1 Getting to know your wireless

router

1.1 Welcome!

Thank you for purchasing an ASUS BRT-AC828/M2 Wireless Router!

The ultra-thin and stylish BRT-AC828/M2 features 2.4GHz and

5GHz dual bands for an unmatched concurrent wireless HD

streaming; SMB server, UPnP AV server, and FTP server for 24/7

le sharing; a capability to handle 300,000 sessions; and the ASUS

Green Network Technology, which provides up to 70% power-

saving solution.

1.2 Package contents

NOTES:

• Ifanyoftheitemsisdamagedormissing,contactASUSfortechnical

inquiries and support, Refer to the ASUS Support Hotline list at the

back of this user manual.

• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture

warranty services such as repair or replacement.

BRT-AC828/M2 Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

Support CD (Manual)

1.3 Your wireless router

Power LED

O: No power.

On: Device is ready.

Flashing slow: Rescue mode

LAN 1~8 LED

O: No power or no physical connection.

On: Has physical connection to a local area network (LAN).

2.4GHz LED

O: No 2.4GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

5GHz LED

O: No 5GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

WAN (Internet) LED

Red: No IP or no physical connection.

On: Has physical connection to a wide area network (WAN).

Failover LED

O: Failover feature is disabled.

On: Failover feature is enabled.

Flashing: Failover feature is functioning.

SSD LED

O: No SSD device connected.

Flashing: SSD devices are running.

USB LED

O: No USB device connected.

Flashing: USB devices are running.

NOTES:

• Useonlytheadapterthatcamewithyourpackage.Usingother

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +19V with max 2.37A/3.42A current

Operating

Temperature 0~40oCStorage 0~70oC

Operating Humidity 50~90% Storage 20~90%

USB unmount button

Press this button to safely remove the USB device.

USB 3.0 port

Insert USB 3.0 devices such as USB hard disks or USB flash drives into this port.

WAN (Internet) ports

Connect a network cable into these ports to establish WAN connection.

WPS button

This button launches the WPS Wizard.

LAN 1 ~ 8 ports

Connect network cables into these ports to establish LAN connection.

Power button

Press this button to power on or off the system.

Power (DC-IN) port

Insert the bundled AC adapter into this port and connect your router to a power source.

1.4 Positioning your router

For the best wireless signal transmission between the wireless

router and the network devices connected to it, ensure that you:

• Placethewirelessrouterinacentralizedareaforamaximum

wireless coverage for the network devices.

• Keepthedeviceawayfrommetalobstructionsandawayfrom

direct sunlight.

• Keepthedeviceawayfrom802.11gor20MHzonlyWi-Fi

devices, 2.4GHz computer peripherals, Bluetooth devices,

cordlessphones,transformers,heavy-dutymotors,fluorescent

lights, microwave ovens, refrigerators, and other industrial

equipment to prevent signal interference or loss.

• Alwaysupdatetothelatestfirmware.VisittheASUSwebsiteat

http://www.asus.com to get the latest firmware updates.

• Toensurethebestwirelesssignal,orientthefourdetachable

antennas as shown in the drawing below.

45°45°

1.5 Setup Requirements

To set up your wireless network, you need a computer that meets

the following system requirements:

• EthernetRJ-45(LAN)port(10Base-T/100Base-TX/

1000BaseTX)

• IEEE802.11a/b/g/n/acwirelesscapability

• AninstalledTCP/IPservice

• WebbrowsersuchasInternetExplorer,Firefox,Safari,or

Google Chrome

NOTES:

• Ifyourcomputerdoesnothavebuilt-inwirelesscapabilities,youmay

install an IEEE 802.11a/b/g/n/ac WLAN adapter to your computer to

connect to the network.

• Withitsdualbandtechnology,yourwirelessroutersupports2.4GHz

and 5GHz wireless signals simultaneously. This allows you to do

Internet-related activities such as Internet surng or reading/writing

e-mail messages using the 2.4GHz band while simultaneously

streaming high-denition audio/video les such as movies or music

using the 5GHz band.

• SomeIEEE802.11ndevicesthatyouwanttoconnecttoyournetwork

may or may not support 5GHz band. Refer to the device's manual for

specications.

• TheEthernetRJ-45cablesthatwillbeusedtoconnectthenetwork

devices should not exceed 100 meters.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Asus Router di rete

Asus

Asus DSL-AC68VG Manuale utente

Asus

Asus RT-AC88U Manuale utente

Asus

Asus WL-700GE - Wireless Router Manuale utente

Asus

Asus RT-G32 - Wireless Router Manuale utente

Asus

Asus BLUE CAVE AC2600 Manuale utente

Asus

Asus RT-AC66U Foglio di istruzioni

Asus

Asus RT-AX95U Manuale utente

Asus

Asus RT-N11 Manuale utente

Asus

Asus RT-AC57U Manuale utente

Asus

Asus RT-AC68U Manuale utente

Asus

Asus RT-AC2900 Manuale utente

Asus

Asus AX5400 Manuale utente

Asus

Asus RX3041 Manuale utente

Asus

Asus XT8 Manuale utente

Asus

Asus RT-AC66U Manuale utente

Asus

Asus RT-AX3000 V2 Manuale utente

Asus

Asus WL-AM604 Manuale utente

Asus

Asus RT-AX68U Manuale utente

Asus

Asus RT-AC1200 Manuale di istruzioni

Asus

Asus ZenWiFi AC Mini CD6 Series Manuale utente

Asus

Asus RT-AX86U Manuale utente

Asus

Asus RT-AX1800U Manuale utente

Asus

Asus ZenWiFi Pro ET12 Manuale utente

Asus

Asus RT-AC1500G PLUS Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
