Audi A4 Cabriolet •S4 Cabriolet

Quick reference guide

Fuel

(see sticker)

Tyre pressures

(see sticker on door

pillar on driver side)

Fuel tank flap

To open:

Press the right side of the flap.

To close:

Press the tank flap until you hear

it click into place.

Engine oil

The correct oil specifi-

cations and engine oil

capacity are listed in

the Performance,

weights and dimen-

sions section of the

Owner’s Manual.

Warning triangle

The compartment for the warning

triangle is located inside the boot lid.

Welcome

Dear Audi Driver,

This quick reference guide gives you

an overview of the main features and

controls of your vehicle. However, it

cannot replace the detailed Owner’s

Manual which contains important

information and safety warnings.

Please refer to your Owner's Manual

for detailed information on your vehicle.

You will find everything you need to

know about the radio, CD, navigation, TV

and telephone functions in the Operating

Manual for your sound system or

navigation system.

We wish you safe and enjoyable

motoring with your new Audi.

AUDI AG

Controls and

displays

Buttons for seat memory

Electric windows

To set the desired position:

Press/pull to the first stop

and hold.

„One-touch“ function:

Press/pull briefly to the

second stop.

Bonnet lock release

Steering wheel position

adjuster

10 14

12 12

11 11

Door handle and

central locking switch

Unlock

Lock

Adjuster for exterior

mirrors

Turn the adjuster for:

Left exterior mirror

Exterior mirror heating

Right exterior mirror

Exterior mirror

retraction

Press the adjuster to move

the mirror glass in the

desired direction.

Overview

Air conditioner

Driver’s seat heating

Front passenger’s seat

heating

Gear lever or selector lever

for automatic gearbox

Handbrake

Power-operated soft top

Cigarette lighter/electrical

socket

Windscreen wipers/washer

and buttons for on-board

computer

Ignition lock

Switches and warning

lamps for:

Electronic stabilisation

program

Passenger airbag off

Hazard warning lights

Storage tray

Sound system or

navigation system

ESP

OFF

16 17

Cruise control system

Headlight range control

and coming home/leaving

home function

Light switch

Turn signal and main beam

lever

Controls on multi-function

steering wheel

tiptronic paddle levers

Instruments and warning/

indicator lamps

21 3

Seat adjustment

Electric seat adjustment

To adjust seat height and move seat backwards or forwards:

Front of seat cushion up/down

Rear of seat cushion up/down

Seat up/down

Seat forwards/backwards

To adjust backrest:

Backrest further upright/

further reclined

Head restraint up/down

To adjust lumbar support:

Press the appropriate

part of the switch.

Manual seat adjustment

To move seat backwards or forwards:

Lift the lever and move the seat. Then

release the lever and move the seat further

until the catch engages.

To adjust angle of seat cushion:

Lift the lever and adjust the seat angle.

To adjust seat height:

Pull up or press down the lever repeatedly.

To adjust lumbar support:

Press the appropriate part of the switch.

To adjust backrest:

Take your weight off the backrest and turn

the knob.

Easy entry function:

Pull the lever upwards and fold the backrest

forwards; then release the lever and move

the seat forwards.

To adjust head restraint:

Press the button on the side of the head

restraint and move the head restraint up or

down. The top of the head restraint should

be at eye level or higher.

Sitting position

Sit in a normal upright position and

do not sit too close to the steering

wheel. If necessary, also adjust the

position of the steering wheel.

min.

25 cm

First steps

Starting the engine

Switching on the ignition/starting the engine

Insert the key into the ignition lock.

To switch on the ignition: Turn the key to

position . The glow plugs on diesel

engines start preheating in this

position.

To start the engine (on vehicles with

manual gearbox): Press the clutch

and turn the key to position until

the engine starts.

To start the engine (on vehicles with

automatic gearbox): Move the selector

lever to position Por N, press the brake

pedal, and turn the key to position until

the engine starts.

To switch off the engine: Turn the key to position .

Automatic gearbox

Selector lever positions

PParking lock

RReverse gear

NNeutral

DDrive (forwards)

SSport position

To release the selector lever and

engage a gear: Switch on the ignition,

press the brake pedal, and press the

interlock button on the selector

lever. Move the selector lever to

Dor Sto start driving forwards.

tiptronic: To switch to manual

gear selection mode, push the

selector lever from position D

to the right. The gears are

shown on the driver infor-

mation system.

To shift up or down a gear:

Briefly push the selector lever forwards or

backwards.

Air conditioner

Variable

soft top storage box

The storage box can be raised in order to

extend the luggage compartment.

The soft top must be closed!

To raise: Slide the lever to position .

To lower: Slide the lever to position .

Switches for air conditioner

Buttons on left: Temperature

selection for left side

Buttons on right: Temperature

selection for right side

Buttons in centre: Blower speed

Automatic mode

Set the desired temperature and

press the button

Air recirculation

Circulates and filters the air in the

interior of the vehicle

ECON mode

Activates/deactivates air cooling

To deactivate the air conditioner

Air to the windows

Air from the dashboard outlets

Air to the footwells

ECON

AUTO

Power-operated

soft top

To open the soft top:

Switch on the ignition.

Pull and hold the

switch until

the soft top is fully

open.

To close the soft top:

Switch on the ignition.

Press and hold the

switch until the

soft top is fully closed.

Technology

Setting up:

pTake the windbreak out of the storage

bag (luggage compartment).

pFold the two side sections outwards.

pPull out the retainer pegs (left/right)

and hold the windbreak in a horizontal

position against the backrest upholstery.

pSlide the retainer pegs (left/right) all

the way into the mountings.

pPress the release catches (left/right)

and slide the locking pins into the

mounting holes at the sides.

pFold the vertical section of the wind-

break into the fully upright position.

Removing:

Follow the instructions in reverse order.

Windbreak

Cruise control

system

When the system is switched on, the

indicator lamp appears in the

instrument cluster.

To switch on/off: Pull/press lever .

To set speed: Press button .

To adjust stored speed: Press lever up

(faster) or down (slower).

Audi Navigation System plus

Components

Driver information system

Multi-function steering wheel

Scroll the left thumbwheel to select a menu item in the

driver information system. Press the thumbwheel to

confirm the selection.

Press the MODE button to switch between the active audio

source and the navigation and telephone functions.

Scroll the right thumbwheel to adjust the volume. If you

press the right thumbwheel, the last navigation cue will be

repeated.
