ATEN VE156 Manuale utente
VGA/DVI/HDMI over Cat 5 Extender Wall Plate
VE156 / VE606 / VE806
User Manual
www.aten.com
VE156 / VE606 / VE806 User Manual
ii
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
Warning: Operation of this equipment in a residential environment could cause radio
interference.
Suggestion: Shielded twisted pair (STP) cables must be used with the unit to ensure
compliance with FCC & CE standards.
Achtung: Der Gebrauch dieses Geräts in Wohnumgebung kann Funkstörungen
verursachen.
KCC Statement
RoHS
This product is RoHS compliant.
VE156 / VE606 / VE806 User Manual
iii
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS
CORRECT BEFORE USE.
International http://eservice.aten.com
International 886-2-8692-6959
China 86-400-810-0-810
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1-949-428-1111
VE156 / VE606 / VE806 User Manual
iv
Package Contents
The VGA/DVI/HDMI over Cat 5 Extender Wall Plate package contains the
following items:
1 VE156T / VE606T / VE806T VGA/DVI/HDMI over Cat 5 Extender
Wall Plate
1 VE156R / VE606R / VE806R VGA/DVI/HDMI over Cat 5 Extender
Wall Plate
1 Terminal Block Connector
1 Power Adapter
1 User Instructions*
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
*Features may have been added to the VE156 / VE606 / VE806 since this
manual was published. Please visit our website to download the most up-to-
date version.
© Copyright 2020 ATEN® International Co., Ltd.
Manual Date: 2020-08-05
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
VE156 / VE606 / VE806 User Manual
v
Contents
EMC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
RoHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front View (Transmitter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front View (Receiver) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rear View (Transmitter / Receiver) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2. Hardware Setup
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Before Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wall Box Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to Supply Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3. Basic Operation
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Picture Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Appendix
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
International. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Supported ATEN Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
VE156 / VE606 / VE806 User Manual
vi
About this Manual
This User Manual is provided to help you get the most from your system. It
covers all aspects of installation, configuration and operation. An overview of
the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the VE156 / VE606 / VE806
system. Its purpose, features and benefits are presented, and its front and back
panel components are described.
Chapter 2, Hardware Setup, describes how to set up your installation. All
necessary steps to prepare for operation are provided.
Chapter 3, Basic Operation, describes how to adjust the picture quality.
An Appendix, provides specifications and other technical information
regarding the VE156 / VE606 / VE806.
VE156 / VE606 / VE806 User Manual
vii
Conventions
This manual uses the following conventions:
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
Reseller. Visit ATEN on the Web for a list of locations and telephone numbers:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential steps.
→Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start
→
Run means to
open the Start menu, and then select Run.
Indicates critical information.
International http://www.aten.com
North America http://www.aten-usa.com
VE156 / VE606 / VE806 User Manual
viii
This Page Intentionally Left Blank
1
Chapter 1
Introduction
Overview
The VGA/DVI/HDMI over Cat 5 Extender Wall Plate extends VGA/DVI/
HDMI and audio signals up to 150 m (for VE156) / 60 m (for VE606 / VE806)
using Cat 5e cables. It supports popular wide screen formats and ensures
excellent video quality over long distance transmissions. The VE156 / VE606
/ VE806, in combination with other ATEN devices such as VGA/DVI/HDMI
extenders and MDS solutions, can further extend the distance or multiply A/V
sources/displays.
The VE156 / VE606 / VE806 can be powered at either the Transmitter or
Receiver side, and uses a second Cat 5e cable to transmit the power signal to
the other unit. The compact wall plate design does away with bulky cables and
allows a neat and convenient installation. It is an ideal solution for function
rooms, museums and any environment that requires equipment or cabling to be
kept hidden from public view.
VE156 / VE606 / VE806 User Manual
2
Features
Uses two Cat 5e cables to connect the local and remote units – one to
transmit video and audio; and another for power*
Remotely powered from either the Transmitter or Receiver side**
Extends the distance between VGA/DVI/HDMI source and VGA/DVI/
HDMI display
Superior video quality – VE156: up to 1920 x 1200 @60Hz (30 m), 1280 x
1024 @ 60Hz (150m); VE606 / VE806: 1080p @ 60Hz (40m), 1080i @
60Hz (60m)
Adjustable Video Compensation Control – manually adjusts signal
strength to compensate for distance (VE156)
8-segment equalization adjustment switch optimizes display quality
(VE606 / VE806)
Compatible with existing ATEN VGA/DVI/HDMI extenders – see
page 18 for more information
Supports wide screen formats
Supports hot-plugging
Decora type design is easily configurable to fit various wall plates
HDMI (3D, Deep Color); HDCP compatible (VE806)
LED indication of power sources / connection status
Supports stereo audio
Built-in 8KV/15KV ESD protection
A neat and cleaner installation via easy wall-mounting
Plug-and-play – no software installation required
Note: * The second Cat 5e cable connection is required to remotely power on
either the Transmitter or Receiver. For VE606 / VE806, it is also
required for real EDID Bypass and HDCP key authentication.
** A power adapter is provided with this package, and can be used at
either the Transmitter or Receiver side, which in turn remotely powers
the other unit. See How to Supply Power, page 8.
Questo manuale è adatto per i seguenti modelli
8
Indice
Altri manuali ATEN Estensione
ATEN
ATEN ProXime CE750 Manuale utente
ATEN
ATEN VE600A Manuale utente
ATEN
ATEN ProXime CE750 Manuale utente
ATEN
ATEN VANCRYST VE066T Manuale utente
ATEN
ATEN VE1830T Manuale utente
ATEN
ATEN CE100 Manuale utente
ATEN
ATEN VanCryst CE820 Manuale utente
ATEN
ATEN UEH4002 Manuale utente
ATEN
ATEN Altusen KA-9250 Manuale utente
ATEN
ATEN CE624 Manuale utente
