not contain
metallic components to support operation in this
manner. Cases with metal parts may change the RF
performance of the device, including its compliance
withRFexposureguidelines,inamannerthat
hasnotbeentestedorcertied,andusesuch
accessories should be avoided.
ThehighestFCCSARvaluesforthedeviceareas
follows:
• 0.72W/Kg@1g(Head)
• 1.19W/Kg@1g(Body)
TheFCChasgrantedanEquipmentAuthorization
for this device with all reported SAR levels evaluated
asincompliancewiththeFCCRFexposure
guidelines.SARinformationonthisdeviceisonle
with the FCC and can be found under the Display
Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: MSQX00PD.
Canada, Industry Canada (IC)
Notices
ThisdevicecomplieswithIndustryCanada’s
licence-exemptRSSstandard(s).Operationis
subject to the following two conditions:
(1) Thisdevicemaynotcauseinterference;and
(2) Thisdevicemustacceptanyinterference,
including interference that may cause
undesired operation of the device.
LeprésentappareilestconformeauxnormesCNR
d’IndustrieCanadaapplicablesauxappareilsradio
exemptsdelicence.Sonutilisationestsujetteaux
deuxconditionssuivantes:
(1) Cet appareil ne doit pas créer d’interférences
nuisibles, et
(2) Cet appareil doit tolérer tout type
d’interférences, y compris celles susceptibles
de provoquer un fonctionnement non souhaité
de l’appareil.
