Audiovox Electronics Shuttle SIR-PNP3 Manuale utente

128-7193A

1 of 32

Shuttle User Guide SIR-PNP3

JUMP

s.seek

.tune

Category A-112:00P

Artist

Song

001 ChannelNam e

Released: 8-6-04

Revision A: 8-10-04 Removed maximum FM frequency reference; default display mode PDT to 2 lines

and font type to A.

128-7193A

2 of 32

Congratulations

You are one step closer to experiencing the latest innovation in Sirius Satellite Radio. Sirius will

revolutionize your in-home or vehicle entertainment with:

•Over 120 channels of original programming, including –

65 channels of 100% commercial-free music – guaranteed,

Over 50 channels of world-class sports, news, talk and information.

Your Audiovox Shuttle receiver must be used with an adapter kit, such as the Audiovox Home kit,

Boom Box or Vehicle Kit as required by your specific installation needs. These kits are available at

retailers where Audiovox main units are sold.

AudiovoxHomeKit: Part Number SIR-HK3

AudiovoxVehicleKit: Part Number SIR-CK3

AudiovoxBoomBox: Part Number SIR-BB3

-2-

128-7193A

3 of 32

-3-

Contents

Cautions and Warnings ...................................... 4

Shuttle System Components .............................. 4

Introduction .......................................................... 5

Enjoying Your Sirius Shuttle ................................ 5

Sirius Shuttle Controls......................................... 6

Basic Operation ................................................... 8

Tuning by Category .......................................... 8

Content Listing Options (Look Ahead) ............ 8

Direct Tuning ......................................................9

Setting/Using Channel Preset Buttons .............9

Preset List Mode ..............................................10

Display Button .................................................. 10

Memory Button (S-Seek Function) ................... 11

Menu Display Options ......................................... 14

Sirius ID ............................................................ 14

Jump Settings .................................................. 14

Display Settings ............................................... 18

FM Transmitter Options ................................... 19

Add or Skip ....................................................... 20

Lock Options .................................................... 20

Lock/Unlock Default Code Function ................ 20

Edit Code.......................................................... 21

Audio Level Options ......................................... 21

Antenna Aiming (Home Installation)................ 21

Memory Options ............................................... 22

Time Based Features ...................................... 22

Clock................................................................. 22

Format........................................................... 22

Time Zone..................................................... 23

Alarm Clock .................................................. 23

Alarm Time ................................................... 24

Program Alert ................................................... 24

Time/Day....................................................... 24

Channel ........................................................ 25

Program Alert On/Off..................................... 25

Auto Shutdown ................................................. 25

Sleep Mode ...................................................... 25

Factory Default ..................................................... 26

Remote Control Unit ............................................ 26

Troubleshooting .................................................. 28

Specifications ...................................................... 28

APPENDIXA ......................................................... 29

Warranty ............................................................... 31

128-7193A

4 of 32

Cautions and Warnings

1. Do not install the Shuttle in a position that hinders

your view through the windshield, or obstructs view-

ing of the dashboard indicators and displays.

2. Do not install the unit where it may obstruct the

operation or deployment of safety devices, such

as airbags, etc.

3. Do not allow operation of the unit to detract from

safe driving practices; remember that you are

responsible as the vehicle operator to adhere to

all safe driving and traffic regulations.

4. This device complies with Part 15 of the FCC Rules.

Operation is subject to the condition that this device

does not cause harmful interference.

5. By adhering to these warnings and safety consider-

ations, serious accidents and/or personal injury can

be avoided.

Introduction

The Audiovox SIRIUS® Shuttle processes the satellite

signals received by the externally mounted antenna

(purchased separately as part of the Home, Vehicle or

Boom Box Kits). The Shuttle recognizes and decodes

the incoming SIRIUS® program information and

provides an audio signal to your radio or other audio

output equipment. -4-

Shuttle System Components

Shuttle Unit

Model PNP3,

P/N144-2453

Remote Control Unit

P/N136-3803

Batteries for

Remote, (2) “AAA”,

P/N156-2215

JUMP

s.seek p.tune

Category A-112:00P

Artist

Song

001 ChannelNam e

128-7193A

5 of 32

NOTE: The SIRIUS® signal can be received and

processed virtually anywhere as long as there

are no obvious satellite signal obstructions

such as nearby buildings, high terrain,

parking garages or tunnels.

The Shuttle is typically installed in an

accessible location of the vehicle (dash area),

consistent with line-of-sight operation of the

remote control, and/or within easy reach of the

driver. For home use, situate the Shuttle

close to your stereo receiving equipment.

Enjoying Your SIRIUS®

Shuttle

You can begin to enjoy Sirius®Satellite Radio as soon

as the Shuttle and Kit installation are complete:

1.Set up your Audiovox Shuttle using the installation

instructions included in your Home Kit, Vehicle

Kit or Boom Box Kit, or with the help of a profes

sional installer.

NOTE: Refer to Antenna Aiming (page 21) during

the installation procedure.

2. When power is available to the unit, note that the

integral Power button LED icon lights red. Then

press the Power button to turn on the Shuttle.

3. The Sirius logo ( ) appears on the display

followed by the Sirius preview channel. If this is the

first time using the Shuttle, the screen will display

“Updating Channels”. If not, go to channel 184 us-

ing the direct channel method, page 9, Direct Tun-

ing.

4.To obtain the Sirius identification (ID) number,

press the MENU button. The Menu Options page

appears with the Sirius ID option highlighted. Press

the Encoder knob and the 12 digit Sirius ID number

will appear. Write the number here for future refer-

ence.

5.Activate your Sirius®radio service ---- it’s easy. You

have one of two choices to activate your service:

(a) Visit the website at sirius.com and click on

the “JOIN” section. You will then need to follow

some simple directions and provide Sirius with

some basic information in order to activate your

service.

-5-

128-7193A

6 of 32

(b) Call Sirius at 1-888-539-SIRIUS (7474). One of

our friendly Customer Care representatives will

takethe necessary information and walk you

through the activation process.

Sirius® Shuttle Controls

The Audiovox Sirius®Shuttle Unit provides eight control

buttons, an Encoder knob and 10 number keys.

Power Button:

This button applies power to and removes power from

the Sirius®Shuttle as follows:

1. A momentary press of the power button turns on

the receiver, and is accompanied by a confirmation

beep tone. The Sirius logo/name ( ) initially

appears on the LCD display for 3 seconds, followed

by the Default screen (if turned on for the first time),

or by the tuning mode in effect when the unit was

last powered off.

2. A momentary press of the power buttonturns off

the receiver. While the unit powers down, the

Audiovox logo appears for 2 seconds and the

unit turns off.

-6-

Category A-112:00P

Artist

Song

001 ChannelName AUTOSIZING/

SCROLLING

ARTIST NAME

BAND/PRESET

BANKNUMBER

CLOCK

8-CHARACTER

CATEGORY

(UP/DOWN)

BUTTONS

INFRARED

SENSOR

PRESET(NUMBER)

BUTTONS

JUMP

BUTTON

128-7193A

7 of 32

-7-

Encoder Knob and Select Button:

The Encoder knob is the primary control for navigating

through the various lists and option menus available on

the unit. In the default mode, the Encoder knob provides

sequential tuning through the available program chan-

nels. Clockwise (CW) rotation tunes up one channel-

per-detent,while Counterclockwise (CCW) rotation tunes

down one channel-per-detent. When in the list or menu

mode, turning the Encoder knob CCW and CW scrolls

down and up, respectively, through the various menus

and lists. The current selection from the list will be high-

lightedon the display.Whenthe item is highlighted, press

the Encoder knob (Select Button) to enter the selection.

Pressing and holding the Encoder knob will tune to the

previously selected channel.

Category Buttons:

The Up or Down category buttons allows the user to ad-

vance through the channel groups based on content

category. By turning the rotary Encoder knob, the user

can then scroll up or down through the channels within

that category. Once a choice has been made, it can be

entered by pressing the Select Button.

Memory(MEMO)Button(s-seek) Function):

This feature allows the user to capture and store the cur-

rent program data information (Channel Name & Num-

ber/Artist & Song title). You can store up to 24 Artist/Song

Title combinations. The Shuttle also has the capability to

search the current incoming Sirius signal, and thereby

alert you if it matches the Artist/Song title stored in Shuttle

memory.

Display(DISP)Button:

This button allows the user to choose one of several ways

of presenting the Channel Name, Artist and Song title

information on the LCD screen.

Menu(MENU) Button:

TheMENUButton is used toaccess “Menu Options” which

displays the user setup menu, plus other feature/function

adjustments.

BANDButton(BAND)/PresetTune (p.tune):

Each momentary press of the BAND Button allows the

user to switch between 3 bands of Channel presets (10

presets each A, B and C). Pressing and holding the BAND

Button for 2 seconds initiates preset tuning (accompa-

nied by a beep confirmation tone) that will display and

tune all stored preset channels in sequence. This is

indicated by the reverse image of the channel number

128-7193A

8 of 32

and band preset number on the display. Pre- set tuning

continues until the user decides to terminate this func-

tion by pressing and holding the BAND Button for 2 sec-

onds.

Keypad Buttons 0-9:

These buttons are used to directly enter a desired chan-

nel number. They are also used when entering and re-

calling preset channel numbers into memory.

Jump ( ) Button:

As an example, the button stores a favorite memory

preset to allow you to easily tune to a selected city of

interest (or any other channel), and then tune back to the

music/talk/sports programming you were previously lis-

tening to.

BasicOperation

With the unit properly installed, activated and connected

to your home or vehicle audio system, proceed as fol-

lows:

1. Press the Power button; the Shuttle turns on and

the Sirius logo appears for 3 seconds followed by

the default display for the channel and tuning mode

in effect prior to turnoff.

1. Using the Encoder knob, select the desired chan-

nel.

2. Press the Encoder knob to select that channel.

3. Once the channel has been selected, the unit will

revert to the default screen and your selection

will be played.

Content Listing Options (Look Ahead)

This feature allows you to view what is playing on other

channels without having to change the current channel

you are listening to. The content listing options are se-

lected by using the DISP button. When the default screen

-8-

2. Rotate the Encoder knob to select and play the

desired channel, or use the Category Up/Down

buttons to tune and select a desired channel based

on genre.

Tuning By Category

When in Category Tuning Mode, each momentary

press of the Category Up/Down Button(s) advances

through the available Genres:

Category List Display

004 Channel Name

003 Channel Name

001 Channel Name

002 Channel Name

Manuali Ricevitore popolari di altre marche

Garmin

Garmin GA 23 Manuale utente

Aiphone

Aiphone PS-12F Manuale utente

IMES

IMES TCS-01CA-PMI Manuale utente

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuale

AMIMON

AMIMON AMN12310 WHDI Manuale utente

Dual

Dual DMCPA79BT Istruzioni operative

Sound Associates

Sound Associates SA652P Manuale utente

Sherwood

Sherwood NewCastle R-772 Manuale utente

Audio

Audio A10-RX Series Manuale utente

AllSee

AllSee PushShare PSRV1.1 Manuale utente

DEMAG

DEMAG DRC-DR D2 Manuale utente

Teleco

Teleco TVRCL868A02 Manuale utente

Bosch

Bosch RF3222E Manuale utente

Kramer

Kramer 631R Manuale utente

Xpress

Xpress xmc10 Manuale utente

JVC

JVC KD-MR1BTS Manuale utente

Omega Engineering

Omega Engineering UWTC-REC3 Manuale utente

e-survey

e-survey E300 Pro Manuale utente
