Asus DSL-AX82U Manuale utente

Quick Start Guide

DSL-AX82UDSL-AX82U

AX5400 WiFi VDSL/ADSLAX5400 WiFi VDSL/ADSL

Modem RouterModem Router

A16649 / First Edition / July 2020

Table of contentsTable of contents

English�� 3

繁體中文 �� 8

Bahasa Indonesia��13

Bahasa Melayu��18

ไทย��23

Tiếng Việt��28

English

A quick look at your routerA quick look at your router

NOTE: If any of the items is damaged or missing, contact your

retailer�

Package contentsPackage contents

VDSL/ADSL Wireless Modem

Router Power adapter

Network cable (RJ-45 cable) Quick Start Guide

Splitter (varies with region) DSL/phone cable (RJ-11

cable)

Warranty card

1� Power LED 8� DSL port

2� WiFi LED 9� USB 3�1 Gen 1 port

3� LAN LED 10� LAN 1~4 ports

4� DSL/WAN LED 11� WAN port

5� Aura LEDs/WPS/WiFi combo

button 12� Power switch

6� Aura LEDs 13� Power (DCIN) port

7� Reset button

2346789 10 11 12 13

English

Setting up your xDSL routerSetting up your xDSL router

1� Insert your xDSL modem router’s

power adapter to the DCIN port and

plug it to a power outlet�

2� Connect one end of the RJ-11 cable

to the DSL port of your xDSL modem

router, and connect the other end to

the DSL port of your splitter�

3� Turn on your xDSL modem router and

wait for a few minutes for Internet

connection�

4� You can set up your router via wired or wireless connection�

• [Via Wired Connection]

Connect your computer to the router using a wired Ethernet cable�

• [Via Wireless Connection]

Connect to the wireless network with SSID shown on the product

label on the back side of the router�

5� When DSL/WAN LED stops ashing and lights constantly, you can

start the DSL setup process via the QIS Wizard (Quick Internet Setup

Wizard)�

a� Open a web browser and enter http://router�asus�com to launch the

web GUI� Follow onscreen instructions to complete the setup�

b� You can also choose ASUS Router app to

set up your router� Download ASUS Router

App to set up your router via your mobile

devices�

Laptop

Tablet

Smart phone

DSL-AX82U

Power 1

Wall telephone outlet

Splitter

Phone

DSL

Line

Wall Power Outlet

Laptop

LAN

ASUS Router

ASUS

Router

English

NOTES:

• Use only the adapter that came with your package� Using other

adapters may damage the device�

• Specications:

DC Power adapter DC Output: +12V with max� 2�5A current

Operating Temperature 0~40oC Storage 0~70oC

Operating Humidity 50~90% Storage 20~90%

NOTES:

• You can use either xDSL Modem or Ethernet WAN for Internet access�

• The default username and password for Web GUI are admin and

admin�

• The auto-detection of your ISP connection type takes place when you

congure your xDSL modem router for the rst time or when your

router is reset to its default settings� During the QIS process, you may

need to key in the Internet account information that you obtained

from your Internet Service Provider (ISP)�

English

LED indications

LEDs Indications

Power LED Color: White and red�

O: No power�

Solid white: Device is working normally�

Solid red: Device is working abnormally�

Flashing red slowly: Rescue mode�

Flashing white slowly: WPS or rmware upgrade in

progress�

WiFi LED

Color: White�

O: No WiFi signal�

On: Wireless system is ready�

Flashing: Transmitting or receiving data via wireless

connection�

LAN LED

Color: White�

O: No data activity or no physical connection�

On: Ethernet connection is established�

DSL/WAN

LED

Color: White and red

O: Both DSL and WAN cables are unplugged�

Flashing red slowly: DSL is attempting to connect to

a DSLAM�

Solid red: Device is ready for conguration but

Internet connection has not been

established yet�

Solid white: Internet connection is established�

English

Button Functions

AURA LEDs/

WPS/WiFi

combo button

Press the button on the top cover for about 2 seconds

to perform any of the following actions.

• Turning on or o the Aura LEDs (Default)

Press for 1 second to change the Aura lighting eects.

• Starting the WPS process

• Turning on or o the WiFi connection

Note: You can change the button function by going to

Administration > System from the web GUI�

Button function

FAQFAQ

1� Where can I nd more information about the wireless router?

• Technical support site: https://www�asus�com/support

• You can get the user manual online at https://www�asus�com/support

繁體中文

認識您的無線路由器認識您的無線路由器

注意： 若以上列出的任何一項配件有毀損或是短缺的情形，

請儘速聯絡您的經銷商。

產品包裝內容產品包裝內容

VDSL /ADSL 無線數據路由器電源變壓器

RJ-45 網路線快速使用指南

分離器 (視地區而定) DSL / 電話線 (RJ-11)

保固卡

1. 電源指示燈 8. DSL 連接埠

2. WiFi 指示燈 9. USB 3.1 Gen 1 連接埠

3. LAN 指示燈 10. LAN (1~4) 連接埠

4. DSL/WAN 指示燈 11. WAN 連接埠

5. Aura 指示燈 / WPS 和 WiFi

組合按鈕 12. 電源開關

6. Aura 指示燈 13. 電源（DCIN）連接埠

7. 重置按鈕

2346789 10 11 12 13

繁體中文

設定您的 xDSL 路由器設定您的 xDSL 路由器

1. 將 xDSL 無線數據路由器的電源變

壓器插入電源（DCIN）插孔，並連

接至電源插座。

2. 將 RJ-11 線的一端插入 xDSL 無線

數據路由器的 DSL 連接埠，另一端

連接至分離器的 DSL 連接埠。

3. 開啟 xDSL 無線數據路由器，等待幾

分鐘直到連線至網際網路。

4. 您可以透過有線或無線兩種方式設

定您的無線路由器。

• [透過有線連線]

使用網路線連接電腦與路由器。

• [透過無線連線]

連接到路由器後側標籤上註明的網路名稱（SSID）。

5. 當 DSL/WAN 指示燈停止閃爍，轉為恆亮時，即可透過網路設定

精靈（QIS）進行 DSL 設定。

開啟網頁瀏覽器並在地址欄中鍵入 http://repeater.asus.com 以開啟

網頁介面（web GUI）。請依照螢幕提示完成設定。

b. 您可以透過 ASUS Router App 設定您

的路由器。透過行動裝置下載 ASUS

Router App 以設定您的路由器。

Laptop

Tablet

Smart phone

DSL-AX82U

Power 1

Wall telephone outlet

Splitter

Phone

DSL

Line

Wall Power Outlet

Laptop

LAN

ASUS Router

ASUS

Router

繁體中文

注意：

• 請僅使用包裝中的電源變壓器。使用其他類型的電源變壓器可能會

造成裝置損毀。

• 規格：

直流電源變壓器 DC 輸出： +12V 電壓，支援最大 2.5A 電流

運作溫度 0~40°C 儲存溫度 0~70°C

運作濕度 50~90% 儲存濕度 20~90%

注意：

• 您可以使用 xDSL 數據機或有線乙太網路來存取網際網路。

• 預設的網頁介面（web GUI）登入名稱和密碼為 admin / admin。

• 自動偵測 ISP 連線類型會在您第一次設定 xDSL 數據機路由器時，

或重置路由器為預設設定後出現。進入網路設定精靈（QIS）後，

您需要輸入從網際網路服務供應商（ISP）處獲得的網際網路帳戶

資訊。
