Asus RT-AC2900 Manuale utente
Quick Start Guide
RT-AC2900
Wireless-AC2900 Dual band
Gigabit Router
U13201-1 / First Edition / July 2017
WEU13201_RT-AC2900_booklet_QSG.indb 1 2017/8/15 12:07:28
Table of contents
Package contents....................................................................... 3
A quick look at your router ..................................................... 3
Preparing your modem............................................................ 4
Setting up your router.............................................................. 5
A. Wired connection .............................................................................5
B. Wireless connection ........................................................................6
Remembering your wireless router settings ................... 8
FAQ .................................................................................................. 8
Networks Global Hotline Information ..............................75
English
Dansk
Nederlands
Français
Deutsch
Italiano
Suomi
Ελληνικά
Norsk
Português
Español
Svenska
This QSG contains these languages:
WEU13201_RT-AC2900_booklet_QSG.indb 2 2017/8/15 12:07:28
English
3
A quick look at your router
NOTE: If any of the items is damaged or missing, contact your retailer.
Package contents
RT-AC2900 Wireless Router 3 * wireless antennas
AC adapter Network cable (RJ-45)
Quick Start Guide
1. LAN LED 8. Power (DC-IN) port
2. WAN (Internet) LED 9. USB 2.0 port
3. 2.4GHz / 5GHz Wi-Fi LED 10. USB 3.0 port
4. Power LED 11. WAN (Internet) port
5. WPS button 12. LED On/O button
6. Wi-Fi On/O button 13. LAN ports
7. Power button 14. Reset button
WEU13201_RT-AC2900_booklet_QSG.indb 3 2017/8/15 12:07:29
English
4
Preparing your modem
1. Unplug the power cable/DSL modem. If it has a battery
backup, remove the battery.
NOTE: If you are using DSL for Internet, you
will need your username/password from your In-
ternet Service Provider (ISP) to properly congure
the router.
2. Connect your modem to the router with the bundled
network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to ensure the
connection is active.
Unplug
WEU13201_RT-AC2900_booklet_QSG.indb 4 2017/8/15 12:07:29
English
5
Setting up your router
You can set up your router via wired or wireless connection.
A. Wired connection
1. Plug your router into a power
outlet and power it on. Connect the
network cable from your computer
to a LAN port on your router.
RT-AC2900
1
Internet
Modem
4
3
WAN
2
LAN
Laptop
NOTES:
• Useonlytheadapterthatcamewithyourpackage.Usingotheradaptersmay
damage the device.
• Specications:
DC Power adapter DC Output: +19V with max. 1.75A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
WEU13201_RT-AC2900_booklet_QSG.indb 5 2017/8/15 12:07:30
English
6
B. Wireless connection
1. Plug your router into a power
outlet and power it on.
RT-AC2900
Laptop
Tablet
Smart phone
1
Internet
Modem
3
2
WAN
2. The web GUI launches automatically when you open a web browser. If it does not
auto-launch, enter http://router.asus.com
3. Set up a password for your router to prevent unauthorized access.
WEU13201_RT-AC2900_booklet_QSG.indb 6 2017/8/15 12:07:30
English
7
2. Connect to the network name(SSID) shown on the product label on the back side
of the router. For better network security, change to a unique SSID and assign a
password.
ASUS router
2.4G Wi-Fi Name (SSID): ASUS_XX_2G
5G Wi-Fi Name (SSID): ASUS_XX_5G
* XX refers to the last two digits of 2.4GHz MAC
address. You can nd it on the label on the
back of your router.
3. Once connected, the web GUI launches automatically when you open a web
browser. If it does not auto-launch, enter http://router.asus.com.
4. Set up a password for your router to prevent unauthorized access.
WEU13201_RT-AC2900_booklet_QSG.indb 7 2017/8/15 12:07:30
English
8
Remembering your wireless router settings
• Rememberyourwirelesssettingsasyoucompletetheroutersetup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
FAQ
1. Where can I nd more information about the wireless router?
•OnlineFAQsite:http://support.asus.com/faq
•Technicalsupportsite:http://support.asus.com
•Customerhotline:refertotheSupportHotlinesectioninthisQuickStartGuide
WEU13201_RT-AC2900_booklet_QSG.indb 8 2017/8/15 12:07:30
9
Dansk
Et hurtigt kik på din router
BEMÆRK: Du bedes venligst kontakte din forhandler, hvis nogen af dele-
ne mangler eller er beskadiget.
Pakkens indhold
RT-AC2900 3 * trådløse antennaer
vekselstrømsadapteren Netværkskabel (RJ-45)
Kvikstartguide
1. LAN LED 8. Strøm (DC-IN) port
2. WAN-indikator (Internet) 9. USB 2.0 port
3. Wi-Fi-indikator for 2,4 GHz/5 GHz 10. USB 3.0 port
4. Strøm LED 11. WAN-port (Internet)
5. WPS knap 12. LED til/fra-knap
6. Wi-Fi til/fra-knap 13. LAN porte
7. Strøm knap 14. Nulstillingsknap
WEU13201_RT-AC2900_booklet_QSG.indb 9 2017/8/15 12:07:31
10
Dansk
1. Afbryd ledningen/DSL-modemmet. Hvis enheden
indeholder et batteri, skal dette tages ud.
BEMÆRK: Hvis du bruger DSL til dit internet, skal
du bruge dit brugernavn/adgangskode fra din
internetudbyder (ISP) for at kongurere routeren.
2. Tilslut modemmet til routeren med den medfølgende
netværkskabel.
Forberedelse af dit modem
Unplug
3. Tænd din kabel/DSL-modem.
4. Hold øje med lysindikatorerne på dit kabel/DSL-
modem, for at sikre at forbindelsen er aktiv.
WEU13201_RT-AC2900_booklet_QSG.indb 10 2017/7/25 14:16:56
