OVERVIEW - Continued
In STANDARD TEMPERATURE MODE, the instrument
functions like a normal thermometer. In ITS™Mode, the
instrument operates with the Intelligent Temperature
Stabilization™ feature. The 353 series instrument has a
unique feature to display temperature of item being
measured when the temperature has reached its final
stabilized temperature. The purpose of this feature is to
assist the user in determining when the final stabilized
temperature has been reached.The ITS feature is
dynamic, in that it operates continuously in real time. It
can be used in ITS Mode with the option of recording
stabilized temperature readings or simply as a
thermometer with ITS functionality. The MEMORY MODE
is for viewing ITS temperature data stored in memory
and you can scroll in both directions. The key
easily allows the user to select desired mode of
operation.
STANDARD TEMPERATURE MODE:
1) Press ON/OFF key to turn instrument ON/OFF.
2) Default temperature scale is Fahrenheit. To change
temperature scale, with instrument turned OFF,
press and hold key and then press key
to enter USER MODE
(NOTE: Display will show
“USEr”)
. Press key to switch between
Fahrenheit and Celsius
(NOTE: Display will toggle
between “F” and “C” icons on right side of
display with each press of the key).
Press
key to exit USER MODE to use instrument in
STANDARD TEMPERATURE MODE.
3) The instrument has an auto off feature that will turn
off unit after 10 minutes of non keypad activity to
conserve battery life. To disable auto off feature, with
instrument turned OFF, press and hold the MODE
key and then press key to enter USER
MODE. Press key to enable or disable auto off
feature. When active, the AUTO icon appears at the
top of LCD display. Press key to exit USER
MODE to use instrument in STANDARD
TEMPERATURE MODE.
ITS MODE (Intelligent Temperature Stabilization™):
1) To use ITS MODE, press to turn instrument ON. On
power up, the instrument is placed in STANDARD
TEMPERATURE MODE. Press the key to
select and activate the ITS function. The ITS icon will
appear at the top of the LCD when ITS MODE is
selected.
4) The instrument has an auto off feature that will turn
off unit after 10 minutes of non keypad activity to
conserve battery life. To manually turn instrument off,
press and hold key momentarily. To disable
AUTO-OFF feature, press and hold key and
then press key.
(NOTE: “AUTO” icon at top
of display will appear when AUTO-OFF feature is
active).
5) The resolution default setting is tenth degree. To
change resolution to whole degree, press and hold
key and then press key.
6) Press key to turn on backlight. When pressed,
the backlight will remain on for 5 seconds and
automatically turn off.
NOTE: USE OF BACKLIGHT WILL
SIGNIFICANTLY DECREASE BATTERY
LIFE DUE TO INCREASED POWER
REQUIRED FOR BACKLIGHT OPERATION
7) The instrument has a “HOLD” feature to capture the
current temperature reading on the display. To
activate the hold feature, press and release the
key. The current temperature reading will flash on the
display and the hold icon will appear at top of display.
Press the key again to return to STANDARD
TEMPERATURE MODE.
45
AquaTuff™ 353 THERMOMETER
Press to turn instrument ON or OFF.
Press to select Standard, ITS™, or Memory
mode of operation.
In ITS Mode, press to store ITS
temperature readings. In Memory Mode,
press to scroll forward. In User Mode, press
to select temperature scale.
In Memory Mode, press to scroll backward.
In User mode, press to enable/disable
Auto Off feature.
OPERATION OVERVIEW:
There are 3 Main Modes of operation:
1) Standard Temperature Mode
2) Intelligent Temperature Stabilization™ (ITS™) Mode
3) Memory Mode
AquaTuff™ 352 THERMOMETER
OPERATION - Continued:
AquaTuff™ 353 THERMOMETER
