Your Auto8

Set-up Guidelines

Ensuring that the AQUAvalve floods

and drains correctly

Care and maintenance

Making sure your AQUAvalve ﬂoods and

drains correctly is simply achieved and

only takes a few seconds.

Hold the AQUAvalve at eye level so that

you can see the silicon ﬁtted to the top ﬂoat

resting on the hole below it.

The silicon must create a tight seal when

touching the hole.

If it looks like it is not sitting parallel on the

hole below, simply lift the top ﬂoat and

apply pressure to one side of the silicon,

drop the ﬂoat and hold at eye level again.

Repeat the procedure if necessary.

At the end of your growing season, clean

the AQUAvalve using warm soapy water.

Using an old tooth brush will help.

The AQUAvalve is easily disassembled.

The top ﬂoat will slide all the way across

and the bottom ﬂoat is unclipped from its

pivoting position. The circular discs ﬁtted to

the top ﬂoat can also be removed by using

pliers to grip the raised point.

At this point is it advisable to remove the

silicones to avoid them being lost.

It is also handy to have a paper clip or

pipe cleaner to hand so that you can push

it through the AQUAvalve nozzle, this will

remove any lime scale build up that may

have occurred during the growing season.

Blowing through the AQUAvalve nozzle will

also help to remove any build up. Do not

under any circumstances use a drill & drill

bit to clear the AQUAvalve nozzle.

This will potentially damage the

AQUAvalve beyond repair.

Simple care

guidelines

Ensure the silicon is sitting parallel on

the hole below it. Hold at eye level

to check the position is correct

plants

Allow your

establish

before turning your

system

If you require any guidance email - [email protected]

Advice

Allow your plants to establish for 7-10 days before turning system on

[email protected] I www.autopot.co.uk I +44 (0)844 8581520

• 1x Auto8 tray

• 1x Auto8 lid

• 1x Round blue access cover

• 1x AQUAvalve

• 1x AQUAvalve cover

• 1x 6mm top hat grommet

• 1x metre 6mm piping

• 8x Marix disc (square)

• 8x PotSock Square

• 8x 8.5 ltr pot if (AUTO8/8.5)

• 8x 15 ltr pot if (AUTO8/15)

Auto8 contents Auto8 Setup

Advice

• Pot up your plants, water through, then allow your plants to establish in the pots for a period of 7 to 10 days before

turning your system on. This will encourage a stronger and healthier root system.

• Always raise your reservoir to a minimum of 150mm above the highest AQUAvalve and re-ﬁll the reservoir when

there is approximately a 1/3 of the solution left - NEVER ALLOW THE RESERVOIR TO RUN EMPTY.

• For best results, we recommend mineral fertilisers. Do not use liquid organic fertilisers, as they have a tendency to

block small pipe work.

• Clean all substrate from the bottom and sides of the pots before placing in each tray. This will ensure your system

is clean from the start.

• Always use free draining substrates, for example: soil/perlite, coco/perlite, soil/clay pebbles, coco/clay pebbles,

rockwool/clay pebbles.

Remove any slack

from 6mm pipe by

drawing excess pipe

out of the tray.

Ensure that the circular

spirit level indicates

the tray is level,

adjust if required.

Cut 6mm pipe to

appropriate length.

Connect via 6mm

/ 16mm ﬁttings to a

ﬁlter (not included).

Connect ﬁlter to

reservoir. Leave tap off.

Make sure the

system is clean and

free of debris.

Place the lid on top

of the tray. Insert the

pots. Place the round

blue access cover

over the valve.

Pot and Tray Dimensions

575mm

275mm

195mm

245mm

200mm

8.5 ltr

pot

Place AQUAvalve cover

over the AQUAvalve.

The AQUAvalve and

cover should be placed

directly onto the tray.

1190mm

535mm

Required Reservoir Capacity

FlexiTank and FlexiTank Pro are the only collapsible reservoirs

that AutoPot recommend for use with Auto8 Tray Systems.

A minimum 100ltr reservoir is required per unit.

Push 6mm top hat

grommet into the hole

in the Auto8 tray wall.

Thread 6mm pipe into the

tray through the grommet.

Remove AQUAvalve

collar.

Push 6mm pipe through

collar and attach to

AQUAvalve nozzle.

Rescrew collar - DON’T

overturn... when you

feel it grip STOP.

5 6

Fill pots with medium

and pot up plants.

Water through pots

and allow to drain

outside the tray.

Put the black marix

discs into the pots

Auto8

System Size 1x Auto8 2x Auto8 4x Auto8 8x Auto8 10x Auto8

FlexiTank or

FlexiTank Pro

Capacity

FlexiTank

/ Pro 100ltr

FlexiTank

/ Pro 225ltr

FlexiTank

/ Pro 400ltr

FlexiTank

750ltr

FlexiTank

1000ltr

350mm

245mm

15 ltr

pot

260mm

195mm

300mm

260mm

195mm

300mm

Included with

(AUTO8/8.5)

Included with

(AUTO8/15)

Once pots have drained

ﬁt a PotSock Square over

the base of each pot.

Make sure the pots are

clean and free of debris.
