AT&T Definity 6402D Manuale utente

555-540-702

Issue 1

1989

AT&T System 25

Single-Line Telephone

User Guide

Printed in USA

TO ORDER COPIES OF THIS DOCUMENT REFER TO DOCUMENT

NUMBER 555-540-702.

Contact:

Call:

Write:

Your AT&T sales representative, or

800-432-6600, Monday to Friday between 7:30 am

and 6:00 pm EST.

In Canada call: 800-255-1242, or

AT&T Customer Information Center

2855 North Franklin Road

P.O. Box 19901

Indianapolis, Indiana 46219

Every effort was made to ensure that the information in this document

was complete and accurate at the time of printing. However, this

information is subject to change. This document will be reissued

periodically to incorporate changes.

Single-Line Telephone User Guide

Prepared by the

Technical Publications Group

Contents

Introduction

Single-Line Features

Account Code Entry

Call Accountability

Call Waiting

Callback

Conference Calls

Direct Group Calling (DGC)

Following

Forwarding

Hold

Leave Word Calling

Message Waiting

Night Service

Paging

Park

Pickup

Placing Calls

Programming Speed Dialing Codes

Speed Dialing

Transfer

Glossary

Introduction

This guide describes the features available to you from AT&T

System 25 through a single-line telephone and provides

instructions for using the features. For your convenience, the

features are arranged in alphabetical order.

Your telephone is ready to use as soon as it is connected to the

System 25. Therefore, as you learn to use the features, you can

make and receive calls with your telephone just as you would

with an ordinary phone.

System 25 supports both touch-tone and rotary sets. However,

if you have a rotary set, you will not be able to use the features

that require you to enter a “*” or “ #” character.

Features

Your AT&T System 25 has two types of features: fixed and

assignable.

A fixed feature is one that is provided on every

single-line telephone. (In this guide, fixed features are indicated

at the beginning of a feature description by a box with a check.)

An assignable feature is not provided automatically. It must be

“assigned” by your System Administrator. (In this guide,

assigned features are indicated at the beginning of a feature

description by an empty box.)

✔fixed feature

assignable feature

Check with your System Administrator as to which features have

been assigned to you. (As a reminder, you can place a check in

the box of each assignable feature as you receive it.)

The Switchhook

The switchhook is the button held down by the handset when it

rests in the cradle on your telephone. Some System 25 features

require that you use the switchhook to signal the system.

When you are instructed to press the switchhook, press the

button down as far as it will go for approximately 1/2 second and

then release it. If the switchhook is released too soon, the signal

will not work. If you hold the switchhook down for too long

your call will be disconnected.

If you want to hang up and place another call right away, be

sure to hold down the switchhook for more than two seconds.

NOTE: If you have a RECALL or FLASH button on your

telephone, you can press it instead of the switchhook.

The RECALL or FLASH buttons cannot be used to disconnect a

call.

Ringing Tones

System 25 signals you with three distinctive rings. The rings

and their descriptions are listed below.

INSIDE CALL IIIIIIIIIIIIIIIIIIII (one long ring)

Your call is from a person inside your company.

OUTSIDE CALL IIIII IIIII (two short rings)

Your call is from the attendant or someone outside your

company.

PRIORITY RING IIIII IIIII IIIIIIIIII (two short rings and one long ring)

You are being alerted that your request for Callback can now be

completed; or a call is being set up remotely for your phone via

a data feature known as Third-Party Call Setup.

Handset Tones

System 25 signals you with tones that are heard through the

handset. The tones and their descriptions are listed below.

DIAL TONE lllllllllllllllllllllllllllllllllllllllllllllllllIll (a continuous steady tone)

You can dial.

CONFIRMATION TONE II II II (three short tones)

Your action has been accepted.

RINGBACK TONE IIIIIIIIIIIIIII IIIIIIIIIIIIIII (repeating on/off tone)

The number you dialed is ringing.

SPECIAL RINGBACK TONE IIIIIIIIIIIIIIIII II (one long tone and

one short, dull tone)

The person you dialed is busy, and has been notified of Call

Waiting.

BUSY TONE IIIII IIIII IIIII (repeating on/off tone)

The number you dialed is busy.

FAST BUSY TONE Ill Ill Ill Ill (fast repeating on/off tone)

The number you dialed was busy, misdialed, or restricted.

CALL WAITING TONE (short tone(s) heard during a call)

III

(the waiting call is an inside call)

III III (the waiting call is an outside call)

You have a call waiting to be answered.

QUEUEING TONE II II II II II (five short tones)

Your request for a callback has been confirmed.

DEQUEUEING TONE II II II (three short tones)

The extension or outside line that you requested for callback is

now available.

Data Dial Code (DDC)

When your System 25 was installed, Data Dial Codes (DDCSs)

were assigned to data terminals. If you have a data terminal

associated with your System 25, you will receive separate

information regarding its use.

Personal Dial Code (PDC)

Personal Dial Codes (PDCs) were assigned to telephones. In

most cases, your PDC is your extension number. If a telephone

is shared by two or more people, each person may have been

assigned their own “floating” extension number (FPDC).

Additional Information

See your System Administrator if you have any questions or

would like additional information about your System 25 features.

Single-Line Features

Account Code Entry

For bookkeeping purposes, your System Administrator may

assign account codes to use with certain calls. If you are

required to use account codes for outgoing calls, the account

code must be entered before you can place an outgoing call. If

this feature is not mandatory, you may still use the Account

Code Entry feature.

See your System Administrator to verify the types of calls, if

any, for which you must enter an account code.

Account Code Entry - Outgoing Calls

Listen for dial tone, then press * 0 .

❑ ❑

Dial the account code.

NOTE: If you make a mistake while entering the account

❑ ❑

code, press * 0 again, then the correct account code.“

Listen for dial tone.

Dial the outside line access code and listen for dial tone

again.

Dial the telephone number.

(Continued)

Account Code Entry (Continued)

Account Code Entry - Incoming Calls

Your call will be disconnected when you follow this procedure.

Therefore, do not attempt it until you have finished your

conversation.

After you have completed your conversation, and before you

hang up, press the switchhook.

Listen for confirmation tone and dial tone.

Dial * 0 .

❑ ❑

Dial the account code.

NOTE: If you make a mistake while entering the account

code, dial * 0 again and then the account code.

❑ ❑

Listen for confirmation tone, then hang up.

Call Accountability

You can use your own extension number at any other extension

to place toll calls that should be billed to you.

Billing Calls to Your Extension

1 Listen for dial tone, then press # # .

❑ ❑

2 Dial your extension number.

3 Listen for dial tone, then dial the telephone number.

NOTE: If you make a mistake, hang up and restart the

sequence.
