Audiovox AS 9075a Manuale utente
128-6601
1 of 4
Page 1
Model AS 9075a
Owner’sManual
Remote Start
Upgrade Module
FEATURES :
wRemote Start Safety Control Switch
wSelectable Automatic Timed Start Mode (2 Or 4 Hours Selectable intervals)
wOn-Board Start Relay
wOn-BoardAccessoryRelay
wOn-Board Ignition 1 Relay
wOn-Board Ignition 2 Relay
wIgnition 2 Relay Selectable On or Off During Cranking
wOn-Board Parking Light Relay
wIgnition 3 / Shock By-Pass / GM VAT Output (relay required)
wTach Signal Learning Circuitry
wTwo ( +) and Two ( -)Safety Shutdown Circuits
w
AlarmBy-Pass Outputs
w
Selectable Steady or Flashing Parking Lights for Run Indication
wSelectable 10 or 15 Minute Run Time
wFactoryKeyless UpgradeInputs(AllowsStartingFromFactoryKeylessEntryUnit)
w4 Auxiliary Outputs To Allow Control Of A Factory Alarm
wDiesel Glow Plug Preheat Mode select
CAUTION!
Be certain that the vehicle is outdoors before using this or any re-
motevehiclestartingdevice. Arunningengine produces dangerous
carbon monoxide fumes which can be harmful or fatal if prolonged
exposure occurs. DO NOT remote start the vehicle if the car is
garaged.
128-6601
2 of 4
Page 2
This Remote Start Upgrade unit is designed to be added to an existing remote
control keyless entry system, or remote alarm system.
Because it is an upgrade unit it can be wired to operate from any unused button(s)
from your keychain transmitter. Please check with your installing dealer for which
transmitter button is connected to your remote start unit and, if you require a
single, double, or sequential press of the button(s) to operate your system.
SAFETY(RedHandled )CONTROLSWITCH
The control switch allows you to temporarily disable the remote starting function
of your Remote Start System. To disable the unit, move the red handled control
switch to the off position.
The control switch also allows you to select between automatic 2 hour start up
or 4 hour start up when using the automatic start up timer mode. The factory
preset start up time for this mode is every 4 hours. To select between 2 or 4 hour
start up timer:
1.Begin with the control switch in the on position
2.Turn the ignition switch on then off
3.Within 10 seconds, move the control switch off, on, off, on (2 switch cycles) to
select a 2 hour start timer. After 10 seconds expire, the parking lights will
flash 2 times confirming that the two hour start cycle is set. Or, within 10
seconds move the control switch off, on, off, on, off, on, off, on (4 switch cycles)
to select a 4 hour start timer. The parking lights will flash 4 times confirming that
the 4 hour start timer is set.
REMOTESTARTINGTHEVEHICLE
The System WILL NOT start the vehicle if any one of the following conditions
exists:
1.The Vehicle Hood Is Opened.
2.The Gear Selector Is In Any Gear Other Then Park.
3.The Brake Is Depressed.
4.The Safety Control Switch Is In The Off Position.
CAUTION! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon monox-
ide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT
remote start the vehicle if the car is garaged.
128-6601
3 of 4
To Remote Start The Vehicle:
Press and release the proper button or combination of buttons on your keychain
transmitter to activate the remote start system. The vehicle will start and
remain running for the pre-programmed 10 or 15 minutes. As a visual indica-
tion, the parking lights will flash or turn on dependent on the programming set
up by your installation center.
When you arrive at your vehicle, unlock the vehicle by pressing and releasing
the unlock button of your keychain transmitter or by use of the vehicle key. Enter
the vehicle and turn the ignition key to the on position.
CAUTION! Do not turn the key to the start position. This will cause the starter
motor to engage with the already running
engine which could result in damage. Step on the brake
pedal to disengage the remote start unit. The vehicle will continue to run on it's
own power.
NOTE: The engine will stop running before the expiration of the pre-pro-
grammed run timer if you complete any of the
following:
1.Pressing the proper button or buttons of your keychain transmitter while run-
ning under control of the remote start system will turn
the vehicle off.
2.Depress the brake pedal.
3.Open the hood.
4.Move the red handled control switch to the off position.
5.Race the engine to above 4000 RPM.
OPERATINGONAUTOMATICSTARTUPTIMERMODE
The system has the ability to automatically start the vehicle every 2 or 4 hours
over a 48 hour period. This feature is especially useful in cold climates where
the only means to keep the engine and engine fluids warm is to periodically
start the engine.
CAUTION! Be certain that the vehicle is outdoors before using this or any re-
mote vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure occurs.
DO NOT remote start the vehicle if the car is garaged.
Page 3
128-6601
4 of 4
FUNCTIONSETTINGCHART
To be completed by installer
Lights Steady oPulse o
Run Time 10 Min. o15 Min. o
TOBEGINTHEAUTOMATICSTARTUPTIMER
1.Turn the ignition key on then off.
2.Within 10 seconds, activate the RF start command two times.
The parking lights will flash 4 times indicating the timed start mode is activated.
The vehicle, on a 2 or 4 hour interval basis, will automatically start, run
for the pre-programmed time (10 of 15 minutes), and then shut off. This will
continue for 48 hours.
NOTE: The automatic start up timer can also be initiated from the keychain trans-
mitter.
To do this:
1.Start the vehicle using the keychain transmitter by pressing and releasing the
remote start transmitter button'(s).
2.Shut off the vehicle using the keychain transmitter by pressing and releasing
the remote start transmitter button'(s).
3.Within 10 seconds of step 2, activate the RF start command two times.
The parking lights will flash 4 times indicating the timed start mode is activated.
CANCELINGTHEAUTOMATICSTARTUPTIMER
To cancel the automatic start up timer do one of the following;
1. Start the vehicle manually with the use of the ignition key and depress the
brake pedal.
2. Remote start the vehicle using your keychain RF transmitter.
And then
3. Shut off the vehicle using the keychain RF transmitter.
150 Marcus Blvd., Hauppauge NY 11788 ®(516) 231-7750
128-6601
