AT&T E5865 Manuale utente
Quick reference guide
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones.
Answering system controls
ON/OFF ..................Press to turn answering system on or off.
DELETE ..................Press to delete message currently playing.
TIME SET................Press to set the answering system clock.
MENU......................Press to review or change answering system options.
CHANGE ................Press to change a menu option.
RECORD ................Press to record a memo or outgoing announcement.
Telephone function keys
SOFTKEYS ............Press to select menu item displayed just above the key.
CLEAR ....................Press to cancel an operation, back up to the
previous menu, or exit the menu display.
INTERCOM ............
Press to transfer a call or initiate an intercom conversation.
FLASH ....................During a call, press to receive an incoming call, if
Call Waiting is activated.
VOLUME ................Press to adjust speakerphone listening volume.
MUTE ......................Press to silence microphone; press again to resume.
SPEAKERPHONE ..Press to turn speakerphone on or off (begin or end a call).
Base/Speakerphone
Answering
system
controls
Telephone
function keys
Swivel antenna fully
upright for best results.
REDIAL MENU MEM
Press to play or stop playing messages.
Press to repeat message.
Press twice to hear
previous message.
Press to skip to next
message.
ATT-5865QSG-d3.qxd 1/18/2004 5:26 PM Page 1
Quick Start Guide
5.8 GHz Cordless
Speakerphone/
Answering System E5865
with Caller ID & Call Waiting
ATT-5865QSG-d3.qxd 1/18/2004 5:26 PM Page 2
Installation and setup
Connect the base and install batteries as shown below. After installation, place the
handset in the base and allow the battery to charge for 12 hours before use. You can
keep the battery charged by returning the handset to the base after each use.
Place handset in base to charge
for 12 hours before first use.
Rotate antenna to fully upright
position.
Press coin into slot on
base of handset to
release latch, then
remove battery cover.
Insert supplied
batteries.
Insert top
tab first.
To replace battery cover
Press down to
click in place.
Plug power cord
transformer into
electrical outlet. Plug long telephone
line cord into
telephone jack.
Route cords through
slot in base.
Caution: Use only the supplied
NiMH battery (80-5461-00-00) or
AT&T model 2AA NiMH replace-
ment battery (SKU 26820). Do not
use alkaline batteries.
ATT-5865QSG-d3.qxd 1/18/2004 5:26 PM Page 3
Quick reference guide
NavKey
Press center button to display menus.
Press NavKey buttons to navigate
through menus. Press center button to
select menu item highlighted.
Speaker
Press to activate handset speaker-
phone. Press again to switch call back
to earpiece.
Softkeys
Press a softkey to select a menu item
displayed just above the key.
Off/Cancel
During a call, press to hang up.
While using menus, press to cancel an
operation, back up to the previous menu,
or exit the menu display.
Phone/Flash
Press to begin a call, then dial a number.
During a call, press to receive an incoming
call, if Call Waiting is activated.
Sound Select
Press to customize speaker sound for
clear speakerphone conversations.
Handset
Intercom
Vibrate Ringer Control Ringers
Low Batt Tone Keypad Tone Range Tone
Clock On/Off Set Time Contrast
Phone Setup Language Reset Settings
Directory Calls Log Pictures Sounds&Alerts Settings
Main menu
Sounds & Alerts menu Settings menu
Left Right
Select
Up
Down
ATT-5865QSG-d3.qxd 1/18/2004 5:26 PM Page 4
