ATEN VanCryst VS481A Manuale utente
VS481A
USER MANUAL
HDMI Switch
FCC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own
expense.
FCC Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's authority
to operate this equipment.
CE Warning: Operation of this equipment in a residential
environment could cause radio interference.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Achtung: Der Gebrauch dieses Geräts in Wohnumgebung kann
Funkstörungen verursachen.
KCC Statement:
RoHS
This product is RoHS compliant.
- 3 -
VS481A User Manual
Online Registration
Telephone Support
Technical Support
For international online technical support – including
troubleshooting, documentation, and software updates:
http://support.aten.com
For North American technical support:
International http://support.aten.com
International 886-2-8692-6959
China 86-400-810-0-810
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1-949-428-1111
Email Support [email protected]
Online
Technical
Support
Troubleshooting
Documentation
Software Updates
http://www.aten-usa.com/support
Telephone Support 1-888-999-ATEN ext 4998
- 4 -
Package Contents
The VS481A HDMI Switch package contains the following items:
1 VS481A HDMI Switch
1 IR Remote Control Unit
1 Power Adapter
1 Standard HDMI Cable (1.8 m)
1 User Instructions*
Check to make sure that all the components are present and that
nothing got damaged in shipping. If you encounter a problem,
contact your dealer.
Read this manual thoroughly and follow the installation and
operation procedures carefully to prevent any damage to the unit,
and/or any of the devices connected to it.
*Features may have been added to the VS481A since this
manual was printed. Please visit our website to download the
most up-to-date version of the manual.
Copyright © 2008 – 2020 ATEN
®
International Co., Ltd.
Manual Part No. PAPE-1286-AT3G
Printing Date: 2020-06-19
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.
- 5 -
Overview
With more and more HDMI devices entering the Home Theater
market, the need for simultaneous access to different HDMI A/V
sources is becoming increasingly important. Now, the VS481A
HDMI Switch offers an easy and affordable way to add HDMI
capabilities to your home theater system by allowing you to
switch easily between up to four HDMI A/V sources that are
connected to your HDMI display.
With four HDMI A/V input ports, the VS481A HDMI Switch allows
you to connect four HDMI devices (such as an HD camcorder or
satellite box, HD-DVD player, hi-def Blu-ray player, home theater
PC, stand-alone streaming media player, or gaming console) to
your HDMI monitor, display, projector or TV at the same time. The
remote control and convenient front panel pushbuttons allow you
to quickly and easily toggle between A/V sources, while the front
panel LEDs indicate the source device at a glance.
For your convenience, the VS481A has a single input port
mounted on the front panel for connecting mobile or temporary
devices, such as digital cameras, while your permanent device
connections are out of sight on the rear of the unit.
Furthermore, for complete system and install integration, RS232
control is standard through the VS481A’s built-in bi-directional
RS-232 serial remote port that allows the switch to be controlled
through a high-end controller, PC, and/or home automation /
home theater software package.
- 6 -
Features
Allows up to four HDMI A/V sources to be connected to one
HDMI display
Toggle between A/V sources using remote control or front
panel pushbuttons
Supports high-resolution video – HDTV resolutions of 480p,
720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA
(1600x1200), and WUXGA (1920 x 1200)
Supports Dolby True HD and DTS HD Master Audio
HDMI (3D, Deep Color)
Up to 60 Hz refresh rate
Long-distance transmission – up to 15 m (24 AWG)
Built-in bi-directional RS-232 serial remote port for high-end
system control
Plug-and-play – no software installation required
DDC compatible
HDMI and HDCP compatible
Signaling rates up to 2.25 Gbits in support of 1080p display
All-metal casing
LED indication of A/V source devices
Power On Detection – if one of the HDMI source devices is
powered off, the VS481A will automatically switch to the next
powered on device
Easy and affordable way to add four HDMI inputs to your
home theater system
- 7 -
System Requirements
Source Device(s)
HDMI Type A output connector(s)
Note: A DVI/HDMI adapter is required when connecting a DVI
source device.
Display Device
A display device or receiver with an HDMI Type A input
connector
Cables
4 HDMI cables
Note: 1. Not all cables are included in this package. We strongly
recommend that you purchase high-quality cables of
appropriate length since this will affect the quality of the
audio and video display. Contact your dealer to
purchase the correct cable sets.
2. If you wish to utilize the VS481A’s high-end serial
controller function, you will also need to purchase an
appropriate RS-232 cable. See Installing the RS-232
Controller, page 11.
- 8 -
Components
VS481A Front View
No. Component Function
1 HDMI In Plug the cable from an HDMI source
device into this port (number 4).
2 Port Selection
Pushbuttons
Pressing a port selection pushbutton
routes the A/V source from the
corresponding input port to the output port
for display.
3 IR Receiver This receives signals from the IR remote
control.
4 Port LEDs There are two port LEDs next to each port
selection pushbutton.
The ON LINE LED (top, orange) lights
up to indicate that the device attached
to the corresponding port is powered
on.
The SELECTED LED (bottom, green)
lights up to indicated that the port is
selected.
2
4
31
A
1234
- 9 -
VS481A Rear View
No. Component Function
1 Power Jack The power adapter cable plugs in here.
2 HDMI Out The cable from the HDMI display device
plugs in here.
3 HDMI In The cables from the HDMI source devices
can plug into any of three available ports.
4 RS-232 Serial
Port
This is the serial remote port for input
source selection and high-end system
control.
3
21 4
HDMI IN
HDMI IN HDMI IN
HDMI OUT
32
1
- 10 -
IR Remote Control
No. Component Function
1 Port Up / Port
Down Buttons
Press the Port Up button to cycle forward
through the source devices (1 to 2; 2 to 3; 3 to
4; 4 to 1).
Press the Port Down button to cycle backward
through the source devices (4 to 3; 3 to 2; 2 to
1; 1 to 4).
2 Port Selection
Buttons
Press a button to bring the focus directly to the
source device attached to its associated port.
1
2
