AT&T E2520 Manuale utente

Quick Start Guide

2.4 GHz Cordless

Speakerphone E2520

with Caller ID & Call Waiting

E2520 QSG.qxd 07/19/2004 3:21 PM Page 1

Installation and setup

Connect the base and install batteries as shown below. After installation, place the

handset in the base and allow the batteries to charge for 8 hours before use. You can

keep the batteries charged by returning the handset to the base after each use.

Press coin into slot on

base of handset to

release latch, then

remove battery cover.

Insert supplied

batteries.

Place handset in base to charge

for 8 hours before first use.

Rotate antenna to fully upright

position.

Insert top

tab first.

To replace battery cover

Press down to

click in place.

Caution: Use only the supplied NiCd battery or

AT&T model 2AA NiMH replacement battery

(SKU 26820). Do not use alkaline batteries.

Plug power cord

transformer into

electrical outlet.

Plug long tele-

phone line cord

into telephone jack.

Route cords through

slot in base.

E2520 QSG.qxd 07/19/2004 3:21 PM Page 2

HANDSET 1

REDIAL MEMMENU

Off/Clear

During a call, press to hang up.

While using menus, press to cancel an

operation, back up to the previous

menu, or exit the menu display.

Quick reference guide

Speaker

Press to activate handset speaker-

phone. Press again to switch call back

to earpiece.

Softkeys

Press a softkey to select a menu item

displayed just above the key.

Phone/Flash

Press to begin a call, then dial a number.

During a call, press to receive an incoming

call, if Call Waiting is activated .

Sound Select

Press to customize the sound at the ear-

piece for clear conversations.

Handset

Xfer/Intercom

Press to transfer a call or initiate an

intercom conversation .

Redial Log Phonebook

Screen menus

Item 1 Item 2 Item 3

Menus

Main Menu

Calls Log

Handset Settings

Set Time

Clock Mode

Base settings from handset

Handset Settings

Ringer Volume

Ringer Melody

Low Batt Tone

Range Tone

Keypad Tone

Contrast

Language

Base Settings from

handset

Tone/Pulse

Ringer Melody

E2520 QSG.qxd 07/19/2004 3:21 PM Page 3

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones. Printed in China. Issue 1 AT&T 06/04.

96-005768-010-000

Quick reference guide

Telephone function keys

INTERCOM ............

Press to transfer a call or initiate an intercom conversation.

FLASH ....................During a call, press to receive an incoming call, if

Call Waiting is activated.

VOLUME ................Press to adjust speakerphone listening volume.

MUTE ......................Press to silence microphone; press again to resume.

SPEAKERPHONE....

Press to turn speakerphone on or off (answer or end a call).

REDIAL ..................Press to redial the last number.

HOLD ......................

Press to hold a call, press again to release hold.

Base/Speakerphone

Telephone

function keys

Swivel antenna fully

upright for best results.

E2520 QSG.qxd 07/19/2004 3:21 PM Page 4
