Atlantis Land 10/100Mbps Manuale utente

16 ports

10/100Mbps Fats Ethernet Switch

Layer 2

with 1 optional port

100Base-FX Fiber Module

USER’S GUIDE

The Atlantis Land logo is a registered trademark of Atlants Land

SpA. All other names mentioned mat be trademarks or registered

trademarks of their respective owners. Subject to change without

notice. No liability for technical errors and/or omissions.

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is

operated in a commercial environment. This

equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with this user’s guide, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area

is likely to cause harmful interference, in which

case the user will be required to correct the

interference at his/her own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference, in which

case the user may be required to take adequate

measures.

UL Warning

a) Elevated Operating Ambient Temperature- If installed in a

closed or multi-unit rack assembly, the operating

ambient temperature of the rack environment may

be greater than room ambient. Therefore,

consideration should be given to installing the

equipment in an environment compatible with the

manufacturer's maximum rated ambient

temperature (Tmra).

b) Reduced Air Flow- Installation of the equipment in a rack

should be such that the amount of air flow

required for safe operation of the equipment is not

compromised.

c) Mechanical Loading- Mounting of the equipment in the rack

should be such that a hazardous condition is not

achieved due to uneven mechanical loading.

d) Circuit Overloading- Consideration should be given to the

connection of the equipment to the supply circuit

and the effect that overloading of circuits might

have on over current protection and supply

wiring. Appropriate consideration of equipment

nameplate ratings should be used when

addressing this concern.

e) Reliable Earthing- Reliable earthing of rack-mounted

equipment should be maintained. Particular

attention should be given to supply connections

other than direct connections to the branch circuit

(e.g., use of power strips).

TABLE OF CONTENTS

ABOUT THIS GUIDE............................................................................ 1

PURPOSE .................................................................................................... 1

TERMS/USAGE........................................................................................... 1

INTRODUCTION .................................................................................. 3

FAST ETHERNET TECHNOLOGY ................................................................ 3

SWITCHING TECHNOLOGY ........................................................................ 4

VLAN (VIRTUAL LOCAL AREA NETWORK)............................................. 5

FEATURES.................................................................................................. 6

UNPACKING AND INSTALLATION ................................................ 7

UNPACKING ............................................................................................... 7

INSTALLATION........................................................................................... 8

RACK MOUNTING...................................................................................... 9

CONNECTING NETWORK CABLE ............................................................. 10

AC POWER .............................................................................................. 10

IDENTIFYING EXTERNAL COMPONENTS ................................ 11

FRONT PANEL.......................................................................................... 11

REAR PANEL............................................................................................ 12

UNDERSTANDING LED INDICATORS ......................................... 13

POWER AND SYSTEM LEDS.................................................................... 13

PORTS 1~16 STATUS LEDS..................................................................... 14

FIBER MODULE LEDS............................................................................. 14

CONFIGURATION.............................................................................. 15

CONSOLE PORT (RS-232 DCE)............................................................... 15

CONFIGURING THE SWITCH..................................................................... 16

MAIN MENU ............................................................................................ 18

CONFIGURING SETUP SETTING................................................................ 19

CONFIGURING SYSTEM SETTING............................................................. 23

CONFIGURING FILE SETTING................................................................... 24

STATISTICS .............................................................................................. 25

TECHNICAL SPECIFICATIONS ..................................................... 28

A02-F16-F/M2 (september 2002)

ABOUT THIS GUIDE

Congratulations on your purchase of the 16-Port 10/100Mbps

Fast Ethernet Smart Switch. This device

integrates 100Mbps Fast Ethernet and 10Mbps

Ethernet network capabilities in a highly flexible

package.

Purpose

This guide discusses how to install your 16-Port 10/100Mbps

Fast Ethernet Smart Switch.

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers to

your 16-Port 10/100Mbps Fast Ethernet Smart

Switch, and “switch” (first letter lower case)

refers to other Ethernet switches.

INTRODUCTION

This chapter describes the features of the 16-Port 10/100Mbps

Fast Ethernet Smart Switch and some background

information about Ethernet/Fast Ethernet and

Switching technology.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity

of desktop computing applications are fueling the

need for high performance networks. A number of

high-speed LAN technologies have been proposed

to provide greater bandwidth and improve

client/server response times. Among them,

100BASE-T (Fast Ethernet) provides a non-

disruptive, smooth evolution from the current

10BASE-T technology. The non-disruptive and

smooth evolution nature, and the dominating

potential market base, virtually guarantee cost-

effective and high performance Fast Ethernet

solutions.

100Mbps Fast Ethernet is a standard specified by the IEEE 802.3

LAN committee. It is an extension of the 10Mbps

Ethernet standard with the ability to transmit and

receive data at 100Mbps, while maintaining the

CSMA/CD Ethernet protocol. Since the 100Mbps

Fast Ethernet is compatible with all other 10Mbps

Ethernet environments, it provides a

straightforward upgrade and takes advantage of

the existing investment in hardware, software, and

personnel training.

Switching Technology

Another approach to pushing beyond the limits of Ethernet

technology is the development of switching

technology. A switch bridges Ethernet packets at

the MAC address level of the Ethernet protocol

transmitting among connected Ethernet or Fast

Ethernet LAN segments.

Switching is a cost-effective way of increasing the total network

capacity available to users on a local area

network. A switch increases capacity and

decreases network loading by dividing a local

area network into different segments, which don’t

compete with each other for network transmission

capacity.

The switch acts as a high-speed selective bridge between the

individual segments. The switch, without

interfering with any other segments,

automatically forwards traffic that needs to go

from one segment to another. By doing this the

total network capacity is multiplied, while still

maintaining the same network cabling and adapter

cards.

Switching LAN technology is a marked improvement over the

previous generation of network bridges, which

were characterized by higher latencies. Routers

have also been used to segment local area
