Atlantis Land Edge-Core A07-ES4704BD Manuale utente

Networking

Edge-Core

ISO 9001:2000 Company Certied

Chassis Core Routing Switch

• Ideal for enterprise network

• 4 slot

• 120 Gbps switching capacity and 104 Mpps packet forwarding

• “Hot Swap” for all the modules

• Fan, Power and Module redundancy

Edge-Core A07-ES4704BD chassis routing switch is a high performance switch.

It is an ideal switch for core layer of campus network and enterprise network, and

aggregation layer of IP metropolitan network. Edge-Core A07-ES4704BD has 4

slots. Each management module has forwarding interfaces, which increases the

port density and usage of slots. Edge-Core A07-ES4704BD provides 120 Gbps

switching capacity and 104Mpps packet forwarding. It can support maximum 6 10G

ports, 96 Gigabit ports and 96 Megabit ports. The high capacity enables the switch

to forward Layer 2/Layer 3 traf c in line speed. Edge-Core A07-ES4704BD sup-

ports various types of Network Interface (NI) modules, including Megabit, Gigabit

and 10G modules. It will also support policy-based routing*, IPv6*, MPLS, load

balance*, VPN*, Firewall*. These features meet users’ different network require-

ments. Moreover, Edge-Core A07-ES4704BD is equipped with high Reliability,

such as Fan Redundancy, Power Redundancy, Management Module Redundancy

and Link Redundancy, Hot-swap for all the Modules, AC and DC Power Supplies

and Temperature Sensor.

A07-ES4704BD

PRODUCT:

CODE:

EAN CODE:

Networking

Edge-Core

Subject to change without notice

A07-ES4704BD_SE_065

AtlAntis lAnd S.p.A. - Viale De Gasperi 122

20017 Mazzo di Rho - Milano - ITALY

Phone: +39 - (0)2 - 93.90.60.85 Fax: +39 - (0)2 - 93.90.61.61

Web: www.atlantis-land.com

E-Mail: info@atlantis-land.com

Chassis Core Routing Switch

A07-4704BD

8026974012285

Chassis Core Routing Switch

TECHNICAL FEATURES

Features

IGMP: Snooping v1/v2

IP Routing:

- RIP v1/v2

- RIP

- BGP*

IPSec: VPN up to 9K

IPv4

IPv6*: Future Upgrade

Link Aggregation:

- Load Balancing for both Unicast

- Max trunk per system: 6

- Max port per trunk: 8

- IEEE802.3ad (LACP)

Multicast:

- PIM-DM/SM

- DVMRP

Spanning Tree

- IEEE802.1w Rapid Spanning Tree

- IEEE802.1s Multiple Spanning Tree

- IEEE802.1D Spanning Tree

VLAN:

- GVRP

- 4K VLAN ID

- 255 tagged VLAN

- IEEE802.1Q

VRRP

Networking

ARP

Concurrent Sessions: 70000

DHCP Client/Server, dynamic IP, static IP

DMZ

DNS (Relay/DDNS)

FTP/TFTP

ICMP

IP Routing

NAT(ALG,port forwarding and port tigger)

Password for web access

PPPoE

TCP/IP

Management

Console: RJ-45

Firmware Image: Dual

RMON 1, 2, 3, 9

SNMP: v1/v2c/v3

Support Telnet

SysLog

Performance

Backplane Capacity: 125Gbps

IP Routing Table: 64K

MAC Entries: 16k

Packet Forwarding Rate: 107 Mpps

Switching Capacity: 120Gbps

VLAN: 4K

Physical Configuration

10 Gigabit ports: 6 (Max)

10/100Base-T ports: 48(Max)

AC power supply: 1

Gigabit ports: 48(Max)

open module slots: 4

QoS (Quality of service)

DiffServ

IEEE802.1p

MPLS*: Future Upgrade

Queues per port: 8

Rate Limiting

Scheduling,WRR,SWRR: Strict Priority

ToS

Security

802.1x

ACL

RADIUS Authentication

SSH

User name/Password protection

*Check for avalibility
